Introduction

This document supports the DSP96002 Application Development Module

(DSP96002ADM), including a description of its basic structure and operation, the

equipment required to use it, the specifications of the key components, schematic

diagrams, and a parts list. Section 1 is a Quick Start Guide. Section 2 provides detailed

information about key components in the evaluation module. Appendix A has detailed

schematics.Appendix B lists the Bill Of Materials (BOM) for the board. Detailed

information is provided in the additional documents supplied with this kit.

MOTOROLA DSP96002ADMUM/AD, Preliminary iii

TABLE OF CONTENTS

SECTION 1 QUICK START GUIDE. . . . . . . . . . . . . . . . . . . . . . . . . 1-1

1.1 OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

1.2 EQUIPMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

1.2.1 What You Get with the DSP96002ADM . . . . . . . . . . . . . . . . 1-3

1.2.2 What You Need to Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

1.3 INSTALLATION PROCEDURE . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

1.3.1 Preparing the DSP96002ADM. . . . . . . . . . . . . . . . . . . . . . . . 1-5

1.3.2 Connecting the DSP96002ADM to the PC and Power . . . . . 1-8

1.4 USING THE DSP96002ADM . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8

SECTION 2 DSP96002ADM TECHNICAL SUMMARY. . . . . . . . . . 2-1

2.1 DSP96002ADM DESCRIPTION AND FEATURES . . . . . . . . . . 2-3

2.2 DSP96002 DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

2.3 EXTERNAL/INTERNAL RESET INPUT. . . . . . . . . . . . . . . . . . . 2-5

2.4 CONFIGURING THE DSP96002ADM . . . . . . . . . . . . . . . . . . . . 2-5

2.4.1 Operating Mode Selection. . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8

2.4.2 External IRQA/IRQB/IRQC Input Path. . . . . . . . . . . . . . . . . . 2-9

2.4.3 DSP96002 Port A/B User EPROM Decoders . . . . . . . . . . . 2-10

2.4.4 DSP96002 Port A/B User SRAM Decoder/Partitions . . . . . 2-11

2.4.5 Clock Input Selection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13

2.4.6 Transfer Acknowledge (TA) Pullup/Pulldown Option. . . . . . 2-13

2.4.7 Bus Grant (BG) Pullup/Pulldown Option . . . . . . . . . . . . . . . 2-13

2.5 DSP96002 ADM CONNECTOR DESCRIPTIONS. . . . . . . . . . 2-14

APPENDIX A DSP96002ADM SCHEMATICS. . . . . . . . . . . . . . . . . . A-1

APPENDIX B DSP96002ADM BILL OF MATERIALS. . . . . . . . . . . .B-1

B.1 DSP96002ADM—ELECTRICAL PARTS LIST

REV. 1.8 --10/20/93 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3

B.2 DSP96002ADM—HARDWARE PARTS LIST

REV. 1.8 --10/20/93 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-4

iv DSP96002ADMUM/AD, Preliminary MOTOROLA

LIST OF FIGURES

Figure 1-1 DSP96002ADM Key Component Layout . . . . . . . . . . . . . . . . . . . . . .1-6

Figure 1-2 Application Development . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-8

Figure 2-1 DSP96002ADM Functional Block Diagram . . . . . . . . . . . . . . . . . . . .2-4

Figure 2-2 DSP96002ADM Key Component Layout . . . . . . . . . . . . . . . . . . . . . .2-6

MOTOROLA DSP96002ADMUM/AD, Preliminary v

LIST OF TABLES

Table 1-1 DSP96002ADM Default Jumper Options . . . . . . . . . . . . . . . . . . . . . 1-7

Table 2-1 DSP96002ADM Jumper Functions . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7

Table 2-2 Operating Mode Selection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8

Table 2-3 External IRQA/IRQB/IRQC Input Path . . . . . . . . . . . . . . . . . . . . . . . 2-9

Table 2-4 Port A/B User EPROM Decoder . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10

Table 2-5 Port A/B User EPROM Selection. . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11

Table 2-6 Port A/B User SRAM Decoder. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12

Table 2-7 Port A/B User SRAM Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12

Table 2-8 Clock Input Selection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13

Table 2-9 DSP96002 ADM P1/J3 Port A Connector . . . . . . . . . . . . . . . . . . . . 2-14

Table 2-10 DSP96002 ADM P2/J4 Port B Connector . . . . . . . . . . . . . . . . . . . . 2-15

vi DSP96002ADMUM/AD, Preliminary MOTOROLA

MOTOROLA DSP96002ADMUM/AD, Preliminary 1-1

SECTION 1

QUICK START GUIDE

1-2 DSP96002ADMUM/AD, Preliminary MOTOROLA

Quick Start Guide

1.1 OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3

1.2 EQUIPMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3

1.2.1 What You Get with the DSP96002ADM . . . . . . . . . . . . . . . . .1-3

1.2.2 What You Need to Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4

1.3 INSTALLATION PROCEDURE. . . . . . . . . . . . . . . . . . . . . . . . . .1-4

1.3.1 Preparing the DSP96002ADM . . . . . . . . . . . . . . . . . . . . . . . .1-5

1.3.2 Connecting the DSP96002ADM to the PC and Power . . . . . .1-8

1.4 USING THE DSP96002ADM. . . . . . . . . . . . . . . . . . . . . . . . . . . .1-8

Quick Start Guide

Overview

MOTOROLA DSP96002ADMUM/AD, Preliminary 1-3

1.1 OVERVIEW

The Motorola Application Development System is a tool used to design and test complex

software applications and hardware products using a specific Motorola DSP chip. The

related Application Development Modules (ADMs) contain the DSP chip and related

hardware used for bench development and test. Detailed information about the content

and use of the Application Development System is provided in the Application

Development System User’s Manual (order # DSPADSUM/AD). This manual provides

specific information about the DSP96002 Application Development Module

(DSP96002ADM). This section provides a summary description of the DSP96002ADM,

additional requirements, and quick installation information. Detailed information about

the DSP96002ADM design and operation is provided in the remaining sections of this

manual.

1.2 EQUIPMENT

The following section gives a brief summary of the equipment required to use the

DSP96002 Application Development Module (DSP96002ADM), some of which will be

supplied with the module, and some of which must be supplied by the user.

1.2.1 What You Get with the DSP96002ADM

The following materials are provided with the DSP96002ADM:

• DSP96002 Application Development Module board

• DSP96002ADM Product Information

• DSP96002ADM User’s Manual (this document)

• Motorola Digital Signal Processor Registration Form

1-4 DSP96002ADMUM/AD, Preliminary MOTOROLA

Quick Start Guide

Installation Procedure

1.2.2 What You Need to Supply

• Motorola Application Development System with appropriate host interface card

• Host Computer system:

– PC-compatible computer (386 class or higher) running PC-DOS or MS-DOS

version 5.0 or later with 8 Mbytes RAM, one open 16-bit ISA expansion slot,

free I/O addresses ($100–$102, $200–202, or $300–$303), CD-ROM drive, hard

drive with 4 Mbyte of free disk space, and a mouse

– Sun Microsystems Sun 4 Workstation running Sun Operating System Release

4.1.1 or later (or Solaris Release 2.5 or later), one open SBus expansion slot,

CD-ROM drive, and a mouse

– Hewlett Packard HP7xx Workstation running HPUX Version 9.x (Version 10.x

is not supported), one open EISA expansion slot, CD-ROM drive, and a

mouse.

1.3 INSTALLATION PROCEDURE

Installation requires the following steps:

1. Using information provided in the Motorola Application Development System

User’s Manual, install the Motorola Application Development System in the host

computer.

2. Prepare the DSP96002ADM board

3. Connect the board to the external Command Converter card
