C
REV
DATE
KW
DWG. CREATED5495
RETIRED:
LAST USED: 0None
Q.C. DATE
APPROVED
ENG. DATE
APPROVED
C803AT70
500-0799-111 REV -
4/11/00
N/A
Mitek Corporation
NONE
SOLIDWORKS
BY
REV
ENG. APPROVAL
DESCRIPTION
MAT'L
FINISH
SCALE
TITLE
CAD FILE NAME:
MITEK PAR T # / DRAWING #
CHK'D BY
DATE
DRAWN
DRAWN BY
DESIGNS AND INFORMATION WHICH IS THE
Research & Development
1601 Jack McKay Boulevard
Ennis, TX. 75119
Phone: (972)875-8413
EXPRESS WRITTEN PERMISSION OF A DULY
ARE RESERVED BY MITEK CORPORATION.
CORPORATION AT ANY TIME. IT IS BEING
AUTHORIZED AGENT OF MITEK CORPORATION.
WHOLE OR IN PART, FOR ANY PURPOSE WI THOUT
THIS DRAWING IS SUBJECT TO RECALL BY MITEK
SUBMITTED IN CONF IDENCE AND PATENT RIGHTS
DISCLOSED TO OTHERS, PROPOSED OR USED IN
NONE OF WHICH SHALL BE COPIED, REPRODUCED,
CONFIDENTIAL PROPERTY OF MITEK CORPORATION.
THIS DRAWING AND DATA EMBODY PROPRI ETARY
Fax: (972)875-8416 SHEET #
DRAWN IN
K. WAYMON
SPK 8 IN COAX T7/5W
1/13/04
J. ALMAND
10/17/03
B. MARLIN
11/14/04
W. HENDERSON
4/11/00
A
C803AT70
ASME Y14.5M-1994
Q.C. APPROVAL
B
SIZE
SCALE : 1:2
11
OF
HOLES .005
UNITS INCH
.03
.015
1
X.XXX
X.XX
FRACTIONAL
ANGLUAR
TOLERANCES
1/64
ECO# APRV.
MFG. APPROVAL
MFG. DATE
APPROVED
G. LAW
B
C
E4364
E4520
ADDED 419006, MADE SINGLE PART PRINT, DWG# WAS 30-10774
113557 WAS 187489, 112895 WAS 419006
MDH
KI
6/20/03
10/17/03
BM
BM
2
4
NOTES:
1. ROUTE PRIMARY WIRES THRU CORD CLAMP (#3).
5
3
1
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 368081 LABEL 3 IN RD BLANK BCKPLT
2 1 366415 SPKR ASSY C803A COAX
3 1 112895 CLAMP, 1/4 CORD NYLON
4 1 200297 TRANS, 70V 5,2,1,.5W 1/2 X 5/8
5 2 113557 SCW, # 8 X .375 STABWHHX ZP
8.07
2.88
