Motorola SURFboard SB4000 Manuale utente

High-Speed Access to the Internet

SURFboard

Cable Modem

SURFboard SB4000 User Guide

Regulatory Information

Federal Communications Commission Radio and Television Interface Statement for a Class 'B' Device.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of

the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in the

residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular installation.

If the equipment does cause harmful interference to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:

!Increase the separation between the equipment and the affected receiver

!Connect the equipment on a circuit different from the one the receiver is on

You may find the following booklet, prepared by the Federal Communication Commission, helpful:

How to Identify and Resolve Radio-TV Interference Problems

Stock No. 004-000-0342-4,

U.S. Government Printing Office

Washington, DC 20402

Changes or modification not expressly approved by the party responsible for compliance could void the user's

authority to operate the equipment.

This product was FCC compliant under test conditions that included the use of the supplied cable between system

components. To be in compliance with FCC regulation, the user must use this cable and install it properly.

Declaration of Conformity

According to 47CFR, Parts 2 and 15 for Class B Personal Computers and Peripherals; and/or CPU Boards and Power

Supplies used with Class B Personal Computers, Motorola BCS, 6450 Sequence Drive, San Diego, CA 92121,

1-800-225-9446, declares under sole responsibility that the product identifies with 47CFR Part 2 and 15 of the FCC

Rules as a Class B digital device. Each product marketed is identical to the representative unit tested and found to be

compliant with the standards. Records maintained continue to reflect the equipment being produced can be expected

to be within the variation accepted, due to quantity production and testing on a statistical basis as required by 47CFR

2.909. Operation is subject to the following condition: This device must accept any interference received, including

interference that may cause undesired operation. The above named party is responsible for ensuring that the

equipment complies with the standards of 47CFR, Paragraph 15.101 to 15.109. The Class B digital apparatus meets

all requirements of the Canadian Interference-Causing Equipment Regulations.

iii

The SB4000 meets one or more of the standards listed:

Declaration of Conformity

Motorola, Inc.

Broadband Communications Sector

6450 Sequence Drive

San Diego, CA, U.S.A.

Declare under our sole responsibility that the

SURFboard Cable Modem Model SB4000

To which the declaration relates is in conformity with the following standards:

EN55022 EN55024 EN60950

CISPR 22 CISPR 24 IEC950: 1991 + A1 : 1992 + A2 : 1993 + A3 : 1995 + A4 : 1996

Following the provisions of the Directive(s) of the Council of the European Union:

EMC Directive 89/336/EEC Low Voltage Directive 73/23/EEC

Canadian Compliance

This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.

Cet appareil numérique de la classe B respects toutes les exigences du Règlement sur le matériel brouilleur du

Canada.

Warning

TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

Caution

THESE SERVICING INSTRUCTIONS ARE FOR USE BY QUALIFIED PERSONNEL ONLY. TO REDUCE THE RISK

OF ELECTRICAL SHOCK, DO NOT PERFORM ANY SERVICING OTHER THAN THAT CONTAINED IN THE

INSTALLATION AND TROUBLESHOOTING INSTRUCTIONS UNLESS YOU ARE QUALIFIED TO DO SO. REFER

ALL SERVICING TO QUALIFIED SERVICE PERSONNEL.

Repairs

If this falls within the Motorola warranty, contact Motorola (see the Limited Warranty in the back of this User Guide).

No part of this publication may be reproduced in any form or by any means or used to make any derivative work (such

as translation, transformation or adaptation) without written permission from Motorola, Inc.

Motorola, Inc. reserves the right to revise this publication and to make changes in content from time to time without

obligation on the part of Motorola, Inc. to provide notification of such revision or change. Motorola, Inc. provides this

guide without warranty of any kind, either implied or expressed, including, but not limited, to the implied warranties of

merchantability and fitness for a particular purpose. Motorola, Inc. may make improvements or changes in the

product(s) described in this manual at any time.

MOTOROLA, the stylized M logo and SURFboard are registered trademarks, and the SURFboard logo is a trademark

of Motorola, Inc.

Acrobat Reader software is provided subject to the Adobe Systems, Inc. Software End User License Agreement

included on the CD-ROM. Acrobat is a registered trademark of Adobe Systems, Inc. in the United States and/or other

All other product or service marks are the property of their respective owners.

Introduction Get Started Installation Diagnostics Troubleshooting Glossary/FAQ Legal

Home Print Exit

Open your PC once -

clear your desk forever!

Introduction

Congratulations, you now have the newest innovation in Internet access, a cable modem

inside your computer. This cable modem is easy to install, has all the functionality of an

external cable modem, and saves valuable work space.

More than that, the SB4000 SURFboard internal cable modem is better than traditional

telephone or ISDN modems:

!Built on leading edge hardware that supports automatic software upgrades through

your cable service provider

!Doesn’t tie up your telephone line

!Fast and always on

!Runs on computer power, no extra power plugs

!Install in just three easy steps

Introduction Get Started Installation Diagnostics Troubleshooting Glossary/FAQ Legal

Home Print Exit

Get Started

We know that not everyone is familiar with the technical terms in this User Guide, so we

have included a Glossary in the back of this manual for your convenience.

Contact Your Cable Service Provider

Before you begin installing your SB4000 internal cable modem, take a few minutes to:

1 Record the media access control (MAC) address and serial numbers from the bar

code label marked HFC MAC ID on the cable modem, or on the box it came in.

The address format is 00:20:40:xx:xx:xx.

Keep this in a safe place, you may need it at a later date.

2 Sign up for Internet cable service with your local service provider. They will ask you

for the MAC address and serial numbers you’ve recorded.

Introduction Get Started Installation Diagnostics Troubleshooting Glossary/FAQ Legal

Home Print Exit

Questions for Your Cable Service Provider

!When can you begin using your cable modem?

!Do you need a new browser or plug-in to use their service?

!Do you need a user name or password to access the Internet or use Email?

Gather These Items

Gather these items before you begin installing the cable modem:

!PCI cable modem in its protective sleeve

!Your PC User Guide

!Your PC Operating System disk (may be required)

!75-ohm coaxial cable with F-type connectors to connect the cable modem to the

cable outlet

!5-900 MHz cable splitter (may be required if connecting additional electronics to the

same cable outlet)

!Phillips screwdriver and/or a flat-blade screwdriver

Introduction Get Started Installation Diagnostics Troubleshooting Glossary/FAQ Legal

Home Print Exit

If you plan to video conference, check with your

cable service provider for minimum computer

requirements.

Check Your PC

The SB4000 is compatible with Microsoft®operating systems:

!Windows®98

!Windows 2000

!Windows Me

We do not support use of this product with MacIntosh, UNIX, Microsoft operating

systems before Windows 98, or other operating systems.

Check that your PC meets these minimum requirements:

!Pentium®133 MHz processor

!32 MB RAM for Windows 98 or Windows Me

!64 MB for Windows 2000

!CD-ROM drive

!One free PCI slot

!VGA resolution monitor (640 x 480)

If you are not sure if your computer meets these requirements, check your PC manual.
