USER’S GUIDE
HD Dash Cam with Wi-Fi® For Road or
In-Car Monitoring
Model: MDC10W
The features described in this user’s guide are subject to
modifications without prior notice.
This User’s Guide has all the information you need
to make the most out of your product.
Please read the Safety Instructions on page 5
before you install the unit.
Before you use the Dashboard Camera, we
recommend you insert a SD card into the SD card
slot.
Got everything?
• Dashboard Camera
• Suction Mount
• Sun Visor Mount
• Car Adapter
• User Manual
Thank you for purchasing the Dashboard Camera. The
Dashboard Camera is designed to let you record each
and every instant while you are on the road, and
manage your recordings via Hubble Dashcam app.
Please keep your original dated sales receipt for your
records. For warranty service of your Motorola
product, you will need to provide a copy of your dated
sales receipt to confirm warranty status. Registration
is not required for warranty coverage.
For product related questions, please call:
+44 (0) 844 557 0890 (UK only)*
*Calls cost 7p per minute plus your telephone company's access charge
Mon - Fri 8:00am to 8:00pm
Sat 8.30am to 2:00pm
+44 (0) 8187 62092 (ROI)
On the Web: www.motorolastore.com/support
Email: [email protected]
Welcome...
to your new Motorola Dashboard Camera!
Overview of your Dashboard Camera
1
3
4
567
8
2
1.
Lens
Wide Angle 140°
2.
microSD card slot
Insert a microSD card here.*
3.
DC-IN & USB Socket
Connect the car adapter or
USB data cable here.
4.
Recessed Reset Button
In the unlikely event
MDC10W becomes
unresponsive, insert a pin
into the hole to reset
MDC10W.
5.
Mounting Nut
Screw in the supplied
Suction Mount or Sun Visor
Mount here.
6.
Power Button and Indicator
Press and hold for 3
seconds to turn MDC10W
On / Off.
Red light: Charging
Blue light flashing:
Recording
7.
Microphone
Integrated microphone for
audio recording.
8.
Speaker
*
Make sure the printed side of the
card is facing the right direction as
shown.
4 Table of contents
Table of contents
1. Safety Instructions........................................................ 5
2. Getting Started.............................................................. 6
2.1 Installing your Device .............................................. 6
2.2 Basic Use....................................................................... 8
3. Connecting Devices.................................................... 10
3.1 System Requirements............................................ 10
3.2 Install Hubble Dashcam App ............................. 10
3.3 Connect your smartphone to MDC10W ......... 10
3.3.1 On Android Smartphone ....................... 10
3.3.2 On iOS Smartphone .................................13
4. Manage your recordings.............................................15
5. Manage downloaded photos and videos ..............20
6. Main features and Settings ....................................... 22
6.1 Recording and Saving ...........................................22
6.2 Mass Storage Mode ................................................22
6.3 Parking Mode ............................................................23
6.4 G-sensor / File Protection....................................23
6.5 Automatic Start / Stop ........................................ 24
7. Other settings .............................................................. 25
7.1 Change Wi-Fi password .......................................25
7.2 Language Settings..................................................25
7.3 Device key sound ....................................................25
7.4 Audio recording.......................................................25
7.5 White Balance...........................................................25
7.6 Exposure .....................................................................26
7.7 Restore default settings .......................................26
7.8 Restore Wi-Fi password .......................................26
8. Disposal of the Device (Environment)................... 27
9. General Information ................................................... 28
10. Technical Specifications............................................35
Safety Instructions 5
ENGLISH
1. Safety Instructions
WARNING
• Do not install the device within the driver’s or
passenger airbag operation range. Please refer
to your car’s service manual for details about
the operation range of your car’s airbags.
• Never modify modes, settings, or program
your device while your car is in motion.
• Ensure the device and its power cord are
installed as per the instructions on page 6, and
do not obstruct the driver’s line of sight or
impede the operation of any driving controls.
6 Getting Started
2. Getting Started
2.1 Installing your Device
The above illustration refers to a left-hand drive car. For
right-hand drive cars, please flip the position of the cable
installation accordingly.
• Install your device within the rear-view mirror
area and within the wiper cleaning area to get
the clearest possible view.
• Your device comes with a 3.6m USB power
cable. Organise the power cord so that it
does not interfere with the driver's vision. Use
cable clips to secure the power cord if
necessary.
Best Installation Location
Getting Started 7
ENGLISH
• There are two ways to install MDC10W in your
car:
1. Screw the MDC10W into
the mounting bolt of the
Suction mount.
2. Press the suction cup of
the Suction mount against
the windshield, and press
the lever to lock. Ensure
that the mount is safely
attached to the windshield.
3. Set your desired recording
angle and lock into position
by tightening the lock nut.
Suction mount
1. Screw the MDC10W into
the mounting bolt of the
Sun visor mount.
2. Push the clip of the Sun
visor mount to the sun
visor.
Sun visor mount
8 Getting Started
• When using the dashboard camera in your
car, we recommend that you always use the
cigarette lighter car adapter in order to
maintain the battery level. The unit is not
designed to run on battery power alone, the
battery is there for backup purposes only.
2.2 Basic Use
• Your dashboard camera will only record when
an SD card is inserted.
• Insert a micro SD card (not provided) into the
SD card slot. Your dashboard camera accepts
SD cards of up to 32GB capacity (class 10).
It is necessary that you format the SD card
when using it for the first time.
Note
The above information is for your reference
only. Different memory cards and different
video resolutions will result in different
recording time.
• Your dashboard camera will always power up
and begin loop recording automatically as soon
Card Capacity Estimated recording
time* (minutes)
4GB 20
16GB 80
32GB 160
Getting Started 9
ENGLISH
as it is connected to a power source.
Simply connect your dashboard camera to a
power source that comes on when you start the
engine of your vehicle, and the dashboard
camera will start loop recording automatically
(Blue light flashing) without you having to
remember to press on a button.
• To stop recording to protect your privacy, press
and hold the power button to shut down the
device.
10 Connecting Devices
3. Connecting Devices
3.1 System Requirements
Smartphones: Android™ (Android™ 5.0 or
higher) and iOS® (iOS 10) only.
3.2 Install Hubble Dashcam App
Hubble Dashcam App is available for free
download from Google Play Store (Android)
and the App Store (iOS).
The App can easily be found by searching for
"Hubble Dashcam" in your chosen store. Once
installed, Hubble Dashcam App will be available
on your smartphone.
3.3 Connect your smartphone to
MDC10W
Connecting your smartphone to the MDC10W
works similarly as connecting your smartphone
to a Wi-Fi network.
First, make sure that your MDC10W is powered
on by the car adapter (Red light on and Blue
light flashing).
3.3.1 On Android Smartphone
1. Open Hubble Dashcam app on your
smartphone.
