Maxtor DVMR Manuale utente
VER1.3
8Channel Stand-alone DVMR
1
INSTALLATION & SAFEGUARDS
All the safety and operating instructions should be read before the unit is operated.
Environment Condition for Installation
- To prevent electric shock or other hazard, do not expose units to rain, moisture, or dust.
- This unit should be located in an area with low humidity and a minimum of dust..
- Place this unit in a well-ventilated place and do not place heat-generating objects on this unit.
- This unit should not be located in an area where it is likely to be subjected to mechanical shocks.
Before You Start
- Ensure the power switch is in the OFF position prior to starting.
- Do not attempt to service this unit yourself as opening or removing covers may expose you to
dangerous voltage or other hazards.
- Installation should be performed by qualified service personnel only.
- This unit should be operated only from the type of power source indicated on the manufacturer’s
label and with the power supply included with the unit.
Notice
- Be aware thoroughly about the power connection before installation of the unit.
- Before initial configuration or operation you must first set the TIME/DATE, followed by setting
the unit to the FACTORY DEFAULT settings, lastly clearing the HDD. Please follow these
steps in order.
- Before installing a second HDD, ensure that the drive conforms to the specifications listed on
the specifications page at the end of this manual. When installing a second HDD, set the drive
to SLAVE. After installation, first reset the TIME/DATE, followed by resetting the unit to the
FACTORY DEFAULT settings, lastly clearing the new HDD.
- Pull the unit out of record mode prior to cutting power to the unit. Do this by entering the setup
menu, followed by switching the unit off. Powering off the unit while writing to the disks can
cause critical malfunctions. (ex: Recording Error, Playback Error, System Error)
- When you set the record type, you have to set the Record Configuration and also Schedule
Setup. This unit records as per the Record type & Schedule setup.
- The [REC] button on the front panel is for emergency record using highest image quality.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the
user of this equipment that there are dangerous voltages within the enclosure which may be of
sufficient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to presence of
important operating and maintenance(Servicing) instructions in the literature accompanying the
appliance.
Installation & Safeguards
2
Contents
Contents
17----------------------------------------------------------------Playback4-6.
17----------------------------------------------------------------Record4-5.
16----------------------------------------------------------------Zoom View5)
16----------------------------------------------------------------Freeze View4)
15----------------------------------------------------------------Display Configuration4-3.
14----------------------------------------------------------------Factory Default4-2.
14----------------------------------------------------------------System Log-in4-1.
16----------------------------------------------------------------PIP View3)
16----------------------------------------------------------------Sequencing Cameras2)
15----------------------------------------------------------------Full / Multiple View1)
15----------------------------------------------------------------Live View Setup4-4.
18----------------------------------------------------------------Search4-7.
14----------------------------------------------------------------OperationCHAP. 4
13----------------------------------------------------------------RS-232C ASCII-code9)
13----------------------------------------------------------------Connector Pin Assignment8)
12----------------------------------------------------------------Other External Device7)
12----------------------------------------------------------------VCR, Video Printer6)
11----------------------------------------------------------------Power5)
11----------------------------------------------------------------Monitor4)
11----------------------------------------------------------------Camera3)
10----------------------------------------------------------------HDD(Hard Disk Drive)2)
10----------------------------------------------------------------Rack Mount1)
10----------------------------------------------------------------Detailed Installation3-2.
9----------------------------------------------------------------Installation Configuration3-1.
9----------------------------------------------------------------InstallationCHAP. 3
8----------------------------------------------------------------Rear2-2.
6----------------------------------------------------------------Front2-1.
6----------------------------------------------------------------Function of Each ButtonCHAP. 2
5----------------------------------------------------------------Package Contents1-2.
4----------------------------------------------------------------Features1-1.
4----------------------------------------------------------------Features & Package ContentsCHAP. 1
3
Contents
26----------------------------------------------------------------System Information8.
43----------------------------------------------------------------SpecificationsCHAP. 7
36
41
----------------------------------------------------------------
----------------------------------------------------------------
Remote Viewer Program
Back-Up CD Player
6-2.
6-3.
32----------------------------------------------------------------DVR Network Configuration6-1.
30----------------------------------------------------------------RS-232C Setup2.
30----------------------------------------------------------------TCP/IP Setup1.
29----------------------------------------------------------------External Device5-6.
29----------------------------------------------------------------Back-Up5-5.
32----------------------------------------------------------------Network SetupCHAP. 6
31----------------------------------------------------------------Language Setup5-8.
31----------------------------------------------------------------FACTORY Default5-7.
30----------------------------------------------------------------Pan Tilt Zoom Setup3.
28----------------------------------------------------------------Holiday Setup3.
28----------------------------------------------------------------Schedule Setup2.
27----------------------------------------------------------------Record Configuration1.
27----------------------------------------------------------------Record Setup5-4.
26----------------------------------------------------------------Password Setup7.
26----------------------------------------------------------------Buzzer Setup6.
25----------------------------------------------------------------Alarm Setup5.
25----------------------------------------------------------------Interval Setup4.
23----------------------------------------------------------------Camera Setup3.
23----------------------------------------------------------------TIME/DATE Setup2.
22----------------------------------------------------------------HDD Management1.
22----------------------------------------------------------------Configuration5-3.
21----------------------------------------------------------------Monitor Setup2)
21----------------------------------------------------------------Screen Display1)
21----------------------------------------------------------------Display Setup5-2.
20----------------------------------------------------------------Entering the Menu5-1.
20----------------------------------------------------------------Set UpCHAP. 5
19----------------------------------------------------------------Data Back-Up4-9.
19----------------------------------------------------------------PTZ Camera Operation4-8.
4
Live View
Real time display per camera
Auto Sequence
PIP (Picture in picture)
Digital Zoom
Display Freeze
Simple Playback mode
Simple PTZ camera control
Record
Variable Record resolution (For higher picture quality or higher recording speed)
Efficient Image Quality setup in 5 steps
Schedule Record / Holiday Record
Event Record (Alarm / Motion)
Emergency Record
Network
View Live and Playback images across IP network
Copy images across the network
Playback
Search & Playback by Date/Time, Event and Camera
Outstanding picture quality by JPEG 2000 compression algorithm (No mosaic effect)
Suitable for recording not only images but also text
Various steps in Forward Playback Speed (X1/16, X1/8, X1/4, X1/2, X2, X4, X16, X32, X64)
Various steps in Backward Playback Speed (X1/16, X1/8, X1/4, X1/2, X2, X4, X16, X32, X64)
Easy and convenient search by Jog Shuttle & Remote Controller
Data Back-Up
Simple Back-Up using built-in CD Writer (Back-up CD Player included in the package)
Network Back-Up using Remote Viewer program(Remote Viewer included in the package)
Supports bigger capacity of HDD (300GB or bigger)
Others
Multi-Language (English, Spanish, Portuguese, German, French, Italy, Japan, China)
VGA option board supports both TFT LCD monitor and CRT monitor
Lock the system by Password
JOG / SHUTTLE
PAL/NTSC Auto detection
Control the unit by using Remote Controller
CHAP. 1 Features & Package Contents
CHAP. 1 Features & Package Contents
1-1. Features
5
CHAP. 1 Features & Package Contents
1-2. Package Contents
1. DVR Main Unit 2. Remote Controller
3. Power Cable
4. Power Adapter 5. User’s Manual 6. Software CD
7. Rubber Pad 8. HDD absorber 9. Battery for remote controller 10. Bolts
Rack mount bracket
For fixing DVR with Rack Mount bracket to 19” Rack (4ea)
For fixing Hard Disk Drive into DVR (8ea)
For fixing Rack Mount bracket to DVR (6ea)
10. Rack mount
bracket / Bolts
Battery for remote controller9. Battery
Absorbing the mechanical shock of HDD against the case bottom8. HDD absorber
Prevent DVR from slipping. Attach it to the bottom of main unit7. Rubber Pad
Remote Viewer Software & Back up CD player6. Software CD
User’s Manual5. User’s Manual
12 V DC power supply4. Power Adapter
AC power supply to adapters for 12 V DC power3. Power Cable
DVR control2. Remote Controller
STAND-ALONE DIGITAL VIDEO RECORDER1. DVR Main Unit
DescriptionPackage Contents
6
Reduce or increase the option value in the menu
Navigate in the menu
Move to next step
Selects each menu option
Set up for SYSTEM MENU or Use to exit the menu
Press MENU button before powering off the unit.
Search recorded data on HDD
Playback of recorded data on HDD
Stop of Emergency Record and return to Schedule Record
from Emergency Record. Playback stop.
Emergency Record at continuous, 120ips, SUPER FINE size
• F4 : USER 4
• F3 : USER 3
• F2 : USER 2
• F1 : USER 1
• AUTO : AUTO SCAN
• GOTO : GOTO PRESET
• CLEAR : CLEAR PRESET
• SET : SET PRESET
ENTER
MENU⑥SETUP
SEARCH
PLAY
+ -
▲▼◀▶
NEXT
STOP
REC⑤Record /
Playback
• TELE : ZOOM OUT
• WIDE : ZOOM IN
• FAR : FOCUS FAR
• NEAR : FOCUS NEAR
• CLOSE: IRIS CLOSE
• OPEN : IRIS OPEN
• OFF : LIGHT OFF
• ON : LIGHT ON
2. Control PTZ camera (Each button is assigned for each PTZ command)
1. Pressing this button will display a full screen image of that camera④Camera
selection
&
PTZ camera
control
IR receiver③IR
Firmware upgrade by connecting PC with latest firmware to USB port②USB Device
Shows status of operation①LED Lamps
FunctionName
CHAP. 2 Function of Each Button
2-1 FRONT
CHAP. 2 Function of Each Button
7
⑩CD-RW
⑨Jog Shuttle
⑧Jog Shuttle
Control
Very easy and convenient search : Press J/Shuttle button, and images in
playback pause, and then Jog and Shuttle makes it very easy and convenient
to search, forward or backward, fast and slow, as user want.
ACTIVE LED on : When J/Shuttle button is pressed
RUN LED on : While you operate Jog or Shuttle
Pressing Jog Shuttle button (Ready for use Jog/Shuttle)
: In playback mode, pressing J/SHUTTLE button make
images frozen.
Play from image recorded 2 minutes ago in forward
direction. (in case recorded in continuous mode).
Lock the key function.
To unlock, press longer time (for several seconds) and then
input the password.
Auto camera image sequencing in full screen mode
Display in PIP (Picture in Picture) mode
Switch to split display
MODE button changes screen-division from (to) full screen
to (from) 8 split screen.
Freezing an image
Zooming an image
On/Off for PAN/TILT/ZOOM control mode
Press this button first to control PTZ camera connected to
DVR unit via RS-485
Data Back-up and Firmware Upgrade using built-in CD writer
J/SHUTTLE
Q. Play
(Quick Play)
K.LOCK
SEQ
PIP
MODE
FRZ
ZOOM
PTZ⑦LIVE View
Control
FunctionName
CHAP. 2 Function of Each Button
8
10
9
8
7
6
5
4
3
2
1
MONITOR
Output
LOOP Output
CAMERA Input
RS-232C
ETHERNET
VGA
SENSOR Input
Connection with PTZ Camera or other external device using RS 485
interface
RS 485
POWER
SWITCH
DC Power
VCR Output
Power ON/OFF switch for adapters
To avoid accidental deletion of HDD data, please make sure to press
MENU button before powering off the unit.
This takes the unit out of record mode for safe shutdown.
DC 12V 8.3 A Adaptor (Refer to the Instruction for adapter by HDDs
capacity)
Connection with VCR for analog backup
Connection with Composite Monitor
Camera loop out
Connection with camera
Connection to external device as PC using RS-232C to control the DVR
Connection to ETHERNET device
Connection to VGA Monitor (CRT type or TFT LCD monitor)
Just in case you purchased DVR with VGA option board fixed on the main
board of DVR, you can connect VGA Monitor to DVR unit.
Sensor input terminal
Relay out terminalRELAY Output
FunctionName
CHAP. 2 Function of Each Button
2-2. REAR
9
3-1. Installation Configuration
CHAP. 3 Installation
CHAP.3 Installation
Indice
Altri manuali Maxtor Registratore digitale
Maxtor
Maxtor CDR-04S Manuale utente
Maxtor
Maxtor 4 Channel Stand-alone DVMR Manuale utente
Maxtor
Maxtor Standalone DVR 2007 Manuale utente
Maxtor
Maxtor 4 CH Digital Multiplex Recorder Manuale utente
Maxtor
Maxtor Built in Digital Video Recorder Manuale utente
Maxtor
Maxtor 4 CH Digital Multiplex Recorder Manuale utente
Maxtor
Maxtor 4-Channel DVR (Digital Video Recorder) Manuale utente
Maxtor
Maxtor 4Channel Stand-alone DVMR Manuale utente
Maxtor
Maxtor SSA-0412 Manuale utente
Maxtor
Maxtor 773W V1.0 Manuale utente
