IS1650

Honeywell’s IS1650 self-contained, area-imaging engine provides

easy and reliable bar code scanning for self-service kiosks or other

ﬁxed-mount POS applications.

The IS1650 is ideal for bar code scanning related to self-vending,

ID and boarding-pass veriﬁcation, shipping/receiving, bill payments,

supply-chain management and manufacturing automation.

With its omnidirectional capability, scanning one bar code or several

becomes a simple and swift experience for self-service customers.

The IS1650 contains a high-resolution imaging sensor, and decodes

all standard bar codes with minimal concern for orientation or print

quality – even codes damaged, worn or wrapped in clear plastic.

The IS1650 separates itself from other 2D imaging engines with

CodeSelect

™ technology, robust automatic activation and a 500-

mHz processor. CodeSelect gives the IS1650 the ability to scan up to

seven bar codes in a single flash and output the data in any

predetermined order.

The IS1650 also features Honeywell’s patent-pending TotalFreedom™

open-system architecture which expands scanner functionality by

allowing formatting, parsing and decoding plug-ins to be loaded directly

to the IS1650 instead of the host system.

Forward-illuminating design supports intuitive up-close scanning by

eliminating the “dead zone” associated with most imagers.

For more information on the IS1650 self-contained area-imaging

engine, please visit www.honeywell.com/aidc

Self-Contained Area-Imaging Engine

Total• Freedom:Expands scanner functionality by

allowing formatting, parsing and decoding plug-ins to be

loaded directly to the IS1650 instead of the host system

MobilePhoneReading:• Excels at scanning coupons

and tickets directly from the screen of a mobile device

MotionTolerance:• Offers aggressive scanning of bar

codes passing by the window in presentation mode

OmnidirectionalScanning:• Eliminates the need to

orientate scanner to bar code

Code• Select:Scans up to 7 codes in a single ﬂash and

outputs data in any predetermined order

IRObjectDetection:• Provides robust activation for

hands-free applications

SlimFormFactor:• Delivers superior performance in

tight spaces

Features

Security & Data Collection

Honeywell Scanning & Mobility

Honeywell

90 Coles Road

Blackwood, NJ 08012

856.228.8100

www.honeywell.com

For more information:

www.honeywell.com/aidc

RoHS

2002/95/EC

IS1650TechnicalSpecications

Operational

LightSource LED 645nm ± 7.5 nm

AudibleIndicators 7 tones or no beep

VisualIndicators Blue = ready to scan; White = good read; Yellow = automatic scanning

HostSystemInterfaces USB, RS232, Keyboard Wedge, IBM 46xx (RS485)

Mechanical

Dimensions(LxWxH) 116 mm x 80 mm x 62 mm (4.57˝ x 3.15˝ x 2.44˝)

Weight 204 g (7.2 oz)

Termination 10 pin modular RJ45

Electrical

InputVoltage 5 VDC ± 0.25 V

OperatingCurrent 330 mA @ 5 V - typical; 400 mA @ 5 V - peak

IdleCurrent 160 mA @ 5 V - typical

DCTransformers Class 2: 5.2 VDC @ 1 A

LEDClass Class 1: IEC60825-1, EN60825-1

EMC FCC Part 15, ICES-003, EN55022 Class B

Environmental

OperatingTemperature 0°C to 40°C (32°F to 104°F)

StorageTemperature -40°C to 60°C (-40°F to 140°F)

Humidity 0% to 95% relative humidity, non-condensing

Drop Designed to withstand 1 m (3.3’) drops

Vibration 7 G over 10-500 Hz

ESD Functional after 100 15 kv discharges

LightLevels 0 - 100,000 Lux (9,290 foot-candles) (total darkness - direct sunlight)

ScanPerformance

ScanPattern Area

SensorResolution 1.3 megapixel

MotionTolerance 47 cm/s (18˝/s) for 13 mil UPC @10 cm (4˝) distance

ScanAngle Horizontal: 45°; Vertical: 27°

FocalPoint 7 cm (2.76˝)

PrintContrast 20% minimum reﬂectance difference

DecodeCapability 1D: Code 39, Code 93, Code 128, UPC/EAN/JAN, Code 2 of 5, Code 11, Codabar, MSI Plessey, GS1 DataBar,

Telepen, Trioptic

PDF: PDF417, MicroPDF417

2D: QR Code, Micro QR Code, Data Matrix, Aztec Code, Maxicode,

Codablock, Composite Code, POSTNET,

PLANET, UPU, Intelligent Mail, Canada Post, Australia Post, Japanese Post,

Royal Mail RM4SCC, KIX Code

*OCR:OCR-A, OCR-B, E-13B MICR *Note: Enable by purchasing decoding license

Typical Performance*

Narrow Width Depth of Field

5.2 mil 38 mm - 146 mm (1.5˝ - 5.8˝)

7.5 mil 25 mm - 229 mm (1.0˝ - 9.0˝)

10 mil 0 mm - 330 mm (0˝ - 13.0˝)

13 mil 0 mm - 330 mm (0˝ - 13.0˝)

15.9 mil 0 mm - 432 mm (0˝ - 17.0˝)

10 mil

(Data Matrix) 30 mm - 185 mm (1.2˝ - 7.3˝)

15 mil

(Data Matrix) 30 mm - 265 mm (1.2˝ - 10.4˝)

*Resolution: 5 mil (0.127 mm)

*Performance may be impacted by bar code

quality and environmental conditions
