MSI MS-6545 Manuale utente

Version 1.1

G52-MA00453

MS-6545 (v1.X) ATX Mainboard

MSI

MICRO-STAR INTERNATIONAL

850 Pro5

Manual Rev: 1.0

Release Date: Sept. 2001

FCC-B Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a class

B digital device, pursuant to part 15 of the FCC rules. These limits are designed

to provide reasonable protection against harmful interference when the equip-

ment is operated in a commercial environment. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in accor-

dance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to

cause harmful interference, in which case the user will be required to correct

the interference at his own expense.

Notice 1

The changes or modifications not expressly approved by the party respon-

sible for compliance could void the user’s authority to operate the equipment.

Notice 2

Shielded interface cables and A.C. power cord, if any, must be used in order to

comply with the emission limits.

VOIR LA NOTICE D’INSTALLATION AVANT DE RACCORDER AU

RESEAU.

Micro-Star International MS-6545

Tested to comply

with FCC Standard

For Home or Office Use

iii

Edition

Sept. 2001

The material in this document is the intellectual property of MICRO-

STAR INTERNATIONAL. We take every care in the preparation

of this document, but no guarantee is given as to the correctness of its

contents. Our products are under continual improvement and we re-

serve the right to make changes without notice.

Trademarks

All trademarks used in this manual are the property of their respective

owners.

Intel and Pentium are registered trademarks of Intel Corporation.

PS/2 and OS/2 are registered trademarks of IBM Corporation.

Windows 95 and Windows NT are registered trademarks of Microsoft.

Netware is a registered trademark of Novell.

Award is a registered trademark of Award Software Inc.

Revision History

Revision Revision History Date

V1.0 First release Sept. 2001

1. Always read the safety instructions carefully.

2. Keep this User’s Manual for future reference.

3. Keep this equipment away from humidity.

4. Lay this equipment on a reliable flat surface before setting it up.

5. The openings on the enclosure are for air convection hence protects the

equipment from overheating. DO NOT COVER THE OPENINGS.

6. Make sure the voltage of the power source and adjust properly 110/220V

before connecting the equipment to the power inlet.

7. Place the power cord such a way that people can not step on it. Do not

place anything over the power cord.

8. Always Unplug the Power Cord before inserting any add-on card or module.

9. All cautions and warnings on the equipment should be noted.

10. Never pour any liquid into the opening that could damage or cause electri-

cal shock.

11. If any of the following situations arises, get the equipment checked by a

service personnel:

zThe power cord or plug is damaged

zLiquid has penetrated into the equipment

zThe equipment has been exposed to moisture

zThe equipment has not work well or you can not get it work according

to User’s Manual.

zThe equipment has dropped and damaged

zIf the equipment has obvious sign of breakage

12. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT

UNCONDITIONED,STORAGETEMPERATUREABOVE600

C(1400F),IT

MAY DAMAGE THE EQUIPMENT.

Safety Instructions

CAUTION: Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type recommended by the

manufacturer.

CONTENTS

Chapter 1. Introduction ............................................................... 1-1

Mainboard Specification ............................................................ 1-2

Mainboard Layout ..................................................................... 1-4

Quick Components Guide ......................................................... 1-5

Key Features ............................................................................ 1-6

MSI Special Features ................................................................ 1-7

T.O.P Tech™ ...................................................................... 1-7

PC Alert™ III ....................................................................... 1-8

D-LED™ & D-Bracket™ (Optional) .................................... 1-10

Fuzzy Logic™ III ............................................................... 1-12

Live BIOS™/Live Driver™ .................................................. 1-13

Chapter 2. Hardware Setup ........................................................ 2-1

Central Processing Unit: CPU ................................................... 2-2

CPU Installation Procedures ............................................... 2-2

Installing the CPU Fan ........................................................ 2-3

CPU Core Speed Derivation Procedure ................................ 2-4

Memory Installation ................................................................... 2-5

Memory Population Rules ................................................... 2-5

Installing RIMM Modules ..................................................... 2-6

Power Supply ............................................................................ 2-7

ATX 20-Pin Power Connector: JWR1 ................................... 2-7

ATX 12V Power Connector: JWR3 ....................................... 2-8

ATX 5V/3V Power Connector: JWR2 ................................... 2-8

Back Panel ............................................................................... 2-9

Mouse Connector: JKBMS1 ................................................ 2-9

Keyboard Connector: JKBMS1 .......................................... 2-10

USB Connectors ............................................................... 2-10

Serial Port Connector: COM A & COM B .......................... 2-11

Joystick/Midi Connectors .................................................. 2-11

Audio Port Connectors ...................................................... 2-11

Parallel Port Connector: LPT1 ........................................... 2-12

Connectors ............................................................................. 2-13

Floppy Disk Drive Connector: FDD1 .................................. 2-13

Remote Power On/Off Switch Connector: JRMS1 ............. 2-13

Hard Disk Connectors: IDE1 & IDE2 ................................. 2-14

Front Panel Connector: JFP1 or J23 (Optional Intel spec) . 2-15

CD-In/Aux-In/Modem-In Connector: JCD1/JAUX1/JPHN1 ... 2-16

Fan Power Connectors: CPUFAN/SYSFAN/PSFAN .......... 2-17

Wake On Ring Connector: JMDM1 ................................... 2-18

Power Saving Switch Connector: JGS1 ............................. 2-18

IrDA Infrared Module Connector: J18 ................................. 2-19

Chassis Intrusion Switch Connector: J12 .......................... 2-19

Front Panel Audio Connector: J22 (Optional Intel spec) ..... 2-20

Front USB Connectors: JUSB1 & JUSB2 .......................... 2-21

D-Bracket™ Connector: J24 .............................................. 2-25

Jumpers .................................................................................. 2-27

Clear CMOS Jumper: JBAT1 ............................................. 2-27

RDRAM Over Voltage Jumper: J20 .................................... 2-28

Clear BIOS Password Jumper: J17 ................................... 2-29

BIOS Flash Jumper: J16 ................................................... 2-29

Slots ....................................................................................... 2-30

AGP (Accelerated Graphics Port) Slot .............................. 2-30

PCI Slots .......................................................................... 2-30

CNR (Communication Network Riser) Slot ........................ 2-30

PCI Interrupt Request Routing ........................................... 2-31

Chapter 3. AWARD®BIOS Setup .................................................. 3-1

Entering Setup .......................................................................... 3-2

Control Keys ............................................................................. 3-2

vii

Getting Help .............................................................................. 3-3

The Main Menu ......................................................................... 3-4

Standard CMOS Features ......................................................... 3-6

Advanced BIOS Features .......................................................... 3-8

Advanced Chipset Features .................................................... 3-12

Integrated Peripherals ............................................................. 3-14

Power Management Setup ...................................................... 3-19

PNP/PCI Configurations .......................................................... 3-23

PC Health Status .................................................................... 3-25

Frequency/Voltage Control ...................................................... 3-26

High System Performance ...................................................... 3-28

Load Optimized Defaults ......................................................... 3-29

Set Supervisor/User Password ................................................ 3-30

Save & Exit Setup ................................................................... 3-32

Exit Without Saving ................................................................. 3-33

Appendix A: MSI Smart Key ....................................................... A-1

Installing MSI Smart Key ......................................................... A-2

Using MSI Smart Key .............................................................. A-3

Appendix B: Using 4-/6-channel Audio Function ...................... B-1

Installing C-Media Drivers ......................................................... B-2

Hardware Configuration ............................................................ B-2

Software Configuration .............................................................. B-3

Appendix C. USB PC to PC Networking Function ..................... C-1

Installing GeneLink™ LAN Driver .............................................. C-3

Using USB PC to PC Networking Function .............................. C-5

Glossary ........................................................................................ G-1

Introduction

1-1

Chapter 1.

Introduction 1

The 850 Pro5 (MS-6545 v1.X) ATX mainboard is a high-performance

computer mainboard based on Intel®82850 chipset. It is optimized to support

Intel®Pentium®4 processors for high-end business/personal desktop markets.

The Intel®850 chipset supports 64-byte cache line size and a 32-bit host

addressing, allowing the processor to access the chipset’s memory address

space. It also provides 4x AGP data transfers and AGP Fast Write capability.

The Intel®850 chipset features a dual channel Direct RDRAM memory

operating in lock-step using RSL technology. It is a highly-flexible chipset

which is designed to extend the basic graphics/multimedia PC platform up to

the mainstream performance desktop platform.

The Intel®82801BA (ICH2) chipset is a highly integrated multifunctional

I/O Controller Hub that provides the interface to the PCI Bus and integrates

many of the functions needed in today’s PC platforms. It communicates with

the host controller over a dedicated hub interface and provides added flexibil-

ity in designing cost-effective system solutions.

This chapter includes the following topics:

Mainboard Specification 1-2

Mainboard Layout 1-4

Quick Components Guide 1-5

Key Features 1-6

MSI Special Features 1-7

Chapter 1

1-2

CPU

zSupports Intel®Pentium®4 processor in the 478 pin package.

zSupports 1.5GHz, 1.6GHz, 1.7GHz, 1.8GHz, 1.9GHz, 2GHz and up.

Chipset

zIntel®82850 MCH (615 OLGA)

- Supports Direct RDRAM up to 2GB maximum memory.

- Supports 400 MHz system bus.

- 1.5V AGP interface with 4x data transfer and 4x fast write capability.

zIntel®82801BA ICH (360 EBGA)

- Upstream hub interface for access to the Intel MCH.

- 2-channel Ultra ATA/100 Bus Master IDE controller.

- USB controller 1.1 (expanded capabilities for 4 ports).

- I/O APIC.

- SMBus controller.

- FWH interface.

- LPC interface.

- AC’97 2.1 interface.

- PCI 2.2 interface.

- Integrated system management controller.

Main Memory

zSupports four 184-pin gold-lead RIMM sockets.

zSupports a maximum memory size of 2GB.

Slots

zOne AGP (Accelerated Graphics Port) 4x slot.

zFour PCI 2.2 32-bit PCI bus slots (support 3.3v/5v PCI bus interface).

zOne CNR (Communication Network Riser) slot.

On-Board IDE

zAn IDE controller on the ICH2 chipset provides IDE HDD/CD-ROM with

PIO, Bus Master and Ultra DMA100 operation modes.

zCan connect up to four IDE devices.

On-Board Peripherals

zOn-Board Peripherals include:

Mainboard Specification

Introduction

1-3

- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and

2.88Mbytes.

- 2 serial ports (COM A + COM B).

- 1 parallel port supports SPP/EPP/ECP mode.

- 1 IrDA connector for SIR.

- 1 audio/game port.

USB Interface

zThe mainboard comes with two optional USB interfaces:

- 6 USB 1.1 ports (Rear * 2/ Front * 4, two with Intel spec & two with MSI

spec).

- 4 USB 1.1 ports (Rear * 2/ Front * 2, one regular USB 1.1 port and the other

with USB PC to PC networking function).

Audio

zC-Media CMI8738 / PCI-6ch supports 2/4/6 ch speaker

- 6CH DAC for AC3® 5.1CH purpose.

- HRTF-based 3D positional audio, supporting DirectSoundTM 3D and A3DTM

interface.

- Supports 4.1/5.1 speakers, C3DX positional audio in 4/6 CH speaker mode.

- Legacy audio SBPROTM compatible.

- DLS-based wavetable music synthesizer.

BIOS

zThe mainboard BIOS provides “Plug & Play” BIOS which detects the pe-

ripheral devices and expansion cards of the board automatically.

zIDE drive auto configure, Advanced Power Management (APM) 1.2, ACPI

1.0, DMI 2.0, ECC/Parity support, LS120 support, auto enabled onboard

SCSI termintor.

Dimension

zATX Form Factor: 30.4cm(L) x 24.3cm(W) x 4 layers PCB.

Mounting

z9 mounting holes.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali MSI Scheda madre

MSI

MSI MEG Z590 ACE Manuale utente

MSI

MSI MS-6380 Manuale utente

MSI

MSI K9N4 - Ultra-F Motherboard - ATX Manuale utente

MSI

MSI X79MA-GD45 series Manuale utente

MSI

MSI ATX BX1 Manuale utente

MSI

MSI NF725-C35 Series Manuale utente

MSI

MSI TOMAHAWK PLUS B350 Manuale utente

MSI

MSI MAG X570 TOMAHAWK WIFI Manuale utente

MSI

MSI H67MA-E45 series Manuale utente

MSI

MSI B550-A PRO Manuale utente

MSI

MSI H61I-E35 V2/W8 Series Manuale utente

MSI

MSI PRO Z690-P WIFI Manuale utente

MSI

MSI Fuzzy 945GME1 Series Istruzioni per l’uso

MSI

MSI Z77A-G45 GAMING series Manuale utente

MSI

MSI H55M-E33 series Manuale utente

MSI

MSI 870S-G46 series Manuale utente

MSI

MSI H110M-A PRO M2 Manuale utente

MSI

MSI MS-5184 Manuale utente

MSI

MSI IFC-815N2D Series Manuale utente

MSI

MSI K8T Neo-FSR Manuale utente

MSI

MSI PRO B650-P WIFI Manuale utente

MSI

MSI 694D Pro2 Manuale utente

MSI

MSI 945GZM3 Series Manuale utente

MSI

MSI Creator X299 Manuale utente

Manuali Scheda madre popolari di altre marche

DFI

DFI SD170 Manuale utente

ASROCK

ASROCK ROMED8-2T Manuale utente

Asus

Asus P2L97A Manuale utente

Winmate

Winmate IC70 Manuale utente

Asus

Asus MES-B Manuale utente

Grantech

Grantech SYS8F377VGGA-3OMN Manuale utente

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuale utente

Gigabyte

Gigabyte GA-9IVDT Manuale utente

Texas Instruments

Texas Instruments ADS8372EVM Manuale utente

Commell

Commell MS-C73 Manuale utente

IBT Technologies

IBT Technologies MB860 Manuale utente

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuale utente

Biostar

Biostar M7VIT Bravo Istruzioni per l'uso e l'installazione

Intel

Intel D33217CK Manuale utente

Asus

Asus F1A55-M LX PLUS R2.0 Manuale utente

EPC

EPC EPC9147C Manuale utente

Asus

Asus EX-B760M-V5 D4 Manuale utente

EPOX

EPOX MU-8KHA0010 Manuale utente
