Medisoft 870 A Manuale utente

Treadmillmod.870A,870S, 870C

USER’S MANUAL

This Manual should be carefully read in all of its parts, before starting to

operate the treadmill

REV. 1/01.07.2019

This manual has been carefully written and checked.

Nevertheless no responsibility is assumed for

possible inaccuracies.

document may be reproduced or transmitted in any

form or by any means without the written permission

of Medisoft RAM Italia S.r.l.

The Medisoft RAM Italia S.r.l. company is committed

to a policy of constant improvement in compliance to

Norm ISO EN 9001:2001 requirements, and as a

function of feedback from customers and the market

in compliance to norm ISO EN 13485:2004. As a

consequence, the company reserves the right to

make changes to this document and to the products

described herein without notice.

Validity date : 11.04.2018

© Medisoft RAM Italia S.r.l.. All rights reserved.

TABLE OF CONTENTS

Treadmill Mod. 870 A, 870 S and 870 C



1Introduction to the Equipment..........................................................................................................4
1.1 ABOUT THIS MANUAL ...........................................................................................................4
1.2 INTENDED USE......................................................................................................................4
1.3 PRECAUTIONS........................................................................................................................5
1.4 MANUFACTURER LIABILITY RESTRICTIONS. ....................................................................5
1.5 SAFETY REGULATIONS........................................................................................................6
1.6 ELECTROMAGNETIC COMPATIBILITY ................................................................................8
1.7 IDENTIFICATION PLATES ..................................................................................................11
1.8 SAFETY PLATE.....................................................................................................................12
1.9 MAIN PARTS IDENTIFICATION ...........................................................................................13
2Packing, transport, storage and delivery........................................................................................16
2.1 PACKING...............................................................................................................................16
2.2 TRANSPORT.........................................................................................................................16
2.3 STORAGE .............................................................................................................................16
2.4 DELIVERY AND CLAIMS......................................................................................................17
3Installation......................................................................................................................................18
3.1 INSPECTION ........................................................................................................................18
3.2 CONFIGURATION.................................................................................................................18
3.3 MOUNTING ...........................................................................................................................19
3.4 MOVING.................................................................................................................................22
3.5 PRECAUTIONS.....................................................................................................................22
3.6 VERIFICATION OF SPEED PARAMETERS..........................................................................24
4Patient secutiry...............................................................................................................................24
4.1 EMERGENCY STOP BUTTONS ..........................................................................................24
5Maintenance...................................................................................................................................26
5.1 PRECAUTIONS.....................................................................................................................26
5.2 ROUTINE MAINTENANCE....................................................................................................26
5.3 NON-ROUTINE MAINTENANCE ..........................................................................................29
6Disposal..........................................................................................................................................30
7Treadmill model 870 A technical specifications .............................................................................31
8Treadmill model 870 S technical specifications .............................................................................32
9Treadmill model 870 C technical specifications.............................................................................33

ANNEX A - Symbology..........................................................................................................................34
ANNEX B - RS232 Serial Port...............................................................................................................35
ANNEX C - Tap-Tst program ................................................................................................................36
ANNEX D –Troubleshooting.................................................................................................................37














TREADMILLS MOD. 870A/870S/870C

Rev.1/01.07.2019

WARNING

NO ACCIDENTALLY REBOOT SECURITY SISTEM

If the tension of the treadmill is taken off by one of this methods:

•Pushing the red emergency button

•Switch off the mains

•Pulling off the safety lanyard

Wait at least 30 seconds

Before give tension to the treadmill by this operations:

•Rotate to pull up the red emergency button

•Switch on the mains

•Put on the rubber cup of the safety lanyard

TREADMILLS MOD. 870A/870S/870C

Rev.1/01.07.2019

1 Introduction to the Equipment

Congratulations on your purchase of a new Treadmill 800 Series. This state-of-

the-art equipment represents the best current technology in Fitness, Sports

Applications, and Cardiorespiratory Diagnostic Exercise Systems.

1.1 ABOUT THIS MANUAL

This manual covers all aspects of the installation, operation and maintenance of

the 870 A, 870 S and 870 C Treadmills. It provides the necessary instructions to

guarantee correct and safe operations.

This manual should be kept with the treadmill at all times.

If you have a question regarding the operation or maintenance of the treadmill,

consult the manual first. If your question remains unanswered, please call the

Manufacturer, directly.

1.2 INTENDED USE

These treadmills have been specifically designed to be used in connection to a

variety of medical applications such as motor function, rehabilitation programs,

breathing and stress tests, and cardiorespiratory diagnostic exercise systems.

Used as indicated, the treadmills can be considered as supplementary

components for diagnostic purposes, and must be handled and maintained

under supervision by adequately qualified personnel. Typical environments for

these treadmills are outpatient cardiologic clinics, hospital wards and outpatient

departments for motor function rehabilitation.

The extraordinary versatility of these treadmills allows them to be used by a

wide range of people that wish to enjoy daily use of a treadmill for general

fitness purposes, progressive muscle exercises, and weight control.

The treadmill allows you to exercise in a safe environment, with adequate

space, and with simple fingertip control of all important parameters, including

speed.

Use of a treadmill eliminates many of the risks associated with outdoor

exercise. Most importantly, there is no risk of muscular trauma caused by the

asperity of the ground, because of the shock-absorbing deck. It also avoids

problems and inconveniences associated with climatic conditions and air

pollution.

These instruments were specifically designed to be compatible with other

Manufacturer’s Cardiorespiratory Diagnostic Exercise Systems, and for use in

Motor Rehabilitation Centres. In such configuration the treadmill becomes a

passive device of a diagnostic system and can be used by adequately qualified

personnel only.

TREADMILLS MOD. 870A/870S/870C

Rev.1/01.07.2019

1.3 PRECAUTIONS

During medical procedures such as cardiac stress tests, pulmonary function tests,

or motor rehabilitation therapies, the use of models 870 A, 870 S and 870 Cmust

be supervised and carried out by adequately qualified medical personnel.

•Stress test exercises must be performed under medical supervision and

with the assistance of qualified nursing staff. Furthermore the working area

must be equipped with all first aid instruments to be able to face potential

emergencies.

•During rehabilitation therapies, patients must be followed and kept under

supervision by adequately qualified personnel

During sport activities, the use of treadmill models 870 A, 870 S and 870 C is

strictly forbidden to the following category of people:

•Children under 14 years of age.

•People suffering from a heart condition.

•People suffering from kidney problems.

•Women with gynaecological problems.

•Pregnant women, later than six months.

•People with evident condition of overweight

•Diabetics.

•People without adequate medical certification of their qualification for sports

activities.

1.4 MANUFACTURER LIABILITY RESTRICTIONS.

The treadmills mod. no. 870 A, 870 S and 870 Care in compliance to all norms

applicable. The Manufacturer will not accept liability for any personal injury or

damage to belongings, if equipment is not used as intended, and according to

regulations in this User’s Manual.

Norms compliance can be violated by:

•use not in compliance with intended use as established by Manufacturer

•Failure to observe operating instructions

•Tampering or alterations improperly made by end user or by non-authorized

personnel

•Use of non-original spare parts, or parts not authorised by the

Manufacturer.

•Electrical system (where equipment will be used) in non-compliance with

safety norms and relative statutes

•Failure to observe routine maintenance norms.

•Using the equipment outdoors, or in inadequately protected or unhealthful

conditions or environments.

•Medical or therapeutically use of the equipment by personnel who is not

adequately qualified.

TREADMILLS MOD. 870A/870S/870C

Rev.1/01.07.2019

Non-compliance with any of the above warnings and cautions exempts the

Manufacturer from any responsibility for any accident or damage derived from

non-compliance.

1.5 SAFETY REGULATIONS

WARNING !

Incorrect use of this equipment may cause injury. Please ensure that the

safety regulations listed below are strictly observed:

1. Read this User Manual and the plates attached to the underside of the

treadmill hood carefully. Before operating the treadmill ensure you are

completely familiar with the control panel and its key functions.

2. Before connecting any equipment or device to a network, insure that this is

compatible with input voltage for device operations (230 Vac, 50 –60 Hz). A

lower input voltage, below values indicated on plate, would result in uneven

performance of treadmill, particularly at lower speeds.

3. Medical procedures such as cardiac stress tests, pulmonary function tests, or

motor rehabilitation processes are only to be carried out by adequately

qualified medical personnel.

4. Before beginning any exercise program check with your doctor to determine

your present physical condition and ability to undertake aerobic exercise. This

is especially essential for people suffering from abnormal blood pressure,

smokers, people addicted to stimulants, or taking other medication, people

suffering from cardiovascular disease, or those at risk of hereditary

cardiovascular disease.

5. During exercise, it is important to wear adequate shoes and clothing. Avoid

shoes with leather soles, heels, anti-slip strips, and spikes. The most

appropriate shoes are gym shoes with a soft rubber sole.

6. Do not step onto the running belt without shoes.

7. Do not put drinks or other liquids on or near the treadmill.

8. Do not leave clothing or towels on or near the treadmill. Such items may

seriously interfere with the moving parts of the equipment.

9. Do not scratch the plastic control panel of the treadmill with sharp objects such

as pens or screwdrivers.

10.Before moving the treadmill, make sure that the power switch is OFF, and it is

unplugged from the mains power outlet.

11. If, for any reasons it becomes necessary to move the equipment, you must

insure that the equipment power switch is turned off and that the equipment is

unplugged and rendered inoperable, before moving the equipment. If the

TREADMILLS MOD. 870A/870S/870C

Rev.1/01.07.2019

equipment is moved to a different environment double-check that this is

compatible with input voltage for device operations (230 Vac, 50 –60 Hz)

before connecting it to the network.

12.Ensure the treadmill is positioned well away from sources of water such as

drinking fountains. Do not pour any kind of liquid on the equipment.

WARNING !

If any kind of liquid should filter through the equipment, perform the

following:

•stop using it immediately

•disconnect the device from the mains power

•let skilled technicians check the device before using it again

13.Ensure the treadmill is positioned well away from heat sources such as

radiators.

14.Do not use the treadmill outside, or in areas exposed to external conditions

such as direct sunlight or rain.

15.Do not use the treadmill near an inflammable gas source.

16.Do not pull the power cord or the equipment itself in an attempt to remove the

plug from the outlet.

17.Do not try to move equipment by pulling the power cord.

18.Do not allow children, mentally or physically disabled people to use the

treadmill, unless under the direct supervision of adequately qualified personnel.

19.Always step onto the running belt facing forward (toward the Control Panel).

Assume a normal walking posture and hold the lateral handrails.

20.Do not put your hands, feet or any other object under the treadmill while the

equipment is in motion.

21.Ensure the treadmill has been thoroughly checked prior to use. Do not operate

the equipment if the power cable or plug is damaged. If you suspect the power

cable or plug is malfunctioning, set the power switch to OFF, remove the plug

from the mains outlet and call the authorised dealer.

22.Ensure the area surrounding the treadmill is clean, dry, and dust-free at all

times.

23.Do not remove the treadmill hood. This should only be carried out by

authorised service personnel.

TREADMILLS MOD. 870A/870S/870C

Rev.1/01.07.2019

WARNING !

Medisoft RAM Italia S.r.l. takes no responsibility for any accidents or

any damages caused to people or things due to a connection of the

treadmill to an electric outlet in non-compliance with current laws and

safety norms.

1.6 ELECTROMAGNETIC COMPATIBILITY

This device was designed and built to meet all the requirements and standards

of Norm EN 60601-1-2 and was found in compliance with all such norms and

standards.

EN 60601-1-2: Medical electrical equipment - Part 1: General requirements for

safety –Collateral standard: Electromagnetic compatibility –Requirements and

tests.

Nevertheless, in particular conditions, some interferences may arise. In order to

insure that the equipment operates correctly and performs as expected, the

Manufacturer invites the end user to focus attention on all special features of

the equipment discussed so far, and all that will follow, including all warnings

and recommendations that are often indicated by visually understandable

“warning” and “caution” tags.

It is the client/customer/end user’s responsibility to handle the equipment in

such a way as to be in full compliance with all indications provided by the

Manufacturer, in order to insure that the equipment will perform as expected

and guarantee safety as it operates in compliance with intended use.

The client/customer/end user must keep in mind that the utilisation of wireless

portable devices (such as cellular phones, cordless phones, walkie-talkies) can

interfere with operating functions of the equipment itself. To avoid

electromagnetic interferences it is important to keep a safe minimum distance

between the portable and RF communication devices and the treadmills model

no. 870 A, 870 S and 870 C, as recommended in the following Table 1 -

Immunity to RF.

TREADMILLS MOD. 870A/870S/870C

Rev.1/01.07.2019

Table 1 - RF immunity –Distance calculation for non-life-support equipment

Other equipment or devices can be a source of interference, or can be susceptible

to interference from a nearby noise source, such as TV broadcasts, speakers,

microwave ovens and other radio communication devices.

WARNING !

To avoid interferences between equipment and devices, we recommend

that the equipment be used at an adequate distance from such devices.

CAUTION

If it becomes necessary to use the equipment near other devices one must closely

observe its performance to check if the setup in which it is used, allows it to

perform at normal operational level.

CAUTION

•When connections are made to the RS 232 port, one should be very careful

as to avoid touching the pins of the connectors themselves.

•Before making any connections, we suggest using all ESD elementary

cautionary procedures: discharge the accumulated static electricity by

touching a conducting metal part connected to the ground protection of the

electrical system. As an alternative, touch a metallic part of a very wide

surface.

•When making any connections double-check that both devices or equipment

to connect are turned off.

Recommended separation distances between portable and mobile RF communications equipment and

the 870 A / 870 S /870 C treadmills

The treadmill model no. 860 A / 870 A is intended for use in an electromagnetic environment in which radiated

RF disturbances are controlled. The customer or the end user of the equipment can help prevent

electromagnetic interference by maintaining a minimum distance between portable and mobile RF

communications equipment and the treadmill model no. 870 A / 870 S / 870 C as recommended below,

according to the maximum output power of the radio communications equipment.

Rated maximum

output power of

transmitter (W)

Separation distance according to frequency of transmitter m

150 KHz to 80 MHz

Pd = 35.0

80 MHz to 800 MHz

Pd = 35.0

800 MHz to 2.5 GHz

Pd = 7.0

0.01

0.035

0.07

0.1

0.11

0.22

.35

0.7

1.1

2.2

100

3.5

For transmitters rated at a maximum output power not listed above, the recommended separation distance d in

meters (m) can be determined using the equation applicable to the frequency of the transmitter, where P is the

maximum output power rating of the transmitter in watts (W) according to the transmitter Manufacturer.

NOTES:

• At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.

• These guidelines may not apply in all situations. Electromagnetic propagation is affected by

absorption and reflection from structures, objects, and people.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Medisoft Tapis roulant

Medisoft

Medisoft 800 Series Manuale utente

Medisoft

Medisoft 800 Series Manuale utente

Manuali Tapis roulant popolari di altre marche

Treadly

Treadly TREADLY 2 Manuale utente

HEALTH ONE

HEALTH ONE Walk Ro Manuale utente

NordicTrack

NordicTrack NTL12941 Manuale utente

NordicTrack

NordicTrack T7.5 S Manuale utente

Gold's Gym

Gold's Gym ADVANTAGE GGTL12920 Manuale utente

Merax

Merax MS282992 Manuale utente

FYTTER

FYTTER RU-2SX Manuale utente

Precor

Precor 903 Manuale utente

FitLogic

FitLogic freewill d225 Manuale utente

HOP-SPORT

HOP-SPORT ESTIMA HS-3200LB Manuale utente

Horizon Fitness

Horizon Fitness Adventure 5 Plus Manuale utente

Stamia

Stamia InMotion II Manuale utente

Smooth Fitness

Smooth Fitness EVO 3i Manuale utente

NordicTrack

NordicTrack NETL81810.0 Manuale utente

Schwinn

Schwinn 830/Journey 8.0 Manuale utente

Keys Fitness

Keys Fitness HealthTrainer HT-740T Manuale utente

Spirit

Spirit XT8 Manuale utente

NordicTrack

NordicTrack T 14.0 Treadmill Manuale utente
