CABINET PARTS

5−08 Litho In U.S.A. (pl)(bay) Part No. W10206697 Rev.A

REFRIGERATOR

For Models: MFD2562VEA10, MFD2562VEB10, MFD2562VEM10, MFD2562VEW10

(Monochromatic Satina) (Black) (Monochromatic Stainless) (White)

CABINET PARTS

2W10206697

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 Literature Parts

W10198858

Tech Sheet

W10175446

Owners Manual

W10187813

Tag, Energy

W10137519

Elbow, Fill Tube

3 67003405 Block, Pivot

4 B5759649 Gasket

5 67005955 Hinge, Top Right

6 A3076901 Plug, Button

7 67006118 Roller Assy. (2)

8 67006287 Screw

9 67006521 Screw

10 M0108105 Clamp, Tube

11 67006380 Screw (6)

12 67006611 Bolt, Adjusting

(Front)

13 Cover, Left Hinge

67005953 White

67005951 Black

W10191116

Apollo Grey

14 67006303 Screw (6)

15 Hinge, Center (RT)

67006379 White

67006443 Black

W10191143

Apollo Grey

16 67004092 Block, Filter (2)

17 Cover, Corner

67003484 White

67003485 Black

W10191102

Apollo Grey

W10199045

Hinge, Top Left

W10208641

Bracket, Foot (2)

20 67006564 Screw

21 Shim, Hinge

67006308 Left

67006309 Right

22 Grille, Toe

67006377 White

67006375 Black

W10191107

Apollo Grey

W10157973

Clip, Drain Tube

24 Hinge, Center (LT)

67006277 White

67006275 Black

W10191142

Apollo Grey

25 67006425 Screw (10)

26 67003331 Cover, Water Line

27 67004098 Cover, Water Valve

28 67006669 Screw (2)

29 67004101 Sweep, Dual Tube

30 67006102 Cover, Unit

W10164397

Tube, Drain

32 M0114003 Clip, Speed

33 67003796 Insulation, Sound

34 67003868 Foot Brake

35 Cover, Right Hinge

67005958 White

67005956 Black

W10191117

Apollo Grey

36 Cabinet (Not a

Servicable Part)

For Models: MFD2562VEA10, MFD2562VEB10, MFD2562VEM10, MFD2562VEW10

(Monochromatic Satina) (Black) (Monochromatic Stainless) (White)

FREEZER LINER PARTS

For Models: MFD2562VEA10, MFD2562VEB10, MFD2562VEM10, MFD2562VEW10

(Monochromatic Satina) (Black) (Monochromatic Stainless) (White)

W10206697

FREEZER LINER PARTS

4W10206697

Illus. Part

No. No. DESCRIPTION

1 Liner (Not A

Seviceable Part)

2 67001291 Gasket, Foam

3 12002497 Gear

(Includes LH & RH)

4 67003905 Cover, Light

5 67004017 Shaft

Y12570701

Socket, Light

7 67005874 Guide, Fill Tube

8 67006473 Screw (8)

9 A0282812 Bulb, Light

10 67001035 Housing, Light

11 67005873 Cover, Evaporator

12 67006425 Screw (4)

13 Bracket, Door

W10122147

Left

W10122148

Right

14 67003906 Module, Light

W10208602

Clip, Evap Motor

16 67005653 Switch, Light

17 67006287 Screw (2)

18 Cradle, Basket

W10187668

Left

W10187667

Right

W10120018

Slide, Drawer (2)

20 67002492 Gasket, Bottom

21 Adapter, Slide

W10149390

Left

W10149391

Right

W10175909

Grille, Fz Air

W10167023

Shroud, Evap Fan

24 2169142 Blade, Fan

(Evaporator)

W10150583

Grommet

W10199049

Motor, Evaporator

27 D7753903 Funnel, Drain

28 M0500703 Seal

29 B8381501 Gasket

30 12002355 Thermistor

31 67003924 Cover, Thermistor

32 67006406 Screw (6)

33 67006530 Screw

W10157765

Diverter, Air

35 Rail, Side

W10146443

Left

W10146444

Right

Following Parts Not Illustrated

67006095 Harness, Fz Module

For Models: MFD2562VEA10, MFD2562VEB10, MFD2562VEM10, MFD2562VEW10

(Monochromatic Satina) (Black) (Monochromatic Stainless) (White)

REFRIGERATOR LINER PARTS

W10206697

For Models: MFD2562VEA10, MFD2562VEB10, MFD2562VEM10, MFD2562VEW10

(Monochromatic Satina) (Black) (Monochromatic Stainless) (White)

REFRIGERATOR LINER PARTS

6W10206697

Illus. Part

No. No. DESCRIPTION

1 Liner (Not A

Serviceable Part)

2 67004078 Bracket, Control

and Lights

W10175935

Keyboard

W10185585

Housing, Control

W10207861

Board, Control

6 C3680310 Switch, Light (2)

7 67003897 Cover, Light

8 67003901 Housing, Light

9 A0282812 Bulb, Light (2)

Y12570701

Socket, Light (2)

11 67003900 Insert,

Damper Cover

12 67006602 Screw (2)

13 67003899 Cover, Damper

14 67006604 Insulation

W10127429

Control, Damper

(Incl. Harness)

16 12002355 Thermistor

17 67001668 Plate

18 67006524 Head, Filter

UKF8001AXX

Filter, Water

20 12568001 Cover, Filter

21 67006287 Screw (2)

22 B8390302 Clip, Facade (2)

W10158503

Facade, Dispenser

24 67002742 Plate, Switch

25 12575501 Switch, Limit

26 67003728 Guide, Waterline

27 67002816 Clip, Waterline

28 67005674 Facade (Top)

W10153959

Tank, Water

30 61006182 Union

31 12664501 Plug, Bypass

32 67006400 Screw (2)

W10117358

Insulation, Tank

W10130483

Gasket

Following Parts Not Illustrated

67005417 Harness, Control

(Refrigerator)

For Models: MFD2562VEA10, MFD2562VEB10, MFD2562VEM10, MFD2562VEW10

(Monochromatic Satina) (Black) (Monochromatic Stainless) (White)

REFRIGERATOR DOOR PARTS

W10206697

For Models: MFD2562VEA10, MFD2562VEB10, MFD2562VEM10, MFD2562VEW10

(Monochromatic Satina) (Black) (Monochromatic Stainless) (White)

REFRIGERATOR DOOR PARTS

For Models: MFD2562VEA10, MFD2562VEB10, MFD2562VEM10, MFD2562VEW10

(Monochromatic Satina) (Black) (Monochromatic Stainless) (White)

W10206697

Illus. Part

No. No. DESCRIPTION

1 Door, Left

W10199095

White

W10199872

Black

W10199863

Stainless

W10199868

Satina

2 Door, Right

W10199092

White

W10200711

Black

W10199865

Stainless

W10199871

Satina

3 67003637 Door, Dairy

4 67001279 Tray, Dairy

5 67004748 Bin, Shelf (3)

(Medium)

6 Mullion, Door

67003263 White

67003264 Black

W10199882

Apollo Grey

7 67006786 Screw

8 Gasket, Door (2)

W10163894

White

12723206B

Black

W10179332

Apollo Grey

9 Handle, Door

67006114 White

67006115 Black

W10191144

Antique Pewter

W10136871

Stainless

10 67006287 Screw

11 Stop, Door

12968202W

White

67007011 Black

W10191119

Apollo Grey

12 67006439 Nameplate

13 67006113 Mount, Handle

14 67002935 Screw

15 Closure, Door

67003638 White

67003639 Black

W10191100

Apollo Grey

16 67004749 Bin, Shelf (2)

(Gallon)

UNIT PARTS

For Models: MFD2562VEA10, MFD2562VEB10, MFD2562VEM10, MFD2562VEW10

(Monochromatic Satina) (Black) (Monochromatic Stainless) (White)

W10206697

UNIT PARTS

For Models: MFD2562VEA10, MFD2562VEB10, MFD2562VEM10, MFD2562VEW10

(Monochromatic Satina) (Black) (Monochromatic Stainless) (White)

W10206697

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 67006433 Screw

W10162928

Blade, Fan

3 67005889 Basepan

4 67006425 Screw (2)

5 67004954 Screw (3)

W10134623

Compressor

(Incudes items

11,12,17,27, &

30)

W10171661

Harness, Evap

Heater

8 67007175 Pan, Drain

9 61004743 Grommet (3)

10 67002493 Heater, Defrost

11 2264017 Capacitor

W10128791

Start Device

13 61003210 Gasket

W10165425

Thermostat, Def.

15 67005680 Grommet (2)

W10158508

Shroud

17 2255199 Clip, Capacitor

18 67006131 Condenser

W10134293

Tube, Discharge

20 67002490 Tray, Drip

21 10623002 Clip, Evaporator

22 12002041 Evaporator Kit

(Inc. Evap., Heat

Shield, & Instr.

Sheet)

23 Dam

67001084 Right Side

67001083 Left Side

24 67004432 Motor, Fan

25 10428101 Clip, Heater

26 13060202 Harness, MC

27 2317845 Drier

28 10547003 Clip, Drier

29 67004953 Bracket, Fan Motor

W10169124

Grommet (4)

31 67006432 Screw (3)

32 67006573 Screw (4)

33 67005421 Cover, HV Box

W10205114

Board, HV Control

(Inc. Inst. Sheet)

35 67005719 Spacer, HV Box

36 67005718 Box, HV

37 67006550 Screw (2)

38 12972902 Harness, HV

39 67006615 Screw, Cover

40 67005149 Roller (2)

41 67006434 Axle (2)

W10137529

Grommet (4)

43 67005491 Block, Condenser

44 67006737 Screw

Following Parts Not Illustrated

and Optional Parts Not Included

978025 Valve, Access

(1/4")

978026 Valve, Access

(5/16")

978027 Valve, Access

(3/8")

978028 Valve, Access

(1/2")

978029 Valve, Access

(5/8")

978030 Valve, Access

(3/4")

876764 Valve, Access

(3/16")

REFRIGERANT CHARGE

5.25 Ozs.

(R−134A)
