WOBURN - ACTIVE STEREO LOUDSPEAKER

USER MANUAL

WOBURN

YOU’VE JUST BROUGHT HOME YET ANOTHER UNCOMPROMISING ADDITION

TO MARSHALL’S LEGACY OF LOUD, THE WOBURN. THE MEETING POINT

BETWEEN MODERN TECHNOLOGY AND VINTAGE MARSHALL STYLING, THIS

ACTIVE STEREO LOUDSPEAKER BRINGS MARSHALL’S ICONIC HARD AND

HEAVY SOUND DIRECTLY TO YOUR LIVING ROOM.

BUT, WAIT A MINUTE, BEFORE YOU TURN IT UP, MAKE SURE YOU READ THIS

MANUAL CAREFULLY AND HOLD ON TO IT, ALONG WITH THE INCLUDED

WARRANTY INFORMATION IN CASE YOU EVER NEED IT.

WHEN IT COMES TO SOUND QUALITY, THE WOBURN SPARES NO EXPENSE.

IT’S DESIGNED WITH LOUD IN MIND AND YOU’LL QUICKLY HEAR BY ITS

PERFORMANCE THAT IT HOLDS TRUE TO THE MARSHALL NAME. THIS

LOUDSPEAKER HITS HIGH TREBLES CLEANLY, HANDLES LOW BASS WITH

EASE AND HAS A CLEAR, LIFELIKE MID RANGE. THE ANALOGUE TREBLE,

BASS AND VOLUME KNOBS GIVE YOU CUSTOM CONTROL OF YOUR SOUND.

WITH UNIQUE SOUND DESIGN AND QUALITY COMPONENTS, IT’S MADE TO

DELIVER ACCURATE RESPONSE THROUGHOUT THE FREQUENCY RANGE. THE

WOBURN IS LITERALLY BUILT TO THRILL.

THE WOBURN GIVES YOU THE FREEDOM TO HOOK UP YOUR SMARTPHONE, TAB-

LET OR LAPTOP USING THE 3.5MM AUXILIARY INPUT, CONNECT WIRELESSLY

VIA BLUETOOTH®, PLUG IN YOUR RECORD PLAYER USING THE RCA INPUT,

OR USE THE OPTICAL OUTPUT FOR DEVICES LIKE APPLE TV.

BUT LET’S BE HONEST, LOOKS MATTER, AND WITH IT’S DURABLE VINYL

COVERING, GOLD PIPING, VINTAGE STYLE FRET, AND ICONIC MARSHALL

SCRIPT LOGO, THE WOBURN DOES NOT DISAPPOINT. IT’S CLASSIC DESIGN

ECHOES THE VIBE OF THE GOLDEN YEARS OF ROCK’N’ROLL.

SO, PLUG THIS BEAST IN, CRANK IT UP AND HEAR THE DEFINING SOUND

THAT PUT MARSHALL ON THE MAP

BOX CONTENTS

001. USER MANUAL & WARRANTY INFORMATION

002. DOUBLE-ENDED COIL CORD WITH 3.5MM STEREO PLUGS TO

CONNECT TO YOUR MUSIC PLAYER

003. POWER CORD

004. MARSHALL WOBURN ACTIVE STEREO LOUDSPEAKER

006.

NOTE: OPTICAL AUDIO CABLE AND

RCA CABLE NOT INCLUDED WITH

THE WOBURN AND MUST BE

PURCHASED SEPARATELY.

WOBURN

CAUTION: LIFT ACTIVE

LOUDSPEAKER FROM BOTTOM.

DO NOT LIFT BY PROTECTIVE

BAG FOR RISK OF DROPPING

THE PRODUCT.

GENERAL DESCRIPTION

001. INPUT FOR 3.5MM

STEREO PLUG

002. LED LIGHT SOURCE INDICATOR

003. VOLUME

004. BASS

005. TREBLE

006. PAIR BUTTON

007. SOURCE/WAKE BUTTON

008. POWER SWITCH

009. STANDBY MODE SWITCH

(POWERSAVER MODE AND

STANDARD MODE)

010. RCA INPUT (LEFT & RIGHT)

011. OPTICAL INPUT

012. BACK PLATE

013. BASS PORT

014. POWER JACK

015. POWER CORD

008.

WOBURN

NOTE: DATE CODE

AND SERIAL

NUMBER STICKER

LOCATED HERE.

TURNING THE POWER ON/OFF

001. INSERT THE POWER CORD INTO THE POWER JACK.

002. CONNECT THE CORRECT POWER CORD TO THE WALL SOCKET.

010.

NOTE: DEPENDING ON YOUR

REGION, A POWER CORD WITH AN

APPROPRIATE PLUG IS SUPPLIED.

002.

001. 001. 002.

WOBURN

003. TO TURN THE ACTIVE LOUDSPEAKER ON, SWITCH THE ON/OFF

SWITCH. THE LED LIGHT INDICATOR WILL FLASH RED ON THE

SOURCE MARKED AS BLUETOOTH.

004. TO TURN THE ACTIVE LOUDSPEAKER OFF, SWITCH THE ON/OFF

SWITCH. THE LED INDICATOR WILL TURN OFF.

USING THE WOBURN WITH YOUR DEVICES

THE WOBURN IS A LOUDSPEAKER CREATED FOR TODAY’S WORLD. WITH

MULTIPLE CONNECTION SOURCES, THERE ARE LOADS OF WAYS TO CONNECT

TO YOUR SPEAKER, WHETHER VIA YOUR PHONE, TURNTABLES, TV OR

WIRELESSLY VIA THE LATEST VERSION OF BLUETOOTH®, FEATURING

aptX® TECHNOLOGY. THE ADVANTAGE OF aptX® TECHNOLOGY IS THAT

THE SOUND QUALITY VIA BLUETOOTH IS SIGNIFICANTLY BETTER THAN

A2DP BLUETOOTH. BELOW YOU WILL FIND MORE DETAILS ABOUT THE

CONNECTION SOURCES, IN TWO CATEGORIES:

• WIRELESS CONNECTION VIA BLUETOOTH

• CONNECTION VIA THE 3.5MM, RCA, OR OPTICAL AUDIO CABLE

012.

CAUTION: MAKE SURE THAT

THE VOLUME IS SET TO

LOW ON BOTH THE ACTIVE

LOUDSPEAKER AND THE

MUSIC PLAYER WHEN YOU

START PLAYING MUSIC.

CHOOSING YOUR SOURCE

001. PUSH THE SOURCE/WAKE BUTTON TO CHOOSE YOUR SOURCE AND/OR

TO SWITCH BETWEEN CONNECTED SOURCES.

002. A LIT LED LIGHT INDICATES WHICH SOURCE YOU HAVE SELECTED.

ORDER OF CONNECTIONS (FROM TOP TO BOTTOM):

• BLUETOOTH

• OPTICAL

• INPUT 1 - 3.5MM STERO PLUG

• INPUT 2 - RCA PORTS

002.
