Miele GAS COMBISET CS 1012 Manuale utente
Operating and installation instructions
Gas hobs
CS 1012
CS 1034
To avoid the risk of accidents or
damage to the appliance it is
essential to read these
instructions before it is installed
and used for the first time. M.-Nr. 07 172 910
en-GB
DDas Gerät ist auch für den Gebrauch in anderen als auf dem Gerät
angegebenen Bestimmungsländer zugelassen. Die landesspezifische
Ausführung und die Anschlussart des Gerätes haben wesentlichen Einfluss auf
den einwandfreien und sicheren Betrieb. Für den Betrieb in einem anderen als
auf dem Gerät angegebenen Bestimmungsland wenden Sie sich bitte an den
für das Land zuständigen Kundendienst.
EEl aparato está autorizado para el uso en países diferentes a los países de
destino indicados. La ejecución específica para cada país y el tipo de
conexión del aparato influyen de forma decisiva en el funcionamiento correcto
y seguro. Para el funcionamiento en un país diferente al país de destino
indicado en el aparato, consulte al Servicio Post-venta autorizado para el país.
FCet appareil est également homologué dans des pays différents de ceux
mentionnés sur l’appareil. Pour que l’appareil fonctionne parfaitement et en
toute sécurité, il est important de disposer de l’exécution spécifique au pays et
du type de raccordement approprié. Pour le fonctionnement dans un pays
autre que celui spécifié sur l’appareil, veuillez vous adresser au service
après-vente du pays où sera installé l’appareil.
GThis appliance can be used in countries other than those specified on the
appliance. It is, however, set up for connection to the gas and electricity
supplies in the countries specified. For use in other countries please contact
the Miele spare parts or customer service department in your country.
IL’apparecchio può essere usato anche in paesi diversi da quello indicato
sull’apparecchio stesso. Tuttavia, le varianti specifiche di un determinato paese
e il tipo di allacciamento alla rete hanno un’importanza fondamentale per il suo
sicuro e corretto funzionamento. Per questo se si vuole usare l’apparecchio in
un paese diverso rivolgersi al servizio di assistenza tecnica Miele del paese in
cui si intende usarlo.
MHet apparaat is ook toegelaten voor gebruik in andere landen dan de landen
die op het apparaat vermeld staan. De specifieke uitvoering en de aansluitwijze
zijn van groot belang voor het goed en veilig functioneren. Neem daarom
contact op met de Technische Dienst van de fabrikant in uw land als u het
apparaat in een land wilt gebruiken dat niet op het apparaat vermeld staat.
2
Gas-heated appliances
Safety precautions to take if you smell gas
ßTurn off the gas emergency control valve immediately.
This is usually located near the gas meter.
ßEliminate all sources of ignition in a safe manner.
Do not smoke, light cigarette lighters or matches.
ßDo not operate electrical lights or switches, i.e. do not switch them "On" or "Off".
ßOpen all doors and windows to ventilate the area.
ßIf the smell of gas persists, evacuate the building.
In the UK you must now:
ßCall the Gas Emergency Contact Centre (Tel: 0 800 111 999)
For any gas work in the UK always use a Gas Safe registered engineer.
In other countries please follow relevant country specific procedures on gas.
3
Guide to the appliance .............................................6
CS 1012 ..........................................................6
CS 1034 ..........................................................7
Warning and safety instructions .....................................9
Caring for the environment.........................................15
Before using for the first time.......................................16
Operation .......................................................17
Rapid ignition system ..............................................17
Switching on, adjusting the flame and switching off .......................17
In-operation indicator and Residual heat indicator ........................19
Pans ...........................................................20
Safety features ...................................................21
Cleaning and care ................................................22
General notes ....................................................22
Stainless steel surfaces .............................................23
Pan supports, control knobs .........................................23
Burner ..........................................................24
Problem solving guide ............................................25
Optional accessories..............................................27
Safety instructions for installation...................................28
Appliance and building-in dimensions ...............................32
CS 1012 .........................................................32
CS 1034 .........................................................33
Contents
4
Preparing the worktop.............................................34
Installation of several appliances....................................35
Fitting the spring clamps and spacer bars ............................37
Installing / removing the appliance(s) ................................39
General installation tips ...........................................40
Electrical connection..............................................41
Gas connection ..................................................43
Conversion to another type of gas...................................45
CS 1012 .........................................................45
Jet table ......................................................45
CS 1034 .........................................................46
Jet table ......................................................46
Changing the jets..................................................47
Function test .....................................................48
After sales service, data plate ......................................49
Contents
5
CS 1012
aExtra large burner
bNormal burner
cPan support
dSymbols to indicate which gas
burner the control is for
eDisplay
Display
lIn-operation indicator
mResidual heat indicator
Controls:
frear
gfront
Guide to the appliance
6
CS 1034
aLarge burner
bNormal burner
cExtra large burner
dNormal burner
ePan supports
fSymbols to indicate which gas
burner the control is for
gDisplay
Display
lIn-operation indicator
mResidual heat indicator
Controls:
hfront right
irear right
jrear left
kfront left
Guide to the appliance
7
Burner
nBurner cap
oBurner head
pIgnition safety device
qIgnitor
rBurner base
Guide to the appliance
8
This appliance complies with all
relevant local and national safety
requirements. Improper use can,
however, present a risk of both
personal injury and material
damage.
To avoid the risk of accidents and
damage to the appliance, please
read these instructions carefully
before installation and using it for
the first time. They contain important
notes on installation, safety,
operation and care.
Keep these instructions in a safe
place and ensure that new users are
familiar with the content. Pass them
on to any future owner.
Correct application
~This gas hob is not designed for
commercial use. It is intended for use in
domestic households and in similar
working and residential environments
such as:
–Shops
–Offices and showrooms
and by residents in establishments
such as:
–Hostels and guest houses.
~The gas hob is intended for
domestic use only to cook food and
keep it warm.
Any other use is not supported by the
manufacturer and could be dangerous.
Miele cannot be held liable for damage
resulting from incorrect or improper use
or operation of the appliance.
~This appliance is not intended for
use by persons (including children)
with reduced physical, sensory or
mental capabilities, or lack of
experience and knowledge, unless they
are supervised whilst using it, or have
been shown how to use it by a person
responsible for their safety.
Warning and safety instructions
9
Safety with children
~This appliance is only intended for
use by adults who have read these
instructions. This appliance is not a toy!
To avoid the risk of injury, keep children
well away and do not allow them to play
with it or use the controls. They will not
understand the potential dangers
posed by it. They should be supervised
whenever you are working in the
kitchen.
~Older children may use the
appliance only when its operation has
been clearly explained to them and
they are able to use it safely,
recognising the dangers of misuse.
~The appliance gets hot when in use
and remains hot for quite a while after it
has been switched off. To safeguard
against burning, keep children well
away from the appliance at all times.
~Do not store anything which might
arouse a child's interest in storage
areas above or next to the hob.
Otherwise they could be tempted into
climbing onto the appliance with the
risk of burning themselves.
~Keep all pans out of reach of
children. Turn pan handles inwards
away from the edge of the hob. Danger
of burning or scalding.
~Packaging, e.g. cling film,
polystyrene and plastic wrappings,
must be kept out of the reach of babies
and young children. Danger of
suffocation. Dispose of or recycle all
packaging safely as soon as possible.
Warning and safety instructions
10
