Micromega MySPEAKER Manuale utente
User’s manual
MYSPEAKER AUDIO LOUDSPEAKERS
Dear customer,
Thank you for choosing MySPEAKER Audio loudspeakers, we hope they will bring you many
years of enjoyment.
Please read this manual fully before unpacking and installing the product.
Carton contents
We have carefully checked, tested and inspected these loudspeakers during our
production and packing procedure. However, after unpacking them, please check for
any transport damage that may have occurred since the products left our factory. We
recommend that you keep the original carton boxes and packing materials for any future
shipping needs.
Loudspeaker positioning
Variations in the placement of your loudspeakers can sometimes produce dramatic
differences in the way your music sounds. As no two listening rooms are exactly the same,
we encourage you to spend some time experimenting with which positions work best in
your own room. Trust your ears and be willing to experiment to see what location sounds
best. Here are some basic recommendations: Try to ensure that the position of each
loudspeaker is similar in acoustic character. For example, if one loudspeaker is placed
in a corner or up against a wall while the other is placed farther into the room close
to soft furnishings, both the overall sound quaity and the stereo image are likely to be
compromised. Generally speaking, placing your speakers on bookshelves or on stands
against the wall will often provide a richer, more full-bodied sound. In other words you will
get more bass. On the other hand, if you place the loudspeakers farther into the room in
more open locations, you will often get less bass, but perhaps a more detailed sound.
The theoretically ideal positioning for the loudspeakers would be achieved by placing the
speakers between 1.5 m and 3 m apart at two corners of an equilateral triangle completed
by the listening area at the third corner (see fig. 1).
The MySPEAKER loudspeakers are designed to perform to a very high performance level in
a normal home environment. However, if extra deep bass is required, or for higher volume
levels in a larger room, a subwoofer could be added.
Loudspeaker installation tip
The speakers will sound at their best if they are located with the ‘’tweeters’’ approximately
at your ear level (for example) when you are seated and listening to your music.
MySPEAKER loudspeakers can also be used as the front channels in a surround sound
home theatre system. Positioning the front loudspeakers within approximately 1 m of the
sides of your TV will create the best sound image in scale with the visual image on the
screen. The loudspeaker’s height should ideally be between the centre and top of the
screen. If MySPEAKER loudspeakers are to be used for reproducing the surround channels
in a multi-channel home-theatre system, we suggest you place them as illustrated in fig. 2
to 4 depending on the number of channels.
Connecting your loudspeakers
Please read the manual of your amplifier or AV-receiver carefully before connecting your
loudspeakers. The binding posts on the terminal accepts wire up to Ø 4mm or cables with
banana plugs. Make sure that positive terminal binding posts on the speaker (marked + and
colored red) are connected to the positive output terminal binding posts on the amplifier,
and that the negative terminals on the speaker (marked - and colored black) are connected
to the negative output terminal on the amplifier. See fig 5.
You are now ready to enjoy your MySPEAKER MICROMEGA loudspeakers !
Running-in period
We recommend a running-in time of approximately 15-20 hours at normal listening
levels before you decide on the final positioning of the loudspeakers and before the
MySPEAKER loudspeakers drive units will settle in and will sound at their best.
Care and cleaning
We do not recommend the use of any solvents or spirit based cleaners on any part of your
MySPEAKER loudspeakers. The cabinet surface usually only requires dusting or cleaning
with a damp soft cloth (only use cold clean water). The grille fabric may be cleaned with a
normal clothes brush or vacuumed carefully with the grille detached from the cabinet. Avoid
touching the drive units, especially the tweeter, as damage may result units.
TECHNICAL CHARACTERISTICS
Specifications
2-Way Vented box system
1’’ ‘‘Tweeter’’ high frequency Driver
5 1/4’’ ‘‘Woofer’’ mid and low frequency Driver
Frequency Response 50Hz - 20KHz +/- 3dB
Sensitivity (at 1W/1m) 90 dB
Impedance 4Ω
Power handling 90W
AUDIS sarl, 13-15 rue du 8 Mai 1945, 94470 Boissy Saint Leger, FRANCE
Fax: +33(0)1 4382 6128 – www.micromega-hifi.com – VAT: FR07500331301
LEFT RIGHT
Amplificateur/Amplifier
Fig. 5 Amplificateur & bornier/Amplifier & binding post
Fig. 1 stereo Fig. 2 surround 5.1 Fig. 3 surround 6.1 Fig. 4 surround 7.1
sub sub sub
