1 Version 2.0
Bush Baby Stealth Dictionary
Hidden Camera Manual
SKU: BBSRBDictionary
2 Version 2.0
THANK YOU FOR PURCHASING THE BBSDICTIONARY
Please read through this manual before operating your
device, and keep it handy.
Your purchase should include:
1 x BBSRBDictionary
1 x Remote Control
1 x Removable Battery
1 x MicroUSB Cable
1 x Charging Adapter with Indicator Lights
1 x AC Adapter
1 x 16GB MicroSD Card
1 x MicroSD Card Reader
1 x Instruction Booklet
3 Version 2.0
GET FAMILIAR WITH THE BBSDICTIONARY
4 Version 2.0
5 Version 2.0
6 Version 2.0
BEFORE YOU START
To preserve battery power, your device will come with
the battery connector disconnected. Before
attempting to use the device be sure to connect the
battery’s connector to the circuit board power lead.
OPERATING THE BBSDICTIONARY
IMPORTANT NOTICE: Allow the device to charge 6 –8
hours before using.
MICROSD CARD SLOT
To access the MicroSD Card Slot, you must open the
dictionary using the given key.
1. Gently push the MicroSD Card into the slot. The
gold contacts on the card will be inserted first,
and they should face the main circuit board.
You will feel some spring resistance before the
card clicks in to place.
2. Never force the card into the Card Slot under
any circumstances, otherwise the dictionary
unit or the MicroSD card itself will be damaged.
7 Version 2.0
3. To remove the SD card, gently push the card in
so that it clicks.
4. The internal spring tension will eject the card.
REMOVING AND CHARGING THE BATTERY
1. Remove battery from the inside of the
dictionary.
2. Disconnect the battery connector that is
connecting the battery to the circuit board. Be
careful not to pull on the wires as that could
damage them.
3. Connect the connector on the battery to the
connector on the charging adapter (see page
5).
4. Plug the provided USB cable into the other end
of the charging adapter.
5. Plug the other end of the USB cable into the
wall AC adapter and plug it into the wall.
6. Wait 6 to 8 hours.
a. The larger the battery capacity, the
longer it takes to charge.
8 Version 2.0
HOW TO TURN ON THE CAMERA
1. Press the Power Button on the remote control
one time. The device is now in Standby mode.
HOW TO RECORD CONTINUOUS VIDEO (720P)
1. In standby mode, press the “B” button once
quickly (see page 4). The unit will vibrate twice.
2. Once the device stops vibrating, it is recording
video.
3. To stop recording, press the “B” button again,
and wait three seconds. The device
automatically returns to standby mode.
HOW TO RECORD CONTINUOUS VIDEO (1080P)
1. In standby mode, press and hold the “C” button
for 3 seconds.
2. The unit will vibrate three times. The camera is
recording when the unit stops vibrating.
3. To stop recording, press the “C” button again,
and wait three seconds. The device will save
the video and return to standby mode.
9 Version 2.0
HOW TO RECORD IN MOTION DETECTION MODE
1. In Standby mode, press the “D” button once
quickly (see page 4). The unit will vibrate three
times.
2. The unit is now in motion detection mode, and
it will begin recording video when motion is
detected. NOTE: there will be no indication
when the device detects motion –it will simply
start recording video.
3. To return to standby mode, press the “D”
button again. The unit will vibrate, and then
return to standby mode.
HOW TO TAKE A PICTURE
1. While in Standby mode, press the “C” button
quickly (see page 4). The unit will vibrate, and
one photo will be taken. The unit will return to
standby mode.
MICROSD CARD SLOT
To access the MicroSD Card Slot, you must open the
dictionary’s false inside and find the camera board.
10 Version 2.0
1. Gently push the MicroSD card into the slot until
you hear a click, then release the card. The
spring inside should push the card out enough
that you can grab it.
2. To insert the SD card, make sure the gold
contacts on the card are inserted first, and that
they’re facing the main circuit board. You will
feel some spring resistance before the card
clicks into place.
3. Never force the card into the slot. Otherwise,
your unit or the card will be damaged.
64GB and 128GB MicroSD cards will require special
formatting to work. The device will not function with
these cards if they are not properly formatted
beforehand.
Visit www.mgidownloads.com/Software and download
the “guiformat.zip” file. Extract the files and follow the
instructions in the “64GB SD Card Formatting.pdf”
document.
