Lorex L154-81C4 Manuale utente

DVR

Professional 4 channel DVR (time lapse VCR replacement)

Includes removable 80GB Hard Drive for

up to 2250 Hrs of recording

Rapid search and playback (time, date, event)

Includes remote control

MJPEG compression (5-20KB file size)

Password protection

Supports 2 HDD for a maximum capacity of 500 GB

www.lorexcctv.com

L154-81C4

FEATURES:

CAMERAS

1/4” CCD advanced image sensor produces video with

350 TV Lines and 270K pixels

Advanced Day / Night mode: Picture automatically

switches camera to B&W delivering better clarity in low

light conditions**

12 IR LEDs provides effective night vision range

of 15 ft(5M)

Ceiling or Wall Mountable: Versatile Camera Stand

allows the camera to be mounted on the Wall or Ceiling

Weather resistant camera housing ideal for outdoor or

indoor applications (IP65)*

Component Surveillance System

with Digital Video Recorder and Four Color Cameras

* Not for use in direct exposure to water, rain or snow.

** IR night time low light illumination range up to 15 ft. (5M) under ideal

conditions. Objects at or beyond this range may be partially or completely

obscured, depending on the camera application.

L154-81C4

DVR:

Hard Disk Storage:  IDEType,UTMA66above

   (supports2HDD-upto250GBeach)

Camera support:  4analogCCTV

Video Compression: ModiedMJPEG(5~20Kbyte/frame)

Video Resolution up to: 720x480

Recording Resolution up to: 640x224(fullscreen)

Record Modes:  AlarmExternal/Timer/Manual

Camera inputs:  4BNCVideoinputs

Video output:  2RCAVideooutputs

Alarm history log:  1000events

Security Protection: Passwordprotection

Display refresh rate: 30FPSNTSC,25FPSPAL

Record refresh rate: 30FPSNTSC,25FPSPAL

Video loss detection: Yes

On Screen display:  Yes

HDD Key Lock:  Yes

Playback Searching: Date&Time/FulllistSearching

Alarm input:  TTLinput,High(5V),Low(GND)

Alarm output:  COM/N.O/N.C

Power source:  AC100-240Vswitchingadaptor

Power consumption: 25W

Dimension:  385(W)X73(H)X290(D)mm

Weight:   5kg

Operating temperature: 0°C-50°C

Product Information:

Model#: L154-81C4

Description: 4ChannelDigitalVideoRecorderwith4

CCDColorDay/NightCameras

UPC: 778597154832

Package Weight: 20lbs/9kgs

Package Dimensions: (LxDxH)20”x15.75”x9.75”/

510mmx400mmx248mm

Package Cube: 1.65ft/0.046m

As our product is subject to continuous improvement,

Lorex Technology & subsidiaries reserve the right to modify

product design, specifications & prices without notice and

without incurring any obligation. E&OE

3700 Koppers Street, Suite 504

Baltimore, Maryland 21227,

USA.

Lorex Technology Inc.

300 Alden Road, Markham,

Ontario L3R 4C1

Canada.

Specications:

CAMERA:

Image Sensor:  1/4”InterlinetransfertypecolorCCD

Effective Pixels (NTSC): 510Hx492V(270K)

Resolution:  Horizontal350TVlines

Shutter Speed (NTSC): 1/60~1/10,000sec.

S/N Ratio:  Morethan48dB(AGCoff)

Sync. System:  Internal

Min. Illumination:  1.0LUX(withoutLED)/0.1LUX(withLED)

White Balance:  AWB

Video Output:  VBS1.0Vp-p(75Ωload)

Lens:   FixedLens(6mm)

Power Consumption: 100mA(withoutLED)/180mA(withLED)

Operating Temp:  14Fto113F(-10°C~+45°C)

Weather Proof Rating: IP65

Operating Humidity: 90%RHmax.

Connection type:  BNC

Dimensions:

4in/

102mm

2.5in/63.5mm 3.2in/81mm

15”/385mm

2.8”/73mm

11.4”/290mm

0-23012007
