TF MEGA-S
FOLDER
Instruction manual
Be sure to read this manual prior to use
and leave it at the site of us for easy reference!
1
DECLARATION OF CONFORMITY
HEFTER Systemform GmbH, Am Mühlbach 6, 83209 Prien am Chiemsee, Germany, declares that the
following product,
Name of product : Hefter Folder
Models : TF-MEGA-S
complies with the provisions defined by the regulations listed below.
Regulation : Low Voltage Directive 2006/95/EC under EN 60950-1: 2006 Electromagnetic Compatibility
Directive 89/336/EEC and 2004/108/EC under EN 55014-1: 2006, EN 55014-2: 1997+A1: 2001, EN 55011:
2007+A2: 2007, EN 61000-3-2: 2006, EN 61000-3-3: 1995+A2: 2005
KONFORMITÄTSERKLÄRUNG
Die Firma HEFTER Systemform GmbH, mit Sitz in: Am Mühlbach 6, 83209 Prien am Chiemsee, Deutschland,
erklärt hiermit, dass das folgende Produkt
Bezeichnung des Produkts : HEFTER Falzmaschine
Modell : TF MEGA-S
den nachfolgend aufgelisteten Richtlinien entspricht:
Richtlinien : Niederspannungsrichtlinie 2006/95/EG unter EN60950-1: 2006
Richtlinie über die elektromagnetische Verträglichkeit 89/336/EWG und 2004/108/EG unter EN 55014-1:
2006, EN 55014-2: 1997+A1: 2001, EN 55011: 2007+A2: 2007, EN 61000-3-2: 2006, EN 61000-3-3:
1995+A2: 2005
DECLARATION DE CONFORMITE
HEFTER Systemform GmbH, située à Am Mühlbach 6, 83209 Prien am Chiemsee, Allemagne,
déclare que leproduit suivant ;
Nom du produit : Plieuse HEFTER
Modèle : TF MEGA-S
est conforme aux dispositions définies par les réglementations suivantes :
Réglementations : Directive Basse tension 2006/95/CE en application de EN60950-1 : 2006
Directive sur la compatibilité électromagnétique 89/336/CEE et 2004/108/CE en application des normes EN
55014-1: 2006, EN 55014-2: 1997+A1: 2001, EN 55011: 2007+A2: 2007, EN 61000-3-2: 2006, EN 61000-3-
3: 1995+A2: 2005
DICHIARAZIONE DI CONFORMITÁ
HEFTER Systemform GmbH, sita a Am Mühlbach 6, 83209 Prien am Chiemsee, Germania,
dichiara che il seguente prodotto,
Nome del prodotto : Piegatrice HEFTER
Modello : TF MEGA-S
è conforme ai requisiti definiti dalle norme sotto elencate:
Direttiva Bassa Tensione : Direttiva relativa alle apparecchiature a bassa tensione 2006/95/CE in base a EN
60950-1: 2006
Direttiva di compatibilità elettromagnetica 89/336/CEE e 2004/108/CE in base a EN 55014-1: 2006, EN
55014-2: 1997+A1: 2001, EN 55011: 2007+A2: 2007, EN 61000-3-2: 2006, EN 61000-3-3: 1995+A2: 2005
DECLARACIÓN DE CONFORMIDAD
HEFTER Systemform GmbH, con domicilio en Am Mühlbach 6, 83209 Prien am Chiemsee, Alemania,
declara que el producto siguiente :
Nombre del producto : Plegadora HEFTER
Modelos : TF MEGA-S
cumple con lo dispuesto por los reglamentos que se indican a continuación.
Reglamentaciones : Directiva sobre baja tensión 2006/95/CE, según EN60950-1 : 2006
Directiva sobre compatibilidad electromagnética 89/336/CEE y 2004/108/CE según EN 55014-1: 2006, EN
55014-2: 1997+A1: 2001, EN 55011: 2007+A2: 2007, EN 61000-3-2: 2006, EN 61000-3-3: 1995+A2: 2005
2
Disposal of Old Electrical & Electronic Equipment
This symbol (the symbol of the crossed out wheeled bin) indicates that in European
countries this product should not be disposed of as household waste.
Please recycle where facilities exist by checking with your local authority or supplier for
recycling advice.
By ensuring this product is disposed of correctly through proper treatment, recovery and
recycling, you will help prevent potential negative effects on the environment and human
health.
Entsorgung von alten elektrischen und elektronischen Ausrüstungsteilen
Dieses Symbol (das Symbol mit dem durchgekreuzten fahrbaren Müllbehälter) zeigt an, dass dieses
Produkt in europäischen Länden nicht als Haushaltsmüll entsorgt werden darf. Bitte informieren Sie sich
bei Ihren örtlichen Behörden oder bei Ihrem Händler hinsichtlich einer Empfehlung für die Entsorgung und
führen Sie die betreffenden Teile dort, wo solche Einrichtungen vorhanden sind, einem Recycling-Prozess
zu.
Indem Sie sicherstellen, dass das betreffende Produkt durch richtige Behandlung, Rückführung und
Recycling entsorgt wird, tragen Sie dazu bei, möglichen negativen Auswirkungen auf die Umwelt und
die menschliche Gesundheit vorzubeugen.
Elimination du matériel électronique et électrique usagé
Ce symbole (une poubelle marquée d’une croix) indique que dans les pays européens, ce
produit ne doit pas être éliminé comme des ordures ménagères.
Recyclez-le dans les sites adaptés qui vous seront indiqués par les autorités locales ou
renseignez-vous auprès de votre fournisseur.
En veillant à ce que ce produit soit éliminé correctement avec un traitement, une collecte
et un recyclage adaptés, vous contribuez à éviter son action nocive potentielle sur l’
environnement et la santé humaine.
Smaltimento di attrezzature elettriche ed elettroniche consumate
Questo simbolo (il simbolo della pattumiera con rotelle barrata) indica che nei paesi
europei questo prodotto non deve essere buttato nei ri¿uti domestici.Per favore smaltire in luogo addetto al
riciclo, dove esistente, chiedendo informazioni alleautorità locali o a chi fornisce consulenza a proposito.
Garantendo uno smaltimento adeguato di questo prodotto (trattamento, recupero e riciclo
corretto), aiuterete a prevenire effetti negativi sull’ambiente e sulla salute dell’uomo.
Eliminación de residuos de aparatos eléctricos y electrónicos
Este símbolo (un cubo de basura tachado) indica que en los países europeos este producto no deberá
eliminarse como si se tratara de un residuo doméstico. Solicite asesoramiento sobre reciclaje a las
autoridades locales o a su distribuidor, y siga la normativa en materia de gestión medioambiental y
reciclaje de este tipo de residuos.
Si toma las medidas pertinentes para que este producto se elimine mediante un tratamiento,
recuperación y reciclaje adecuados, contribuirá a evitar posibles efectos negativos en el medio
ambiente y la salud humana.
3
Introduction
Thank you for purchasing a Morgana Systems product. This instruction manual helps you to
make sure using the folder TF MEGA-S safely and according to its specifications. Be sure to read
this manual carefully prior to using the TF MEGA-S.
This manual gives you information on the operation of the machine, detailed safety instructions,
information about regular maintenance and error handling.
The folder TF MEGA-S is an office folding machine which is only destined fort he folding of paper.
Any other use is not according to its specifications. The manufacturer/supplier is not liable for any
damage resulting of such un-allowed handling.
The manual should always be ready to hand for any possible reference needed.
This operation manual is a translation of the original version.
Symbols
In this manual, several symbols are used to indicate important warnings. Please make sure to
read instructions accompanied by these symbols. The symbols have the following meanings:
Describes instructions which must be followed during use. Be sure to read the
instructions carefully to avoid any possible problem due to incorrect operations.
Indicates supplementary useful information
Describes names of related items and supplementary instructions
Trademarks
The product name and company name used in this manual are trademarks or registered
trademarks of the respective company.
4
Ignoring this mark could result in the possibility of
serious injury or even death.
Ignoring this mark could result in the possibility
of injury or physical damage.
Safety precautions
Watch the following remarks and warnings during the operation of the machine. This way you will
prevent any possible danger, personal injury or damage of the machine.
Power supply
This unit shall be installed near the socket-outlet where the plug on the power supply cord is easily
accessible.
Make sure the power supply used is always within the following range:
Power supply: 220 – 240 V AC, 50 Hz (EU)
120 V AC, 60 Hz (North America)
If other appliances are powered by the same AC outlet, make sure that the combined power
consumption does not exceed the power supply capacity.
Rated current (Rated power): 0,4 A (EU), 0,85 A (North America)
Warning!
Make sure that the power supply is in accordance with the information on the rating label. Using
other voltage can result in a fire or any other damage of the machine or in an electrical shock.
Make sure that the combined power consumption of the appliances to be connected does not
exceed the capacity rating of the power outlets or plug receptacles. Exceeding the capacity rating
could cause the power outlets, plug receptacles or the power extension cords to overheat and
catch fire.
Ignoring this mark could result in the possibility of
serious injury or even death.
Ignoring this mark could result in the possibility of
injury or physical damage.
This mark indicates a „Warning“ or „Caution“.
A graphic may be shown inside the mark to describe the warning or caution more specifically.
This mark indicates a forbidden action.
A graphic may be shown inside the mark to describe the warning or caution more specifically.
This mark indicates actions that must be performed.
A graphic may be shown inside the mark to describe the action to be performed more specifically.
WARNING
CAUTION
5
Operating environment
Operate this unit in the following environment:
Temperature: +5°C up to +35° (storage temperature -10°C up to +50°C)
Humidity: 20% up to 85% (storage: 10% up to 90% rel. humidity) no condensation
No direct sunlight
Reasonably free from dust
subject to only little or no vibration
free from air-borne salt
no harmful chemicals
the machine may not be exposed to water
Warning:
Keep this unit and the power cord away from heaters and heater vents. Excessive heat could melt
the cover or power cord covering and result in a fire or an electrical shock.
Do not place metal objects or bins containing liquids on top of the machine. The entry of any metal
object or liquid could result in a fire or an electrical shock.
Do not insert any metal or easily-flammable objects inside the machine. This could result in a fire or
an electrical shock.
Do not use flammable sprays inside or near the machine (e.g. when cleaning the unit). Such
flammable gas may ignite and cause a fire or combustion.
Caution:
Do not install this machine at a location with excessive humidity or where contact with water is
possible. This could result in deterioration of the insulation, a fire or an electrical shock.
Install this unit on a level, stable stand or floor with sufficient space around it. Failure to do so could
result in the unit overturning and causing injury.
Disconnect the power plug from the power outlet before attempting to move the machine. Failure to
do so could result in power cord damage, a fire or an electrical shock.
Always disconnect the power plug from the power outlet when the unit is not to be used for an
extended period of time. Failure to do so could result in a fire to leakage current if the insulation
should deteriorate.
6
Warning:
Do not damage the power cord or power plug. Do not scratch, alter, bend, twist, pull or place heavy
objects on the power cord or power plug. This could result in damage, a fire or an electrical shock.
Do not touch the power switch with wet hands. Otherwise electric hazards may occur.
Do not remove the cover or back panel. This unit contains high-voltage components that could
cause an electrical shock.
Do not disassemble, modify or repair this machine. There is a danger of fire, electrical shock or
injury. Contact 0RUJDQD6\VWHPV when repairs are necessary.
If any foreign objects such as metal or liquid should enter this unit, immediately turn the unit off at
the power switch and disconnect the power plug from the power outlet. Failure to do so could result
in a fire or an electrical shock. Contact your dealer immediately.
Before cleaning this unit, turn the unit off at the power switch and disconnect the power plug from
the power outlet. Accidental operation of the unit during cleaning could result in injury.
Remove any dust that accumulates on the power plug prongs and the surface of the plug from
which the prongs extend. Accidental operation of the unit during cleaning could result in injury.
Always grip the plug when disconnecting the power plug from the power outlet. Forcibly pulling on
the power cord could cause damage, resulting in a fire or an electrical shock.
Do not touch or insert foreign objects into any rotating part during operation. This could result in
injury!
7
Labels „Warning“ / „Caution“
For your own safety there are labels with safety instructions on the fixed on the
machine:
WARNING
CAUTION
These labels may not be removed or changed. If a label gets dirty, breaks or gets
lost, it must be replaced immediately. You can get a new label from Morgana
Systems or an authorized dealer.
For safety reasons you may only use the specified mains fuse!
The mains fuse may only be replaced by a fuse as described on the label!
Do not grip into the machine during operation.
Long hair, clothes such as ties and jewellery
can be grasped during operation!
8
Index
Introduction.................................................................................................................... 3
Safety precautions .............................................................................................................. 4
Power supply......................................................................................................................... 4
Operating environment.......................................................................................................... 5
Maintenance / additional information..................................................................................... 5
Label „WARNING“ /„CAUTION" ............................................................................................ 6
Chapter 1
Before operation
1. Features .......................................................................................................................... 10
2. Installation ....................................................................................................................... 11
1. Standard components ............................................................................................. 11
2. Press release lever ……………. ............................................................................. 11
3. Installing parts ..................................................................................................... 11
3. Names and functions....................................................................................................... 12
4. The control panel............................................................................................................. 13
5. The stacking device......................................................................................................... 13
6. Handling the paper .......................................................................................................... 14
1. Using the paper....................................................................................................... 14
2. Precautions on stacking paper................................................................................ 14
Chapter 2
Basic operation
1. Switching on..................................................................................................................... 15
2. Adjusting the paper width................................................................................................. 15
3. Inserting the paper ........................................................................................................... 16
4. Selecting the fold type...................................................................................................... 16
5. Adjusting the stacking rollers
6. Operation ......................................................................................................................... 16
1. Working with pre-counter ........................................................................................ 17
2. Working with counter............................................................................................... 17
3. After operation......................................................................................................... 17
9
Chapter 3
Maintenance and cleaning of the machine
1. Cleaning the rubber roll ................................................................................................... 18
2. Cleaning the paper feed rings ......................................................................................... 18
3. Cleaning the sensor......................................................................................................... 18
4. Cleaning the paper separator pad ................................................................................... 18
Chapter 4
Trouble shooting guide
1. Paper empty ................................................................................................................... 19
2. Cover open ...................................................................................................................... 19
3. Fold plate 1 absent (plate-1 set err) ................................................................................ 19
4. Fold plate 2 absent (plate-2 set err) ................................................................................ 19
5. Paper jam at paper receiving (Paper jam / empty) .......................................................... 20
6. Paper jam at paper feeding station (Paper jam / empty) ................................................. 20
7. No illumination at LCD display ........................................................................................ 20
8. Paper is not fed ............................................................................................................... 20
9. Paper gets stuck in the fold plates................................................................................... 21
10. The paper is not folded parallely .................................................................................... 21
Chapter 5
Appendix
1. Technical specifications................................................................................................... 22
Indice
Altri manuali Morgana Macchina piegatrice
Morgana
Morgana UFO Manuale
Morgana
Morgana MB300 XL Pro Manuale utente
Morgana
Morgana DigiFold Pro Manuale utente
Morgana
Morgana Digifold Pro CB Manuale utente
Morgana
Morgana Square fold 104 Manuale utente
Morgana
Morgana Digifold 5000P Manuale utente
Morgana
Morgana AutoFold Pro Manuale utente
Morgana
Morgana DocuFold Pro Manuale utente
Morgana
Morgana DIGIFOLD Manuale utente
Morgana
Morgana AutoFold Pro Manuale utente
