MaxiCosi Tayla Manuale utente

TaylaTM

Stroller

Max 50 lb (22.67 kg)

Instructions

CV369, TR428

4358-7811 1.8.20

KEEP INSTRUCTIONS FOR FUTURE USE.

Read all instructions before using this stroller.

WARNING Failure to follow the steps and

warnings on the labels and in the instruction

manual can result in serious injury or death to

your child.

Safety Information

WARNINGS

FOR THE SAFETY OF YOUR CHILD, PLEASE READ THE FOLLOWING WARNINGS

AND ASSEMBLY INSTRUCTIONS AND KEEP FOR FUTURE REFERENCE.

• Adult assembly required. CAUTION: Keep small parts away from children during assembly.

• NEVER LEAVE CHILD UNATTENDED. ALWAYS keep child in view when in stroller.

• AVOID SERIOUS INJURY from falling or sliding out. ALWAYS use the harness system.

Check frequently to make sure it is secure.

• ALWAYS keep fingers away from moving parts, when folding, unfolding or adjusting stroller to

prevent finger entrapment.

• ALWAYS make sure stroller is FULLY OPEN AND LOCKED before using.

• ALWAYS use the brakes when stroller is stopped.

• ALWAYS remove protective material and poly bags and dispose before assembly.

• NEVER put hot liquids in the cup holder.

• NEVER use stroller on stairs or escalators.

• NEVER rollerblade with stroller.

• NEVER allow children to play with or hang onto the stroller.

• NEVER allow children to climb into the stroller unassisted. Stroller may tip over and injure

child.

• NEVER place or hang parcels, bags, or accessories on the handle or canopy. The stroller may tip

over or the canopy may collapse.

• This product will become unstable if a parcel bag or rack is used when there is no provision for

one.

• This product may become unstable if a parcel bag, other than the one recommended by the

manufacturer is used.

• This product will become unstable if the manufacturer’s recommended load is exceeded.

• Care must be taken when folding and unfolding the stroller to prevent finger entrapment.

• DO NOT carry additional children, goods, or accessories in or on this product except as

recommended in the manufacturer’s instructions.

• NEVER place more than 1 lb (.5 kg) in cup holder.

• NEVER place more than 25 lb (11.3 kg) in the storage basket. If weight is exceeded, hazardous

unstable conditions may exist.

• STROLLER is only for use with children up to 50 lb (22.67 kg), and WHEN SEATED, the midpoint

of your child’s head is at or below the top of the stroller seat.

• ONLY use this stroller with ONE child at a time.

• STROLLER is for use with children who can sit up unassisted and is NOT recommended for

newborns.

Contents

Parts of Stroller........................................ 1

Installing Wheels...................................... 2

Unfolding Stroller Frame........................... 3

Adjusting Handle ..................................... 4

Using Parking Brake and

Locking Swivel Wheels ............................. 5

Attaching Car Seat to Stroller Frame ......... 6

Removing Car Seat from Stroller Frame..... 7

Attaching Stroller Seat Forward-Facing...... 8

Removing Stroller Seat from Stroller Frame 9

Attaching Stroller Seat Rear-Facing........... 10

Reclining Stroller Seat .............................. 11

Adjusting Canopy and Footrest.................. 12

Privacy Shade and Storage Basket Use...... 13

Adjusting Stroller Seat Harness Straps....... 14

Securing Child in Stroller Seat................... 16

Folding Stroller ........................................ 17

Removing and Installing Stroller Seat Pad.. 18

Accessories............................................. 21

Wash and Care........................................ 22

Dorel Juvenile Group Information .............. 23

Replacement Parts................................... 23

Warranty ................................................. 23

Parts of Stroller 1

Lay out and identify all of the

parts.

If any parts are missing, do not

return this product to the

place of purchase.

Please contact Consumer Care

via:

• Phone: 1-800-951-4113

• Text: 1-812-652-2525

• Chat: www.maxi-cosi.com

You will need to know the model

number and manufacture date.

It is located on a label on the

stroller frame.

Stroller

Frame

Stroller

Seat

Harness

Straps

Harness

Covers

Canopy

with Privacy

Shield

Rain

Shield

Bumper

Bar

Seat

Receivers

Car Seat

Adapters

Rear

Wheels

Front Swivel

Wheels

Cup

Holder

Attachment

Cup

Holder

Buckle

Installing Wheels

Attach the front

swivel wheels.

Attach the rear wheels. Finished!

Note: Pull out on the

wheels to make sure they

are secured.

Rear Wheels

Front Swivel

Wheels

1 2

click!

Unfolding Stroller Frame 3

• Slide the stroller frame release button to either

the left or right.

• Then squeeze the handle adjustment button.

• Hold them together.

Place your foot on the storage basket frame. • Push your foot down to

start unfolding.

• Then release the buttons.

• Continue to push down

until the stroller locks into

place.

Finished!

Release Buttons

Adjusting Handle

This stroller’s handle is adjustable and has 5 positions: 4 strolling heights and 1 storage.

Adjust to a position that is comfortable for you.

Squeeze the handle

adjustment button and

hold it in.

Lift or lower the handle

to your desired position.

DO NOT use with the

handle in the storage position.

This is when the handle all the

way down.

Handle Height Adjustment Button

Using Parking Brake and Locking Swivel Wheels 5

To Lock Parking Brake

To Lock Swivel Wheels

To Release Parking Brake

To Release Swivel Wheels

Rear Wheels

Front Swivel Wheels

click!

• The wheels must face forward

as shown.

• Firmly push th lock down tabs

with both of your thumbs.

• Locked swivel wheels are

best for traveling over rocky

or uneven surfaces.

• Firmly pull the lock tabs

up with both of your index

ﬁngers.

• Unlocked swivel wheels

are best for everyday

strolling.

Attaching Car Seat to Stroller Frame

The car seat shown is a generic icon used for reference and may not look like your car seat.

Attach the car seat adpaters to

the seat receivers.

Attach the seat receivers with a blue dot to

the stroller frame ﬁxture with a blue dot. Then

attach the receiver with a red dot to the ﬁxture

with a red dot.

Attach the car seat to the car seat adapter.

ONLY install the car seat rear-facing.

Pull up on the car seat

either at the carry handle

or handle hubs to check if

it is securely installed.

Seat Receivers Car Seat Adapters

click!
