Multitech MULTIVOIP MVP-130 Manuale

MultiVOIP®

Voice over IP Gateways

MVP130

MVP130-FXS

Cabling Guide

2 Multi-Tech Systems, Inc.

Cabling Guide

MultiVOIP Single Port Analog Units:

MultiVOIP®MVP130

MultiVOIP®MVP130-FXS

82100365L, Rev. A

This publication may not be reproduced, in whole or in part, without prior expressed

Multi-Tech Systems, Inc. makes no representations or warranty with respect to the

contents hereof and specifically disclaims any implied warranty of merchantability or

fitness for any particular purpose. Furthermore, Multi-Tech Systems, Inc. reserves

the right to revise this publication and to make changes from time to time in the

content hereof without obligation of Multi-Tech Systems, Inc. to notify any person or

organization of such revisions or changes. Check Multi-Tech’s web site for current

versions of our product documentation.

Revision Date Description

A 02/08/08 Initial release as Cabling Guide.

Trademarks

Multi-Tech, the Multi-Tech logo, and MultiVOIP are registered trademarks of Multi-

Tech Systems, Inc. All other brand and product names mentioned in this

publication are trademarks or registered trademarks of their respective companies.

Patents

This Product is covered by one or more of the following U.S. Patent Numbers:

6151333, 5757801, 5682386, 5.301.274; 5.309.562; 5.355.365; 5.355.653;

5.452.289; 5.453.986. Other Patents Pending.

GENERAL

CONTACT TECHNICAL SUPPORT

Country By E-mail By Phone

Europe,

Middle East,

Africa support@multitech.co.uk (+44) 118 959 7774

Multi-Tech

Systems, Inc.

2205 Woodale Drive

Mounds View,

Minnesota

55112, USA

(763) 785-3500

(800) 328-9717

Fax: 763-785-9874

www.multitech.com

U.S.,

Canada,

All Others support@multitech.com

(800) 972-2439;

(763) 717-5863

Multi-Tech Systems, Inc. 3

Introduction

This guide shows you how to make the cable connections to set up your

MultiVOIPP

®MVP130 or MVP130-FXS unit. See your MultiVOIP User Guide

included on the MultiVOIP CD for more information.

Safety Warnings

Lithium Battery Caution

A lithium battery on the voice/fax channel board provides backup power for the

timekeeping capability. The battery has an estimated life expectancy of ten years.

When the battery starts to weaken, the date and time may be incorrect. If the battery

fails, the board must be sent back to Multi-Tech Systems for battery replacement.

Warning: There is danger of explosion if the battery is incorrectly

replaced.

Ethernet Ports Caution

Caution: The Ethernet ports and command ports are not designed to

be connected to a Public Telecommunication network.

Safety Warnings Telecom

•Use this product only with UL- and CUL-listed computers (US).

•Never install phone wiring during a lightning storm.

•Never install a phone jack in a wet location unless the jack is specifically

designed for wet locations.

•Never touch uninsulated phone wires or terminals unless the phone line has

been disconnected at the network interface.

•Use caution when installing or modifying phone lines.

•Avoid using a phone during an electrical storm; there is a risk of electrical

shock from lightning.

•Do not use a phone in the vicinity of a gas leak.

•To reduce the risk of fire, use only 26 AWG or larger telephone line cord.

•This product must be disconnected from power source and telephone network

interface when servicing.

Package Contents:

•One MVP130 or MVP130-FXS unit

•One power cord

•One Command Cable (DB25-to-DB9 connectors)

•One RJ-11 phone cord

•One printed Cabling Guide

•One MultiVOIP CD containing software and user documentation.

Quick Hookup for MVP130/130-FXS

•Connect the power cord supplied with your MultiVOIP to the power

connector on the back of the MultiVOIP and to a live AC outlet.

•Connect the MultiVOIP to a PC by using the RJ-45 (male) to DB-9

(female) cable.

•Connect a network cable to the ETHERNET connector on the back of

the MultiVOIP. Connect the other end of the cable to your network.

•Connect one end of an RJ-11 phone cord to the FXS/FXO connector

on the back of the MultiVOIP. Connect the other end to the device or

phone jack.

82100365L
