Motorola FOCUS88 Manuale utente
USER’S GUIDE
Wi-Fi®Home Video Camera
Models: FOCUS88
The features described in this user’s guide are subject to modifications without prior notice.
This User’s Guide has all the information you need to make the most out of your
product.
Please read the Safety Instructions on pages 5 - 6 before you install the unit.
Inside the Box
• 1 x Wi-Fi®Camera Unit
• 1 x Power Adapter
• 1 x Quick Start Guide
Welcome...
to your new Motorola Wi-Fi
®
Home Video Camera!
Thank you for purchasing your new Motorola Wi-Fi®Home Video Camera.
If you have always wondered what happens when you are away, wonder no
more. Now you can monitor your children, pets or property with this easy to use
system. You can install the Camera only from your iPhone®/iPad®or Android™
devices and view the Camera video from your PC or Notebook, as well as from
your iPhone®/iPad®or Android™ devices.
Please keep your original dated sales receipt for your records. For warranty
service of your Motorola product, you will need to provide a copy of your dated
sales receipt to confirm warranty status. Registration is not required for warranty
coverage.
For product related questions, please call:
+44 (0) 844 557 0890 (UK only)*
*Calls cost 7p per minute plus your telephone company's access charge
+44 (0) 8187 62092 (ROI)
On the Web: www.motorolastore.com/support
Overview of Your Camera
1. Photo Sensor (Night Vision Mode)
2. Camera Lens
3. Infrared LEDs (x 8, for night vision)
4. Power LED
On when linked to Parent Unit
Flashes when searching for Parent
Unit
5. Microphone
6. Camera Battery LED
On when AC power is connected to
camera.
Flashes when the battery level of the
camera is low.
7. POWER ON/OFF switch
8. Temperature Sensor
9. Power Adapter Outlet
10. PAIR Button
11. Speaker
12. Star Grip or Tripod Mount
13. Antenna
1
3
2
4
5
6
10
8
9
7
11
12
13
Important guidelines for installing your Wi-Fi®Camera Unit
• Use of other 2.4 GHz products, such as other wireless networks, Bluetooth®
systems or microwave ovens may cause interference with this product. Keep
the Wi-Fi®Camera Unit away from these types of products, or turn them off if
they appear to be causing interference.
• Always ensure that you have a good Wi-Fi®connection available.
4Table of contents
Table of contents
1. Safety Instructions .................................................................................... 5
2. System Requirements .............................................................................. 7
3. Getting Started - Connecting Devices .................................................... 8
3.1 Setup........................................................................................................... 8
3.2 User Account and Camera Setup on Android™ Devices...................... 10
3.2.1 Power ON and Connect the Camera ...................................... 10
3.2.2 Download Hubble for Motorola Monitors App ........................ 10
3.2.3 Run Hubble for Motorola Monitors App on Android™
device ........................................................................................ 10
3.2.4 Add the Camera to your account ............................................. 11
3.3 User Account and Camera Setup on iPhone®/iPad®............................ 15
3.3.1 Power ON and Connect the Camera ...................................... 15
3.3.2 Download Hubble for Motorola Monitors App ........................ 15
3.3.3 Run Hubble for Motorola Monitors App on iPhone®/iPad®... 15
3.3.4 Add the Camera to your account ............................................. 16
3.4 Camera Functions: .................................................................................. 21
3.4.1 Connecting the Camera Unit to power ................................... 21
3.4.2 Overview of the Features on Hubble App ............................... 21
3.5 Working with PC/Notebook ................................................................... 24
3.6 Procedure for Resetting the Camera...................................................... 24
4. Help ......................................................................................................... 25
5. General Information ............................................................................... 31
6. Technical Specifications ........................................................................ 35
Safety Instructions 5
ENGLISH
1. Safety Instructions
WARNING:
STRANGULATION HAZARD - In case this unit is being used to monitor
infants or children, keep the unit and adapter cord more than 1 metre
away from the cot and out of their reach. Never place the Camera or
cords within a cot or near a bed. Secure the cord away from children's
reach. Never use extension cords with AC Adapters. Only use the AC
Adapters provided.
As with any electrical device, supervision of your pet's usage should be
exercised until your pet is acclimated to the product. If your pet is prone
to chewing, we strongly recommend you keep this and all other
electrical devices out of its reach.
Wi-Fi®CAMERA UNIT SETUP & USE:
• Determine a location for the Wi-Fi®Camera Unit that will provide the
best view of your baby in the cot.
•PlacetheWi-Fi
®Camera Unit on a flat surface, such as a chest of
drawers, desk, shelf or wall-mount it using the keyhole slot in the
Camera base.
• NEVER place the Wi-Fi®Camera Unit or cords within the cot.
6Safety Instructions
WARNING
This Wi-Fi®Camera Unit is compliant with all relevant electromagnetic field
standards and is, when handled as described in the User’s Guide, safe to use.
Therefore, always read the instructions in this User’s Guide carefully before
using the device.
• Adult assembly is required due to small parts. Keep all small parts away from
children.
• This product is not a toy. Do not allow children to play with it.
• This Wi-Fi®Camera Unit is not a substitute for responsible adult supervision.
• Keep this User’s Guide for future reference.
• Do not place the Wi-Fi®Camera Unit or cords in the cot or within reach of
the baby (the unit should be at least 1 metre away).
• Keep the cords out of reach of children.
• Do not cover the Wi-Fi®Camera Unit with a towel or blanket.
• Test the Wi-Fi®Camera Unit and all its functions so that you are familiar with
it prior to use.
• Do not use the Wi-Fi®Camera Unit near water.
• Do not install the Wi-Fi®Camera Unit near a heat source.
• Only use the Power Adapter provided. Do not use other power adapters as
this may damage the device.
• Never use extension cords with Power Adapters.
• Do not touch the plug contacts with sharp or metal objects.
System Requirements 7
ENGLISH
2. System Requirements
Web Portal
• Windows®7
• Mac OS®10.7
• Chrome™ 24
• Internet Explorer®9
• Safari®6
• Java™ 7
• Firefox®18.0
• Adobe®Flash®Player 15.0
Android™System
• Version 4.2 or above
iPhone®/iPad®iOS
• Version 7.0 or above
High Speed (Wi-Fi®) Internet
• At least 0.6 Mbps upload bandwidth per camera (you can test your internet
speed on this site: http://www.speedtest.net)
8Getting Started - Connecting Devices
3. Getting Started - Connecting Devices
How does it work?
When a user tries to access the Camera, our Hubble server authenticates the
user’s identity and permits access to the Camera.
3.1 Setup
• Connect the micro USB plug of the power adapter to the Camera Unit and
the other end to a suitable mains power socket.
• Slide the POWER ON/OFF switch to the ON position to turn the Camera
Unit on.
• The Camera must be within range of the Wi-Fi®router with which you want
to connect. Make sure the password of the router is available for entering
during the in-app setup process.
Access your
Camera locally View your Camera from any
compatible device remotely
Hubble Service
Wi-Fi®Router
Wi-Fi®
Camera
Getting Started - Connecting Devices 9
ENGLISH
IMPORTANT
The Baby Unit is able to operate without mains power for up to 3 hours with the
support of the built-in rechargeable battery (Ni-MH battery 2.4V, 900mAh).
Please charge the unit for at least 16 hours before first time use. The battery is
not a user-accessible item. Please contact the helpline if you think it needs
replacing.
Behavior of the status Indicator LED:
Note
Only use the enclosed Power Adapter (5V DC / 1500mA).
You can only setup via a compatible smartphone or tablet, and not via a PC.
Pairing and setting up Flashes slowly in red and blue
Connected Flashes slowly in blue
Paired but not connected Lights up in blue
Ready for connection Flashes slowly in blue
10 Getting Started - Connecting Devices
3.2 User Account and Camera Setup on Android™ Devices
What you need
• FOCUS88 Camera
• Power adapter for the Camera
• Device with AndroidTM system version 4.2 and above
3.2.1 Power ON and Connect the Camera
• Connect the power adapter to an electrical outlet and insert the plug into the
power socket on the back of the Camera Unit.
• Make sure that the ON/OFF switch is in the ON position.
• The Camera’s Red LED flashes after the Camera has finished booting. When
you hear one beep, this means that the Camera is ready for setup.
3.2.2 Download Hubble for Motorola Monitors App
• Go to Google Play™ Store to search for "Hubble for Motorola Monitors".
• Download "Hubble for Motorola Monitors" App from Google Play™ Store
and install it on your Android™ device
3.2.3 Run Hubble for Motorola Monitors App on Android™ device
• Ensure that your Android™ device is connected to your Wi-Fi®router.
• Run "Hubble for Motorola Monitors" App, enter your account information,
read through the Terms of Service, then select "I agree to the Terms of Use"
before you tap
Create
. (Picture A1)
