mothercare xcursion Manuale utente
xcursion
travel system
user guide
IMPORTANT. KEEP FOR FUTURE REFERENCE
IMPORTANT: Read these instructions carefully before use and keep them for future reference.
Your child’s safety may be affected if you do not follow these instructions.
This vehicle is intended to carry a single child from birth and up to a maximum weight of 15kg.
The xcursion features a reversible seat unit, reclining backrest, adjustable footrest, lockable
front swivel wheels and shopping basket. The shopping basket is intended to carry an evenly
distributed maximum load of 4.5kg (9.9lbs). Built in adaptors enable the xcursion infant carrier to
be fitted to the pushchair.
Safe travelling advice for you and your baby
Pushchairs are an ideal way of transporting your baby. It is important to remember however,
that during their first 3 months, babies should be spending most of their day lying flat for
comfort and development.
introduction
parts checklist
1
fig 1a
fig 1b
fig 1c
fig 1d
fig 1e
chassis frame
fabric seat unit
front wheels
rear wheels
bumper bar
fig 1f
fig 1g
fig 1h
fig 1i
weathershield
apron
hood
i
footmuff
2
parts checklist
unfolding the chassis
fig 1
Remove all packaging materials lay chassis on floor
as shown.
Unfasten the folding latch on the side of the chassis.
fig 2
Step down onto basket to open. Ensure that the
product has been locked out on both sides of the
frame to the red line.
fig 3
unfolding the chassis
fig 4
Attach the front wheels as shown. Ensure the swivel
lock is on the outside.
R
R
L
L
3
preparation for use
fitting the rear wheels
fig 5
Press the wheel release button and attach the rear
wheel as shown. Pull to make sure they are fully
attached.
attaching the seat unit
fig 6
Attach seat unit to the chassis as shown. Check the
seat unit is securely attached before use.
attaching the hood
fig 7
Attach the hood as shown.
4
preparation for use
attaching the bumper bar
fig 8
Attach the bumper bar as shown. Check that it is
securely attached on both sides.
in use
securing your child
fig 9
WARNING. Ensure your child wears a correctly fitting
harness at all times.
To fasten, insert both fasteners securely into the
clasp.
Adjust each strap length with buckles A.
fig 10
To release, press the fastener prongs and pull apart.
'D' rings (B) are provided for fitting a separate
harness complying with BS6684 or BS EN 13210.
Your child should be securely harnessed at all times
and should never be left unattended, even for short
periods.
WARNING. Always use the crotch strap in
combination with the waist belt.
5
in use
using the parking brake
fig 11
To engage the parking brake step down on the
rear peddle to stop the stroller moving whilst in a
stationary position. Check that the brakes have
engaged correctly by gently pushing the stroller. Pull
up to release the brakes.
locking the front wheel
fig 12
To lock front wheels, straighten them and push the
lock across at the side of the wheel.
To unlock the wheels push the lever back.
adjusting the footrest
fig 13
To adjust the footrest, press the buttons on either
side and rotate as required.
6
in use
reclining the seat unit
fig 14
Release the lever and recline the seat as required.
reversing the seat unit
fig 15
Push the buttons inwards as shown on each side
and lift the seat unit away from the frame.
fig 16
Turn the seat unit around and replace into the
adaptors until you hear a ‘click’.
7
in use
adjusting the handle
fig 17
Push the button “1” on the underside of the handle to
the right at the same time press the larger plastic
button “2”.
Adjust the handle as required.
fig 18
fig 19
attaching the apron
fig 20
Attach the apron by pushing in the press studs on
either side of the pushchair.
8
in use
using the footmuff
fig 21
Fit the footmuff to the seat unit by pulling the safety
harness through the holes in the liner.
The front of the footmuff may be removed for use in
warmer weather.
fitting the weathershield
fig 22
Fit the weathershield over the pushchair and attach
to the frame with the velcro tabs.
attaching the infant carrier
fig 23
Attach the infant carrier to the chassis as shown
(front or rear facing). Please ensure that it is securely
attached to the frame before use.
9
after use
removing the bumper bar
fig 24
Push bumper bar pins in on both sides and pull up
to remove as shown.
removing the hood
fig 25
Remove the hood as shown.
removing the seat unit
fig 25
Push the buttons inwards as shown on each side
and lift the seat unit away from the frame.
