MP-Man MP434 Manuale utente

For Model No.

MP434 EN Instruction Manual

Page 1

This manual contains important safety precautions and information of correct use.

Please be sure to read this manual carefully before use so as to avoid any accidents.

Do not place the product in hot, wet or dusty environment, especially in summer,

do not leave the product inside a car with all windows closed.

Avoid dropping, impacting or shaking the product violently, otherwise it may cause damages or malfunctions.

Select a proper volume to avoid ear problem when using earphones.

Do not cross the road or drive vehicles, using headphones to avoid trac accidents.

Be sure to use the provided chargers and accessories in the package.

Be sure to charge the product when the following situations take place,

- The battery icon shows lower or empty.

- System automatically shut down and it turns o soon after restart.

- Operation keys do not respond properly.

- The device shows on the top right corner

Hardware

CPU processor

Flash

Memory

External storage

LCD

LCD resolution

G-Sensor

Wi-Fi

USB

Sound input/output

Battery

Dimension

RK2818 624MHz + DSP 400MHz

4 / 8GB

256MB DDR2 RAM

microSD card slot recognizing up to 32GB

4.3 inch resistive touch screen

480 x 272

Yes

Internal WIFI，support IEEE802.11b/g

High speed Mini USB2.0

Stereo sound，3.5mm earphone jack，internal MIC（only record）

1100mAh lithium battery

113.5mm X 75.5mmX 12.3mm / 122g

Page 2

1. Specification

Software

Explore

Video

Audio


Language

Android 2.2 Froyo

Google

H.264 / MKV / WMV / MOV / 3GP / MPE / AVI

MP3 / WAV / WMA / OGG / AAC / M4A / FLAC

JPG / PNG / BMP / GIF

English / Russian / French / Spanish / Korean / Chinese

Power button

Long press to turn on or o the device

Short press to go to stand-by mode to save battery.

Earphones

microSD card slot recognizing it up to 32GB

USB 2.0 port

MIC for recording voice

Reset

Press reset button on the backside

when the device is stuck or malfunction.

Speaker

Page 3

2. Button layout

Power butten

Earphone

microSD

USB port

Reset

MIC

Important Notice

- If the device is freezing or stuck while using,

press the reset button (a small hole) on the backside.

- When the performance is slow after using some applications,

it is recommended to run “Advanced Task Killer” and press End All.

Press power button for standby mode

Press power button again to turn on the display and slide the lower lock icon to the upper one.

Page 4

3. Standby mode

To optimize battery life, be sure to fully charge the device before rst use. Also recommend to fully

charge it once charging.

4. Charging

To go to home screen, slide the lower lock icon to the upper icon.

Main screen consists of 5 dierent screen. Slice right/left to see other screen.

To remove the short-cut icon from home screen, long press the icon and put it on the waste bin if the

screen activates.

Page 5

5. Main screen

Home button

Directly go to home screen wherever you are.

System notification

There is a system notication bar on the top of screen. Pull down to see the screen below.

Page 6

Add：possible to put Shortcuts, Widgets, Folders, Wallpapers on the main screen.

Wallpaper：possible to set wallpaper you want.

Search：use web browser

Notifications：see the system notication on the tool bar.

Settings：go to Settings.

Page 7

Volume control to press +, -

Menu button ( ) to see menu

To put the short-cut of application on the main screen, long press the application icon.

Then, put it on if the screen activates

Page 8

Return button ( ) to go to previous menu.

Press function button ( ) to go to sub-menu. You will see all application as shown below

Connect the device with the computer using USB cable, the device is automatically

recognized by the computer as seen below from left to right photo.

Press “Turn o the USB storage” to disconnect the device from the computer.

Page 9

6. How to connect/disconnect the device with/from computer
