Motorola Netopia 3387WG-VGx Manuale utente

DATA SHEET

Full-featured wireless router for the savvy home networker or ambitious

small business

Netopia® 3387WG-VGx

4-port Ethernet High-Performance Wireless Gateway

The 3387WG-VGx gateways support the DSL

Forum’s TR-069 specification for comprehensive

remote manageability, which gives service providers

many options for managing the device to receive

updates without consumer interaction.

PRODUCT OVERVIEW

Performance Optimized. The Motorola Netopia

3387WG-VGx 4-port Ethernet High-Performance

Wireless Gateways are designed for the home user

who needs to setup a home network for maximum

media play or for a small, networked office to

conduct essential business activities.

The 3387WG-VGx allows users to connect their

existing DSL or cable modem to an Ethernet port

and then use up to four 10/100 Ethernet ports and

an 802.11b/g wireless access point.

Highlights

Four-port Ethernet switch

supports single-PC

households and home- or

small-office networking

3D Reach®Extreme

technology for increased

Wi-Fi®range and

performance

Perfect wireless gateway

for a GPON multi-user

deployment

Friendly installation for

simple setup

Robust security features

protect PCs and other

networked devices from

unwanted intrusions

Advanced features help

service providers monetize

broadband networks while

improving efficiency and

reducing costs

DATA SHEET

Netopia®3387WG-VGx

4-port Ethernet High-Performance Wireless Gateway

Hardware Features

WAN INTERFACE

10/100 Ethernet, RJ-45

LAN INTERFACE

Built-in 802.11b/g Wireless

Four-port 10/100 Ethernet Switch, RJ-45

LEDS: POWER, LINK, STATUS INDICATORS

Power, Link, Status Indicators

PROTOCOL SUPPORT

Bridged or Routed Ethernet Encapsulation

IP Multicast Pass-through

BRIDGING/ROUTING FUNCTIONS

Network Address Translation (NAT), IP Maps, and Pinholes

Static Routes

IP Multicast Outbound Support Through NAT

DHCP Client, Server, and Relay

DNS Proxy

RIP1 and RIP2 on LAN/WAN

SECURITY

Network Address Port Translation (NAPT)

Stateful Firewall

Configurable Firewall Function

Virtual DMZ/IP Pass-through

Denial of Service Protection

Software and Games Control

VPN Pass-through for PPTP, L2TP, and IPSec

IPSec VPN Gateway (upgrade)

DES, 3DES, and IKE

Hash Algorithm Support: MD5 and SHA1

WIRELESS

Antennas Integrated omni-directional

with diversity support

3-D Reach Wi-Fi transmit power North America100 mW

Wi-Fi Multimedia (WMM)

Channel Set North America1-11

Supported Data Rates 1, 2, 5.5, 6, 9, 11, 12, 18, 24,

36, 48, 54 Mbps with

auto-rate fallback

Wireless Security WEP 64-, 128-, 256-bit encryption

802.1x, WPA, WPA-PSK,

802.11i/WPA2

Block Wireless Bridging

MAC Address Filtering Transmit Power Control

QOS AND TRAFFIC MANAGEMENT

VGx Virtual Gateway Technology

Diffserv – Differentiated Services

IEEE 802.1p – Priority Bits

IEEE 802.1q – VLAN Tagging

IGMP v2/v3 Snooping/Forwarding

with Fast Leave

TR-111 Support

DEVICE MANAGEMENT

TR-069 Remote Management

Remote and Local Management Options via web UI (HTTP)

and CLI (Telnet)

Two-Level Password Protected Access

Statistic and Log Reporting, Remote Syslog Support

Seven-layer Layer Diagnostics

SNMP v1 and v2

Utilities: Ping, Traceroute, Reverse DNS

The Motorola Netopia

3300 Residential Series

Ethernet Gateway

(3387WG-VGx)

The 3387WG-VGx is an

Ethernet router that

connects to your existing

broadband modem,

creating an expandable

wireless network to run

multiple computers and

wireless-enabled network

devices. Although only an

Ethernet gateway, the

3387 is equipped with all

the functionality of the

3300 Series gateways.

Motorola, Inc. 101 Tournament Drive, Horsham, Pennsylvania 19044 U.S.A. www.motorola.com

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. Netopia is a registered trademark of Netopia, Inc., a wholly-owned subsidiary of

Motorola, Inc. Wi-Fi is a registered trademark and Wi-Fi Protected Setup is a trademark of Wi-Fi Alliance. Windows is a registered trademark and Vista is a trademark of

Microsoft Corporation in the U.S. and/or other countries. All other product or service names are the property of their respective owners.

548528-001-a 03/08 5879 - 0K

DATA SHEET

Netopia®3387WG-VGx

4-port Ethernet High-Performance Wireless Gateway

REGULATORY

FCC Part 68, Part 15, Class B

UL Listed, CSA Approval

European EMC and Immunity

CE Mark

Industry Canada

ENVIRONMENTAL

Operating Temperature: 32 °F to 104 °F (0 °C to 40 °C)

Storage Temperature: 32 °F to 158 °F (0 °C to 70 °C)

Relative Humidity: 20% to 80% (Non Condensing)

WEIGHT AND DIMENSIONS

Weight: 2.5 lbs (1,134g) (unit carton)

Dimensions: 1.5 in H, 7.7 in L, 6.7 in W

(3.9 cm x 19.6 cm x 17.1 cm)

COMPATIBILITY

PC Windows®98, 98SE, ME,

2000, XP SP2, and Vista™

Macintosh Ethernet connection
