Minox DD1 Manuale di istruzioni

DD1

MINOX – a name that spells exclusiveness

Just like the legendary MINOX spy camera which

stands for fine mechanical precision in miniature size,

the new MINOX DD1 also creates excitement through

its unique design and technology concept.

Pin-sharp definition and brilliance are guaranteed by

the 5-element multi-coated glass lens. In combination

with the 2.1 megapixel chip, the refined electronics

and the specially developed software, you can be sure

of brilliant images with natural rendition.

Concentration on essentials.

This basic principle also applies to the

MINOX DD1.

All major functions are ergonomically

designed and incorporated in the

“mode” button on the back of the

camera. No need to spend all your time

looking up the operating instructions

and you can get down to sheer photo-

graphic enjoyment straight away.

M1:1

Technical Data

Minox DD1

Image sensor 3.0 MP CMOS (2.1 MP hardware resolution)

Image resolution Still image: Super High Resolution (3MP): 2048 x 1536 Pixels (Interpolation)

Fine High Resolution (2.1 MP) or Fine Low Resolution (2.1 MP): 1600 x 1200 Pixels

Super Low Resolution (2.1 MP): 1600 x 1200 Pixels; Web-Cam / Video: 320 x 240 Pixels

Image memory (internal memory) 32 MB (FLASH)

Image compression (ratio) super/high (3 MP): 1:9 / fine/high (2.1 MP): 1:5

fine/low (2.1 MP): 1:7,5 / super/low (2.1 MP): 1:12

Image memory capacity Super High Resolution (3 MP): approx. 40

Fine High Resolution (2.1 MP): approx. 40

Fine Low Resolution (2.1 MP): approx. 60

Super Low Resolution (2.1 MP): approx. 99

Main memory (camera) 16 MB SD-RAM

Viewfinder Integrated optical viewfinder

LCD status display 2 digit

Lens 5 elements, glass lens element with IR filter

Lens aperture F 2.8

Focal length 9,6 mm / 0,38 inch related to small picture: approx. 48 mm

Focus range 0,5 m / 3,2 ft to infinity

White balance automatic

Exposure Auto exposure

Self-timer 10 seconds

Power supply 1 x CR2 battery / via USB connection (PC)

Menue control Shutter Button and On/Mode Button

Beep signal Yes

Automatic off Off mode, after 30 seconds of non-use

PC connection USB cable

Dimensions 83 x 75 x 32 mm / 3.27 x 2.95 x 1.26 inch (LxHxW)

Weight approx. 120 g / approx. 4.23 oz

System requirements Microsoft Windows 98/SE/ME/2000/XP Pentium-Processor or later; MacOS 9.x

64 MB recommended; Video with 2 MB RAM for displaying at least 16 Bit (High Color)

CD-ROM with 4x velocity; USB-port

This was the set task for the develop-

ment team.

And based on an entirely new inter-

pretation of camera aesthetics the

skilled designers managed once again

to furnish another milestone in

MINOX history.

The body of the DDI is shaped as a

round and flat basic form. The heart of

the camera – the lens – is the core

element and also forms the major com-

ponent in the quality chain. The stylish

shutter release, battery compartment

and USB connection are arranged as

marked features on the outer edge of

the camera body and award the MINOX

DDI the distinguished and unmistakable

character that makes a classic camera.

This extremely compact digital camera,

which weighs just 120 grams / 4.23 oz

and measures a mere 75 mm / 2.95 inch

in diameter, is designed to become your

very personal chronicler – which

accompanies you wherever you go to

record those moments that have to be

captured.

Precision that fits into every pocket.

Graphic Design: Heussinger, Solms / Photography: Maik Scharfscheer, Frankfurt/M.

MINOX GmbH

Walter-Zapp-Str. 4

D-35578 Wetzlar, Germany

Tel.: +49 (0) 6441 / 917-0

Fax: +49 (0) 6441 / 917-612

e-mail: info@minox.com

www.minox.com

Design, features, supply and price are subject to change.

07/03/LX/B / Product information order number: 99246
