MP-Man TK262 Series Manuale utente

EN Video & MP3 Player with Touchpad Control

Instruction Manual

Please read carefully before use.

For series

TK262

Page 2 Table Of Contents

English

ÂTable of Contents

THANK YOU.....................................................................................................................................5

Package Contents ..........................................................................................................................5

Features............................................................................................................................................5

CONTROLS AT A GLANCE..............................................................................................................6

GETTING STARTED...........................................................................................................................7

Charging the Battery......................................................................................................................7

Charging with a Computer ...........................................................................................................7

Turning the Player On/Off ..............................................................................................................7

Resetting the Player ........................................................................................................................8

Disabling the Controls (Hold).........................................................................................................8

Using the Touchpad Controls ........................................................................................................8

MAIN MENU.................................................................................................................................. 10

Main Menu Controls .....................................................................................................................10

MUSIC MODE................................................................................................................................ 11

Music Browser Controls................................................................................................................. 11

Now Playing Controls (Music Playback).....................................................................................12

Quick Option Menu ...........................................................................................................13

Page 3 Table Of Contents

English

PHOTO MODE ............................................................................................................................... 15

Photo Browser Controls.................................................................................................................15

VIDEO MODE ................................................................................................................................ 17

Movie Browser Controls ................................................................................................................17

Movie Playback Controls .............................................................................................................17

RADIO MODE................................................................................................................................ 19

Radio Tuning Controls...................................................................................................................19

Quick Option Menu ...........................................................................................................19

TEXT MODE ...................................................................................................................................22

Text Browser Controls ....................................................................................................................22

Text Reader Controls.....................................................................................................................22

Quick Option Menu ...........................................................................................................22

EXPLORER MODE ..........................................................................................................................25

Explorer Controls ...........................................................................................................................25

SETUP MODE ................................................................................................................................. 27

VIDEO CONVERSION ...................................................................................................................30

SPECIFICATIONS........................................................................................................................... 31

Page 4 Table Of Contents

English

TROUBLESHOOTING & SUPPORT...................................................................................................33

Page 5 Thank You

English

ÂThank You

Congratulations on your purchase of the Video & MP player. This manual is designed to help you easily

set up and begin using your new player right away. Please read this manual carefully and retain it for

future reference.

Package Contents

Please make sure that the items shown below are

included in the package. Should an item be miss-

ing, please contact the local retailer from which you

purchased this product.

MP Player

USB Cable

Instruction Manual & Documentation

Professional Stereo Earphones

This package may contain plastic bags or

other materials that pose a hazard to chil-

dren. Be sure to safely dispose of all pack-

ing materials after opening.

Features

Integrated ﬂash memory

.” TFT LCD full-color display

Elegant touchpad controls with LED backlight

Integrated stereo speakers

Plays music, video, photos and text

ID and LRC support for song and synchronized

lyric information display

Integrated FM Radio

USB . Hi-speed for fast ﬁle transfers

Page 6 Controls At A Glance

English

ÂControls at a Glance

Front View

1. Integrated Speakers

2. LCD Display

3. Menu Button <MENU>

4. Control Buttons

<UP>

<DOWN>

<LEFT>

<RIGHT>

5. Enter Button <ENTER>

6. Option Button <OPTION>

Side View

7. Power/Hold Switch

Slide and hold the switch down to power

the player on or off. Slide the switch up to

disable the player’s controls.

<POWER>

Bottom View

8. USB Port/Charge

9. 3.5mm Headphone Jack

Rear View

10. Reset Button <RESET>

Page 7 Getting Started

English

ÂGetting Started

Charging the Battery

Your player has an integrated rechargeable battery.

Upon initial use, the battery should be charged fully

to ensure optimal performance and battery life.

If the player has not been used in a while, the

battery may need to be recharged overnight (about

 hours).

The battery used in this device may present

a ﬁre or chemical burn if mistreated. Do not

disassemble, incinerate, or heat the battery.

Do not leave the battery in a place subject

to direct sunlight, or in a car with its win-

dows closed.

Do not connect the player to a power source

other than that which is indicated here or on

the label as this may result in the risk of ﬁre

or electric shock.

Charging with a Computer

Your player can be charged through a USB com-

puter connection. Use the supplied USB cable to

connect the player to a high-power USB port of a

computer. The computer must be powered on and

not in sleep mode.

When the player is connected and charg-

ing, a USB symbol will be displayed on the

player’s screen.

Turning the Player On/Oﬀ

To turn the player on, slide and hold the

<POWER> switch down until the screen turns on.

To turn the player oﬀ, slide and hold the

<POWER> switch down until the screen turns oﬀ.

Page 8 Getting Started

English

Resetting the Player

Reset the player if it should freeze and not respond

or otherwise malfunction.

1. Disconnect your player if it is connected to a

computer.

2. Use a paper clip to gently touch the <RESET>

button located on the rear of the player.

Disabling the Controls (Hold)

When the <POWER> switch is set to the “Hold”

position, your player’s controls are disabled.

You may want to disable the controls to avoid

turning on the player or activating the controls

accidentally when it is in your pocket or bag.

To disable the controls, slide the <POWER>

switch up until it clicks into the “Hold” position.

To enable the controls, slide the <POWER> switch

down to release it from the “Hold” position.

A lock icon will appear on the screen when

the controls are disabled. Re-enable the

controls to continue.

Using the Touchpad Controls

Your player comes equipped with a touch-sensitive

control pad. To use the controls, touch the arrow

keys on the front of the player lightly just as you

would a button and the controls will light up. If you

touch and hold a key, it will register as a continuous

button touch.

Using the Controls to Navigate

To navigate through the diﬀerent menu options

and ﬁles on your player:

Touch the Arrow keys to move the selection in

the direction of the arrow.

<UP> Move the selection up.

<DOWN> Move the selection down.

Page 9 Getting Started

English

<RIGHT> Move the selection right.

<LEFT> Move the selection left.

Touch <ENTER> to conﬁrm a selection.

Touch <MENU> to return to the previous screen.

Page 10 Main Menu

English

ÂMain Menu

When you turn on the player, you will see the Main

menu. The Main menu gives you access to the diﬀer-

ent function modes of your player. These modes are:

Music: Browse and play music.

Photo: Browse and view Photo.

Video: Browse and play Video.

Radio: Listen to FM radio broadcasts.

Text: Browse and read text ﬁles.

Explorer: Browse all ﬁles.

Setup: Adjust the player’s options.

Select “Extras” from the Main Menu to get

the “Text” and “Explorer” menus.

Main Menu Controls

To browse through the diﬀerent modes, touch

<UP> or <DOWN>.

To adjust volume level, touch <LEFT> or

<RIGHT>.

To select a mode, touch <ENTER> .

To return to the previous screen, touch

<MENU>.
