1 - Introduction

This manual identifies some of the most frequent system breakdowns of the series 800 treadmills

and describes the diagnostic procedures in order to eliminate breakdowns and return the system to

its correct functioning.

It refers principally to the troubleshooting of the 800 series.

WARNING:

Before resolving any treadmill breakdowns one must check that the connector located at the base

of the right handle has been correctly screwed in during the installation phase.

The incorrect closure of the connector’s ring nut could cause contact with some pins and not with

others. This could create breakdown symptoms as described below.

Service Manual 800 series Rev. 1/01.07.2019

2 - System breakdowns and diagnostic procedures

WARNING:

Before undertaking any maintenance procedure, the service technicians must take the following

precautions:

1) Use tools with insulated handles

2) Wear personal protective clothing and equipment, such as insulated gloves and shoes,

3) Switch off the equipment (ON/OFF switch to "0") and remove the plug from the outlet.

The following table lists the most frequent system breakdowns and associates the symptoms with

various diagnostic procedures.

Symptom

Diagnostic Procedure

Par

The treadmill does not raise or fall

Diagnosis of the inclination subsystem

The treadmill does not rotate (does not move)

Diagnosis of the velocity subsystem

The treadmill does not turn on

(the belt does not elevate and it does not rotate)

Diagnosis of the power subsystem

The treadmill is not regularly sliding

Diagnosis of the sliding subsystem

3 - Diagnosis of inclination subsystem

This procedure, whose flow chart is described in the next paragraph, takes into consideration the

possible causes of the inclination subsystem’s breakdown starting from the most probable and

listing descending order those with least probability.

Possible breakdown factors:

1. Transmission of the command from the PC to the treadmill

2. Fuse on filter board and control board

3. End run micro-switches

4. Power board

5. Elevation motor

Service Manual 800 series Rev. 1/01.07.2019

not OK

Not OK

not OK

Not OK

not OK

3.1 - Flow chart for the diagnosis of inclination subsystem

3.5 Substitution RS 232

cable

Stop

Start

3.2 Transmission

check

3.3 Connection check

Stop

3.4 RS 232 cable check

3.6 Inclination check

3.9 Control board

imput check

3.10 Filter board and

control board fuse check

3.12 Test of the limit

switch

Send the treadmill to

the manufacturer

3.8 Removal of the hood

3.7 Treadmill check

Stop

3.11 Test control board

and elevation motor

elevaz.

3.13 Test of 0% limit

switch

3.14 Substitution of the

control board

3.15 Substitution of the

elevation motor

Service Manual 800 series Rev. 1/01.07.2019

3.2 - Transmission check

The trial consists in verifying whether the command (of elevation or of rotation) correctly reaches

the treadmill. It requires the use of software installed on a personal computer in order to send the

command to the treadmill.

If the transmission of the command does not work, the software should show an error message.

Consequently, if the error message shows on the PC, it means that the transmission check is not

OK. Should this not occur, the transmission check should be considered OK.

Note: Unfortunately not all software on all PC’s have the possibility of determining whether the

command reached the treadmill in the correct manner, and therefore in these cases, one should

consider the check not OK, even in the absence of error messages.

3.3 - Connection check

With this check one must verify whether the connectors of the RS232 cable are properly inserted in

the ports of the PC and of the treadmill. It requires the manual verification of the positioning of the

connectors and possible reinsertion of them.

After this verification, one must send a new command (of elevation or of rotation) to the treadmill

and verify if the treadmill responds accordingly or not. If the treadmill correctly executes the

command it means that the connection check is OK, otherwise not OK.

3.4 - RS232 cable check

This check consists of the verification that the connection cable RS232 between the PC and the

treadmill is intact. It requires a visual trial, checking that the cable has not undergone damage and

that it is immune from cuts, tears, or crushing.

If the cable appears in a good state the check of the cable RS232 is OK, otherwise not OK.

3.5 - Substitution of RS232 cable

Essential tools:

•Screwdriver

Essential replacement parts:

•RS232 serial cable

This very simple procedure requires removal of the RS232 cable disconnecting the cable from the

ports and then substituting it with a new cable.

Service Manual 800 series Rev. 1/01.07.2019

3.6 - Inclination check

In order to execute the elevation check it is obviously necessary that the treadmill is under tension

and should the hood be open, it is necessary to act very carefully. To apply tension, with the cover

open, the following operations must be executed, in order:

1) block the security contact in the closet position(Fig.1)

2) connect the power plug

3) main switch to the ON position

WARNING:

At this moment, the machine is under tension and you are advised to act very carefully in order to

avoid accidental contact with the parts under tension.

The elevation check can be performed utilizing the software from the PC in order to send an

elevation command to the treadmill. If the treadmill elevates itself in the proper way after the

command is given, the elevation check is considered OK; otherwise not OK.

After the execution of the check and given that one must still work on the treadmill with the cover

open, it is recommended to remove the tension following these steps:

1) Switch OFF the treadmill

2) Unplug the power plug

3.7 - Treadmill check

Essential tools:

•RAM Serial Tester

This check is executed utilizing an instrument called a “RAM Serial Tester” (CERST), which is

able to send elevation and rotation commands to the treadmill.

The objective of this check is to verify the behaviour of the treadmill in reaction to commands

received from the “Serial Tester”.

If the treadmill exhibits the correct behaviour, one must hypothesize that the cause of the

malfunctioning is external and must be researched on the PC software that prepares the structure of

the commands, or on the system which transmits commands.

When the serial tester receives power, the display shows the velocity and inclination information.

The instrument has four buttons with the following functions:

START/STOP: activates and deactivates the treadmill

VEL/INC : moves the cursor on the display and allows the selection of velocity or inclination

UP () : increases by 0.5 the velocity or inclination

DOWN () : decreases by 0.5 the velocity or inclination

The “Serial tester” device is also provided with an RS232 plug for the connection to the treadmill.

When one presses the Start/Stop, Up or Down buttons, the serial tester sends the corresponding

command to the treadmill.

Service Manual 800 series Rev. 1/01.07.2019

The reception of the command by the treadmill is signalled by a change in the symbol on the lower

right hand part of the display, that goes from > (greater) to < (lesser) or vice versa.

The check is executed by disconnecting the PC connector from the RS232 port and connecting the

serial tester. Once the serial tester and the treadmill are turned on, it is possible to utilize the various

buttons of the serial tester to send commands to the treadmill, thereby observing its behaviour.

If the treadmill acts correctly based on the commands received, the check is considered OK;

otherwise not OK.

3.8 - Removal of hood

Necessary tools:

•Philips screwdriver

•Screwdriver

In order to remove the motor hood cover, the following steps must be taken, in the order indicated:

1) Switch OFF the treadmill by main switch

2) unplug the power plug

3) unscrew the screws of the RS232 connector on the hood and remove the connector

4) remove the hood by unscrewing the four screws found at its base

5) re-insert the connector in the serial port RS232 on the motor box

Should the hood come off prior to having executed operations 1) and 2), a security switch will

interrupt the power to the treadmill. The main switch will remain under tension and the warning

light will remain on to signal the operator that it’s necessary to follow the operations listed above in

1) and 2).

3.9 –Control board input check

Tools needed:

•5,5 mm wrench

•hook or elastic restraint safety switch

Remove the protective cover of the control board placed under the engine of elevation with 5,5mm

wrench.

Attach the hook to the safety restraint (Fig.1-4), switch ON the treadmill by main switch and verify

visually that the light-emitting diodes DL1, DL2 and DL3 on the control board are lit (Fig.2-3).

If these diodes are lit, the test is OK, otherwise it is not OK.

Altri manuali per 800 Series

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Medisoft Tapis roulant

Medisoft

Medisoft 870 A Manuale utente

Medisoft

Medisoft 800 Series Manuale utente

Manuali Tapis roulant popolari di altre marche

Treadly

Treadly TREADLY 2 Manuale utente

HEALTH ONE

HEALTH ONE Walk Ro Manuale utente

NordicTrack

NordicTrack NTL12941 Manuale utente

NordicTrack

NordicTrack T7.5 S Manuale utente

Gold's Gym

Gold's Gym ADVANTAGE GGTL12920 Manuale utente

Merax

Merax MS282992 Manuale utente

FYTTER

FYTTER RU-2SX Manuale utente

Precor

Precor 903 Manuale utente

FitLogic

FitLogic freewill d225 Manuale utente

HOP-SPORT

HOP-SPORT ESTIMA HS-3200LB Manuale utente

Horizon Fitness

Horizon Fitness Adventure 5 Plus Manuale utente

Stamia

Stamia InMotion II Manuale utente

Smooth Fitness

Smooth Fitness EVO 3i Manuale utente

NordicTrack

NordicTrack NETL81810.0 Manuale utente

Schwinn

Schwinn 830/Journey 8.0 Manuale utente

Keys Fitness

Keys Fitness HealthTrainer HT-740T Manuale utente

Spirit

Spirit XT8 Manuale utente

NordicTrack

NordicTrack T 14.0 Treadmill Manuale utente
