Mayo Stand

Double-Post with “California” Base

Weight capacity 25lbs

Instructions

for Use

MDRMS2021

Description

Secure, mobile, height-adjustable stand with tray for use in many types of

medical procedures.

Assembly Instructions

Remove contents from box, making sure you have all parts listed here.

Item Qty

1 Caster 2

2 Caster Socket 2

3 Tubular Upright 1

4 Base 1

5 Spring Pin 2

6 Support Rod 2

7 Tray Holder 1

8 Screw-Lock Knob 1

9Tray 1

1. Push Caster stem (1) fully into Caster Socket (2).

Note: casters may already be inserted.

2. Insert Tubular Upright (3) into Base (4). To lock

Tubular Upright in place, depress both Spring Pins

(5) and push the Tubular Upright into the base until

the pins “click” into place in the holes on the Base.

3. Manually hand screw the two Support Rods (6)

into the threaded sockets on the tray holder (7).

4. Slide the two Support Rods (6) attached to the

Tray Holder into the Plastic Sockets on top of

Tubular Upright (3).

5. Insert the Screw-Lock Knob (8) into the threaded

opening just below the Plastic Socket, adjust

height of the stand, and tighten knob.

Operating Instructions

Caution: DO NOT raise the height of the stand above the indicated markings on support

rods. Max Height 45".

DO NOT exceed the weight capacity of 25 lbs.

DO NOT use in MRI areas.

DO NOT attempt to support your body weight or us as a stand assist.

1. Place the tray (9) into the Tray Holder(7).

2. Loosen Screw-Lock Knob (8), adjust to desired height, and turn clockwise to tighten

securely.

3. Readjust whenever needed. NOTE: Tighten the Screw-Lock Knob prior to each use.

Maintenance

All surfaces should be cleaned according to facility guidelines.

Routine cleaning – Use warm water with mild cleansers.

Deeper cleaning – Vinegar provides deeper cleaning but should be wiped off and buffed

to maintain chrome.

DO NOT use abrasives, bleach, acid or ammonia. Wipe up any leftover liquid or it can

cause rust.

Inspect this stand periodically to ensure that all parts and hardware are secure, that

components are in good working order and not worn or loose. If any part or mechanism

appears to be unsafe or damaged, do not use the product. If you experience problems,

please contact Medline at 1-800-MEDLINE.

Medline Industries, LP, Three Lakes Drive, Northﬁeld, IL 60093 USA

Medline United States

1-800-MEDLINE (633-5463)

medline.com | [email protected]

Medline Canada

1-800-268-2848 | medline.ca | [email protected]

Medline Mexico

01-800-831-0898 | medlinemexico.com | [email protected]

Limited Warranty

Your Medline product is warranted to be free of defects in materials and workmanship

for the duration of use by the original purchaser. This device was built to precise stan-

dards and carefully inspected prior to shipment. This limited warranty is an expression

of our conﬁdence in the materials and workmanship of our products and assures years

of convenient, dependable service. In the event of a defect covered by this warranty,

we will, at our option, repair or replace the device. This warranty does not cover device

failure due to owner misuse or negligence, or normal wear and tear. The warranty does

not extend to non-durable components, such as rubber accessories, casters and grips,

which are subject to normal wear and replacement.
