Microtek C588 Manuale utente

OperationInstructions

Thank you forpurchasing thismonitor,ahigh-resolution multi-scancolormonitor.

Pleasereadthisguidethoroughlybeforeinstallation.

FCC RADIOFREQUENCY INTERFERENCESTATEMENTWARNING:(FOR

FCC CERTIFIEDMODELS)

Thismonitorhasbeentestedand found compliantwiththelimitsforaClass Bdigital

device,pursuanttopart15 oftheFCC Rules.Theselimitsaredesignedtoprovide

properprotection againstharmfulinterferencetoaresidentialinstallation.Thismonitor

generates,uses,and canradiateradiofrequencyenergy.Harmfulinterference toradio

communication mayresult ifit’snotproperlyinstalledand used.However,thereisno

guarantee thatinterference will notoccurinapaticularinstallation.If thismonitordoes

causeseriousinterference toradioortelevision reception,resetting themonitormay

determineit.Moreover,usersareencouragedto

correctinterference by doing oneormoreofthefollowing:

uReorientorrelocatethereceiving antenna.

uMovethemonitorand thereceiverfurtherawayfromeachother.

uConnectthemonitorintoanoutleton acircuit differentfromthatto

whichthereceiverisconnected.

uConsult yourlocaldealeroranqualifiedtechnician.

FCCWarning:

ToassureacontinuedFCC compliance,ausermustuseagroundedpowersupplycord

and theprovidedshieldedvideointerface cablewithbondedferritecores.Also,any

unauthorizedchangesormodificationstothismonitorwouldvoidtheuser’sauthority

tooperatethisdevice.

Note:If necessary,shieldedinterface cablesand theA.C.powercordmustbeusedto

meettheemissionlevellimits.

EMICertification

TheClass Bdigitalapparatusmeetsall requirementsoftheCanadianInterference-

Causing EquipmentRegulation.Cetappareil numeriquedeclass Brespectetoutesles

exigencesdu ReglementsurIcmaterielbrouilleurdu Canada.

SafetyPrecautions

Careand Maintenance

FirstStep

FrontPanelControl

Installation

UsingOSDFunctions

Timing Modes

TechnicalInformation

Contents

.........................................................1

..................................................2

......................................................................3

......................................................4

....................................................................4

....................................................5

..............................................................6

..................................................7

SafetyPrecautions

Thismonitorismanufacturedand testedon theground principlethatauser’ssafety

comesfirst.However,improperuseorinstallation maynotonlydamagethemonitor

butendangertheuseraswell.Asasafetyprecaution,go overthefollowing WARN-

INGScarefullybeforeinstallation,and keepthisguidehandy.

WARNINGS:

lThismonitorshouldbeoperatedonlyatthecorrectpowersourcesindicatedon

thelabelattherearend ofthemonitor.If you areunsureofthepowersupplyin

yourresidence,consult yourlocaldealerorpowercompany.

lDonottrytorepairthemonitoryourselfasit containsno user-serviceableparts.

Themonitorshouldonlyberepairedby aqualifiedtechnician.

lDonotremovethemonitorcabinet.Therearehigh-voltagepartsinsidethatmay

causeelectricshocktohumanbodies,evenwhenthepowercordisdisconnected.

lStop using themonitorifthecabinetisdamaged.Haveit checkedby aservice

technician.

lPutyourmonitoronlyinaclean,dryenvironment.Unplug themonitorimmedi-

atelyifit getswet,and consult yourservice technician.

lAlwaysunplug themonitorbeforecleaning it.Cleanthecabinetwithaclean,dry

cloth.Applynon-ammonia-basedcleanerontothecloth,notdirectlyontothe

glass screen.

lKeepthemonitorawayfrommagneticobjects,motors,TVsets,andtransformers.

lDonotplace heavy objectson thecableorpowercord.

lForPLUGGABLE EQUIPMENT,thesocketoutletshouldbeinstallednearthe

equipmentand shouldbeeasilyaccessible.

CareandMaintenance

Care

lAvoidexposing yourmonitordirectlytosunlightorotherheatsources.Place

yourmonitorawayfromthesun toreduce glare.

lPutyourmonitorinawell ventilatedarea.Donotplace anything heavy on top of

yourmonitor.

lMakecertainthatyourmonitorisinstalledinacleanand moisture-free area.

lKeepyourmonitorawayfrommagnets,motors,transformers,speakers,and TV

sets.

SafetyTips:

lIf smoke,abnormalnoiseorodorcomeoutofyourmonitor,switchoff thepower

immediatelyand call yourservice center.

lNeverremovetherearcoverofyourmonitorcabinet.Thedisplayunit inside

containshigh-voltagepartsand maycauseelectricshocktohumanbodies.

lNevertrytorepairthemonitoryourself.Alwayscall yourservice centerora

qualifiedtechniciantofixit.

Note

Thisuser’smanualcontainsgraphicsand information thatisforreference purposeonly

and issubjecttochangewithoutnotice.

FirstStep

Thank you forpurchasing thishigh performance monitor!

Thismonitorpackagecomeswith:

lVideocablewith15 pinD-SUBconnector.

lPowercable.

lUser’smanual

QuickInstallation

1.Connectvideocable

Makesureboththemonitorand com-

puterarepoweredOFF.Connectthe

videocabletothecomputer,thento

themonitor.

2.Connectpowercord

Connectthepowercordtoaproperly

groundedACoutlet,thentothe

monitor.

3.Power-ONcomputerandmonitor

Power-ON thecomputer,thenPower-

ONthemonitor.

4.Windowsusers:SettheTiming

Mode(Resolution and RefreshRate)

Example:1024x768@75Hz

ResolutionRight-clickontheWindows

desktop >Properties>Settings>

“Desktop Area”.Settheresolution.

RefreshRate(verticalfrequency):

See yourgraphiccard’suserguidefor

instructions.

PowerD-SUB

FrontPanelControl

OSDON/OFF ENTER

SCROLLDOWNPOWERINDICATOR

SCROLLUPPOWERON/OFF

Installation

POWERINPUT(ACINPUT)

SINGALINPUT(VGA15PIND-SUB)

UsingtheOSDFunctions

MAINMENU(example)

AutoAdjust: Forautoadjusting thehorizontalposition,verticalposition,Clockand phase.

H.Position:Foradjusting thehorizontalposition ofthepicture.

V.Position:Foradjusting theverticalposition ofthepicture.

Brightness:Foradjusting thebrightness ortheback-lightcurrent.

Contrast:Foradjusting thecontrastpicture.

Phase:Foradjusting thedelaytimebetweenthehorizontalsynchronoussignaland thepicture.

Clock:Foradjusting thevideodisplayclock.

Sharpness:Foradjusting theInterpolation mode(excluding 1024~768timing)(Sharporsmooth)

OSDFunction:Forselecting theOSDposition and transparency.

ColorAdjustment: Forselecting colortemperaturesbetween6500Kand usersettings.

TextMode:Forselecting720X400 or640X400.

Language:FiveOSDlanguagescanbeselected:ENGLISH,FRENCH,GERMAN,ITALIAN,

SPANISH

MemoryRecall:Toreverttodefault settingsbeforesaving.

1.Press the‘’button toturntheOSDoff.

2.Press the‘ ’ or‘ ’ button toscroll up/down.

3.Press the‘’button toentertheselectedfunction intheOSDsub-menu.

EXITSELECT

HotKeyfunctions:

Whenno OSDappears,press:

the‘’button toturntheOSDon/off,

the‘’button tohavethemonitorauto-adjustand saveall settings,

the‘ ’ button toadjustthecontrast,

the‘ ’ button toadjustthebrightness,

or‘ ’+‘ ’forMemoryRecall.

Timingmodes

640x400@70HZ

640x480@60HZ

640x480@67HZ

640x480@75HZ

800x600@56HZ

800x600@60HZ

800x600@72HZ

800x600@75HZ

832x624@75HZ

1024x768@60HZ

1024x768@70HZ

1024x768@75Hz

VESA

MAC

VESA

TechnicalInformation

TechnicalSpecifications

15.0TFT

EnergyStarcompliantVESA

DPMScompatible

<5W

XGA1024x768max.VerticalFrequency

75Hzmax.

0.297x0.297mm

16.7M(8bits/color)

304.1x228.1mm

Horizontal: 60 (typical)

Vertical:-55 ~+45 (typical)

+90 ~0

350:1(typical)

200cd/m2(typical)

Tr=13ms(typical)

Tf=27ms(typical)

304.1mmx228.1mm

Operation:0~+40

Storage:-20 ~+60

UL,TUV/GS,CE,FCC-B,EnergyStar

Voltage90-264VAC

Consumption30Watts(max)

LCDPanel

PowerManagement

DisplayableResolution

PixelDimension

LCDDisplayColor

ActiveDisplayArea

ViewingAngle

Tilt

ContrastRatio

Brightness

ResponseTime

ActiveDisplayArea

Temperature

Compliance

Power
