Minolta MNCD50 Manuale utente
MINOLT
•
MINOLTX MNCD50
Dash Cam
ADDENDUM A
FAQ
Q: My camera will not respond to any buttons presses. Why is this happening?
A: Your dash-cam is designed to prioritize the recording of video and will not allow any interruptions. The menu and other
modes can only be operated while the dash-cam is in standby (not recording).
Q: How can I access the menu or change modes while my camera is recording (blinking red dot at top of screen)?
A: If Motion Detection is enabled (if this icon displays on the left side of the screen), please follow one of these steps:
1) Set your dash-cam on a flat surface. Press the RECORD button to ensure that the red dot on the screen is no longer
blinking. Now press the menu button.
OR
2) Remove the MicroSD memory card by pushing it in. It will bounce back out. You can now press the MENU or MODE
button to access the menu and other modes. If you select PLAYBACK mode, be sure to reinsert your MicroSD card so you
can play back your files.
Q: How can I disable Motion Detection ?
A: With the MicroSD removed, make sure you are in VIDEO mode and press the MENU button.
Navigate to Motion Detection with the UP and DOWN buttons.
Press the RECORD button.
Select OFF and press the RECORD button again to confirm the setting.
Press the MENU button twice to save and exit the menu.
Getting Started
Simply insert the MicroSD card into the MicroSD card slot, and insert the auxiliary power adaptor into the camera’s
USB port and your car’s power port. The camcorder will automatically power on and begin recording video.
Remove the auxiliary power adaptor to automatically save a recording and power the camcorder off. To start or
stop recording at any time, press the RECORD button. Press the power button for 5 seconds to manually power off.
Video Capture
To manually capture video, enter VIDEO Mode and press the RECORD button to begin recording video.
Photo Capture
To capture a photo, enter PHOTO Mode and the RECORD button to instantly capture a photo.
Modes
To switch between video, photo and playback modes, simply press the MODE button.MODE icons are displayed in
the upper left corner of the screen.
VIDEO Mode PHOTO Mode PLAYBACK Mode
________________________________________________________________________________________________________________________________________________________________
Safety and Handling Precautions
•Do not take apart or attempt to service the camera yourself.
•Do not expose the camera to moisture, or extreme temperatures.
•Allow the camera to warm up when moving from cold to warm temperatures.
•Do not touch and put pressure on the camera lens.
•Do not expose the lens to direct sunlight for extended periods.
•Do not use abrasive chemicals, cleaning solvents or strong detergents to clean the product. Wipe the product with a slightly damp soft cloth.
•When the camera is used for an extended period of time, it is normal for the camera body to feel warm.
•Do not subject the LCD monitor to impact.
•To prevent the risk of fire or electric shock, do not expose this appliance to rain or moisture.
INTRODUCTION
The Minolta MNCD50 Car Camcorder integrates multiple functions of 1080p HD video capture,
sound recording and external memory storage. It adopts video decoding technology of high
performance and compression ratios, and contains an HDMI interface capable of transferring HD
videos and audio data with several sound channels uncompressed. This camcorder is intended for in-
vehicle shooting, which effectively enables the collection of evidence for driving accidents, daily life,
traveling and outdoor activities.
The Minolta MNCD50 allows you to record video when mounted to your car’s windshield in a wide,
large angle.
This quick guide explains how to use your camcorder and provides additional information, including
precautions and technical specifications. Please read through it carefully and understand this quick
guide before use. Keep it properly stored away for reference.
9
MicroSD Card Slot
10
Up
11
Menu
12
Down
13
Front Lens
14
USB Port
15
Mount Port
16
HDMI Port
OVERVIEW
1
Display
2
Status LED Indicator
3
Speaker & Microphone
4
Reset
5
OK/Record
6
Lock File/Parking Monitor
7
Mode
8
Power
GETTING STARTED
MicroSD Card Insertion and Removal
Ensure the camera is powered off.
Insert a MicroSD card into the MicroSD card slot with the gold pins facing the direction of the
display screen. The MicroSD card can only be inserted in one direction. Do not force it through.
Once successfully inserted, it will click in.
To remove the MicroSD card, simply push the MicroSD card in and it will bounce back out.
Power
In-Car Use
Connect the included Auxiliary USB Power Adaptor to your car. Plug the USB plug into the
camcorder’s USB interface. Charging will begin immediately. Please note that the internal battery
has a very limited capacity and is only intended for use in emergency use situations.
USB Cord Use
Connect the included USB cable to a free USB port on your computer, and connect the other end into
the camcorder’s USB interface. The battery may be charged while the camcorder is powered on or
off.
While charging, the red indicator LED will illuminate. When charging is complete, the indicator LED
will automatically turn off.
Quick Use
Simply insert a MicroSD card into the MicroSD card slot, and insert the auxiliary power adaptor into
the camera’s USB port and your car’s power port. The camcorder will automatically power on.
Remove the auxiliary power adaptor to automatically save a recording and power the camcorder off.
To start or stop recording at any time, press the RECORD button.
CAMCORDER OPERATION
Press the POWER button to power the camcorder on. The camcorder will automatically begin
recording video if a MicroSD card is inserted in the card slot and motion detection has been enabled,
or the G-sensor sensitivity is enabled. Press the power button for 5 seconds to manually power off.
To switch between video, photo and playback modes, simply press the MODE button.
MODE icons are displayed in the upper left corner of the screen. Press the RECORD button to begin
recording video or to capture a photo.
VIDEO Mode PHOTO Mode
1. VIDEO Mode
2. Loop Recording Enabled
3. Motion Detection Recording Enabled
4. Exposure Value
5. G-Sensor Enabled
6. Recording Time Remaining
7. Current Date
8. Current Time
9. Current Battery Power Level
10. MicroSD Card Inserted
11. Microphone Enabled
12. Wide Dynamic Range Enabled
13. Current Video Resolution
14. Recording Active
15. Park Mode Enabled
VIDEO MODE
PHOTO MODE
1. PHOTO Mode
2. Exposure Value
3. Automatic White Balance Enabled
4. Automatic ISO Enabled
5. Digital Image Stabilization Enabled
6. Sequence Photos Mode
7. Number of Pictures Remaining
8. Current Photo Resolution
9. Current Image Quality
10. MicroSD Card Inserted
11. Current Battery Power Level
PLAYBACK MODE
Press the MODE button until you enter PLAYBACK mode. It is the third mode. PLAYBACK mode
allows you to browse through your photos and videos, and allows you to playback files recorded by
your camcorder.
Press the UP and DOWN buttons to cycle through available playback files.
Press the MODE button again to exit PLAYBACK mode.
Playing Back Video Clips
Press the RECORD button to play or stop a video clip in PLAYBACK mode.
To fast forward, press the DOWN button while video is playing back.
To rewind, press the UP button while video is playing back.
Press the MENU button to delete a file or to protect a file from deletion.
MENU & SETTINGS INTERFACE
The menu interface is available in all 3 modes and the options settings differ depending on the
current mode enabled.
To access VIDEO and PHOTO mode settings:
Press the MODE until you are in either VIDEO or PHOTO mode. While in VIDEO mode, you will
notice a camcorder icon in the top left corner. In PHOTO mode, you will notice a camera icon in the
top left corner.
Press the MENU button to access the current mode’s settings.
Press the UP and DOWN buttons to navigate through the various settings within the menu.
Press the RECORD button to access a highlighted setting, or to access any of the submenus.
Press the RECORD button again to confirm a highlighted setting.
Press the MENU button twice at any time to save your settings and exit the menu.
To access SETUP/MAIN settings:
While in any mode, press the MENU button twice to access the SETUP/MAIN settings.
Press the UP and DOWN buttons to navigate through the various settings within the menu.
Press the RECORD button to access a highlighted setting, or to access any of the submenus.
Press the RECORD button again to confirm a highlighted setting.
Press the MENUbutton again at any time to save your settings and exit the menu.
