1Q SERIES USER MANUAL
Thank You
Congratulations on the purchase of your new
Matrix loudspea er. Matrix products are the
result of a collaboration between Designers,
Engineers and Musicians with many decades
of experience in the design and practical in
field application of exceptionally robust,
reliable and ergonomic audio equipment.
This manual will help you to get the most
from your loudspea er. For maximum
benefit, it is recommended that all
instructions and warnings are carefully read.
Where unsure about anything, please
consult a qualified technician.
For warranty service, please retain your
receipt and all pac aging that comes with
the loudspea er, as it has been specifically
designed to transport the cabinet safely.
Unpacking
Please unpac and inspect your new
loudspea er for any damage that may have
occurred during transit. If damage is found,
notify the carrier immediately.
PLEASE RETAIN ALL FACTORY PACKAGING
FOR ANY FUTURE POSTAL TRANSIT.
THIS PRODUCT IS CAPABLE OF PRODUCING
SOUND PRESSURE LEVELS WHICH MAY
DAMAGE HEARING. THE USER IS
RESPONSIBLE FOR EXPOSURE LEVELS AND
USE OF HEARING PROTECTION.
CONTENTS:
Page
Thank You 1
AMPLIFIED Cabinet Section :
1. Feature and Specification 2–3
2. Amplifier Feature Overview 4
3. Connecting to a Slave Cabinet 5
PASSIVE Cabinet Section :
4. Feature and Specification 6–7
5. Mono Loud peaker U age 8
6. Stereo Loud peaker U age 9
7. Recommended Amplification 10
8. Warranty 11
9. Declaration of CE Conformity 12
CAUTION:
OBSERVE ALL SAFETY AND USAGE
INSTRUCTIONS TO AVOID POSSIBLE DAMAGE
TO EQUIPMENT AND EXPOSURE TO HAZARDS
(THIS SYMBOL UNIVERSALLY FLAGS CAUTION
NOTICES)
LETHAL VOLTAGES PRESENT AT SPEAKER,
CABLE AND AMPLIFIER TERMINALS; ENSURE
ALL WIRING IS SAFE AND CORRECT BEFORE
USE.
(THIS SYMBOL ALSO UNIVERSALLY FLAGS
ELECTRICAL HAZARDS)
DO NOT OPEN LOUDSPEAKER; LEAVE ALL
INTERNAL SERVICE OPERATIONS TO A
QUALIFIED TECHNICIAN.
REV.1.22 MATRIX AMPLIFICATION
