Specifications
Specification
Weight in lbs. (kg)
Dimensions (inches) (WxDxH)
Dimensions (mm) (WxDxH)
Color Palette
Resolution
SXGA com ression(1024 x 768)
Three 0.9 anel
olysilicone LCD
Projection lam
User-re laceable lam
Brightness (ANSI lumens - based
on industry s ecification ractices)
Contrast ratio
Projection Lens
As ect Ratio
Audio (built in)
Digital Keystone
Video Com atibility
NTSC/NTSC 4.43 PAL B/D/G/H/I/K/L/N/M
SECAM B/D/G/H/K/L
Com uter com atibility
Vertical frequency (Hz)
Horizontal frequency(KHz)
MACINTOSH Com atibility
Audible noise ty ical
Connections on projector
Analog RGB (15 Pin HD)
Com osite video (RCA)
Stereo Audio (1/8 mini- lug)
S-video
USB
Power Supply
Voltage (AC RMS)
Frequency (Hz)
Ty ical Power Consum tion (watts)
O erating Tem erature Range
Storage Tem erature Range]
Humidity Range (relative)
Altitude (o erating)
Altitude (storage)
AV-X2 Plus
7.2 (3.26)
12.8 x 9.8 x 3.6 (with lens)
325 x 250 x 92 (with lens)
16.7 million (24 bit)
1024 x 768 (native)
Yes
Yes
130W, ultra com act
Yes
1600 Lumen
400:1
Manual zoom / focus
4:3, 16:9
mono, 1 x 3 watts
+/ -15º
Yes
VGA/ SVGA/ XGA/ SXGA
56 85
30 90
Yes
< 36 dB (at 25º C)
in x 1, out x 1
Yes (x1)
Yes (x2)
Yes (x1)
Yes (x1)
100-240
50/60
195
0-35º C
-20-70º C
10-95%
0 - 10,000 ft
0 - 3,048 m
0 - 40,000 ft
0 - 12,192 m
LCD Projector
User Guide
English
1
English
FCC Warning
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference
at his own expense.
Canada
This class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du
Canada.
Safety Certifications
UL, CUL, TUV
EN 55022 Warning
This is a Class A product. In a domestic environment it may cause radio
interference,in which case the user may be required to take adequate
measures. The typical use is in a conference room, meeting room or
auditorium.
Declaration of Conformity
We declare under our sole responsibility that the Zoom Digital Projector
conform to the following directives and norms:
Directive 89/336/EEC, Amended by 93/68/EEC
EMI: EN 55022 (1992) Class A
EMC: EN 50082-1 (1992)
IEC 801-2, IEC 801-3, IEC 801-4
Directive 73/23/EEC, Amended by 93/68/EEC
Safety: EN 60950: 1992 + A1 + A2 + A3: 1995
Taiwan BSMI
LCD Projector User Guide
22
22
2
Introduction ........................................................................... 4
What’s in the Box .................................................................. 4
Projector Features ................................................................. 5
Remote Instruction ................................................................ 5
How to use Remote ............................................................... 6
Remote mouse function ....................................................................... 6
OSD Menu Funciton ............................................................................. 6
Connecting the Projector...................................................... 7
S-Video to S-Video Cable .................................................................... 7
D-SUB 15 pin RGB Cable ...................................................................... 7
RCA Video Cable .................................................................................. 7
USB Cable ............................................................................................. 7
Mini-Stereo to Mini-stereo Audio Cable .............................................. 7
Mini-Stereo to RCA Stereo Cable ........................................................ 7
Starting the Presentation ...................................................... 8
Power button ........................................................................................ 8
Turning Off the Projector ..................................................................... 9
Keystone correction ........................................................................... 10
Volume ................................................................................................ 10
Brightness ............................................................................................ 10
Contrast ............................................................................................... 10
OSD Menu Format and Description.................................... 10
Basic Menu .......................................................................................... 10
Picture Menu at PC Mode .................................................................. 10
Horizontal position (Data only) .......................................................... 11
Vertical position (Data only) .............................................................. 11
Tracking (Data only) ........................................................................... 11
Frequency (Data only) ........................................................................ 11
Picture Menu at Video Mode ............................................................. 11
Tint (Hue) (NTSC Video only) ............................................................. 11
Color (Saturation) (Video only) .......................................................... 11
Video AGC (Video only) ..................................................................... 11
Table of Contents
3
English
Video Type (Video onl y) .................................................................... 11
Digital Zoom & Pan ............................................................................. 12
Format ................................................................................................. 12
Projection Type ................................................................................... 12
Language ............................................................................................ 12
Utilities - 2 Menu................................................................... 12
Utilities - 1 Menu ................................................................. 12
Reset All .............................................................................................. 13
Auto Image.......................................................................................... 13
Color Management ............................................................................. 13
OSD Position ....................................................................................... 13
Auto Source ........................................................................................ 13
Status at PC Mode ............................................................... 14
Status at Video mode .......................................................... 14
Lamp Hours Reset ............................................................... 15
Input source select .............................................................. 15
Auto Image In Progress ...................................................... 16
Lamp Off Control ................................................................. 16
Out of Range ........................................................................ 16
Positioning the Projector .................................................... 17
Preset Timing ....................................................................... 18
Maintenance ......................................................................... 19
Change the Lamp Module ................................................................. 19
Cleaning the Projection Lens ............................................................ 20
Cleaning the Exterior Case ................................................................ 20
Cleaning the Air Filter ........................................................................ 21
Troubleshooting .................................................................. 22
Power Indicator .................................................................................. 22
Image Quality ..................................................................................... 23
Sound .................................................................................................. 24
Remote Control ................................................................................... 25
Lamp .................................................................................................... 25
Safety ................................................................................... 27
Safety Definitions ................................................................................ 27
Projector Safety .................................................................................. 27
Battery Safety ..................................................................................... 28
LCD Projector User Guide
44
44
4
Introduction
The easy-to-use LCD Digital Projector offers superb image quality at an
affordable price. Built into the LCD Digital Projector with Image Manager
feature. With this feature, you can select the image display setting best suited
for your specific presentation material and projection environment.
In only minutes you can have your LCD Digital Projector ready to go. Just
connect the projector to an image source such as a computer, DVD, VCR, or
digital camera.
If you are familiar with connecting and using digital projectors, refer to the
Quick Start Guide included with the projector. If not, follow the directions in
this user guide to connect your projector and run your presentation.
What’s in the Box
Make sure that all of the following components were included with the
projector. Contact your dealer immediately if anything is missing.
• Soft carry case
• Lens cap
• Analog RGB (15 Pin HD) cable
• S-video cable
• Composite video cable
• Stereo audio cable – 1/8” mini-plug
• RCA audio cable to 1/8” mini plug
• USB cable
• Power cord
• User Manual
• Quick Start Guide
• Remote control
• MACINTOSH adapter
5
English
Projector Features
I/O connection
panel
keypad
remote control sensor
focus ring
zoom ring
adjustable feet
foot release button (2)
Projector Features
Remote Instruction
Direction of laser beam
(See CAUTION)
Power
To power on projector or off
projector
Laser
Press the key activate the laser
pointer (See CAUTION)
Keystone
Press to adjust the image
vertically and make a squarer
image.
OSD Menu
Zoom function
Input Source
Press the key for input source
selection
Cursor Key
Enter button of the remote
mouse. (back of remote)
Function is the same as
mouse right key.
Keystone
Press to adjust the image
vertically and make a squarer
image.
Auto
Press to auto adjust picture
quality.
Mute
Volume
Blank
Press to make screen blank.
Freeze
Press to freeze video screen
at the freezed picture.
LED
LCD Projector User Guide
66
66
6
How to use Remote
Install AAA battery x2 into the remote.
Remote mouse function
The flip cover must be closed in order for the mouse function to work.
OSD Menu Funciton
• The flip cover must be open.
• Press “Menu” to enter OSD menu.
• Up/down arrow of the cursor key will be same as / showed in the
OSD menu.
• Left / right arrow of the cursor key will be same as - / + function.
• Exit is same as ↵to exit OSD menu.
Using the Laser Pointer
The LASER button on the Remote activates a laser which emits a red laser
beam from the front of the Remote unit. It is typically used as a pointer during
presentations. The laser beam emits for the duration that you press the
button.
Caution
• Do not stare into laser beam for it can cause harm to your eyes.
• Do not aim the laser at people and procedures other than those specified
therin may result in hazardous radiation exposure.
• If the Remote transmitter malfunctions or causes a malfunction, consult
with a qualified Luxeon Personnel.
This label is located on the
back of the Remote unit
7
English
Connecting the Projector
The cable are color coded to assist you with making the connections. When
you connect the power cable to the projector, the Power LED on the keypad
will be turned on.
You can connect more than one image source at a time as above reference
drawing. Image source can be either automatically selected or you can switch
off “AUTO SOURCE” function of OSD MENU to be manual selection. Manual
selection is operated by pressing “INPUT” key.
If you are using an older MACINTOSH computer, you might need to use the
MACINTOSH adapter that was included with your projector.
Warning: Always turn off the image source (computer or video source) and
projector before connecting or disconnecting cables.
D-SUB 15 pin RGB Cable
Mini-Stereo to Mini-stereo
Audio Cable
USB Cable
Mini-Stereo to RCA Stereo Cable
RCA Video Cable
S-Video to S-Video Cable
Connecting the Projector
Questo manuale è adatto per i seguenti modelli
1
Indice
Altri manuali Luxeon Proiettore
