Navitar 1-51320 Guida
REV CHANGERECORD AND DATECH
ROCHESTER,NEWYORK
REV
SIZE
B
P/NSUFFIXDEFINITION
-1CONVERSIONCOATING
-2PAINTING
-3MARKING
-RREWORK
UNLESS OTHERWISE
SPECIFIED
DIMENSIONSAREININCHES
AND INCLUDECHEMICALLY
APPLIEDORPLATEDFINISHES
DEC..XXX `.005
DEC..XX `.010
FRACT.`1/64
ANGLES `30'
CONCENTRICITY.003 TIR
BREAK ALL SHARPEDGES
.005 MIN..010 MAX
MAX.SURF.ROUGHNESS 32
TOLERANCES:
MATERIAL:
FINISH:
CHAMFERALL THREADS
30~TOROOTDIAM.
USEDON:
SCALE:
DR.:
CH.:
APP.:
DATEDR.:
DONOTSCALEDRAWING
0.0mm 25.0
0.0inch1.0
SHEETOF
THECONTENTSOFTHIS
DOCUMENTAREPROPRIETARY
TONAVITAR,ITSUSE IS
AUTHORIZEDONLYFOR
RESPONDINGTOREQUEST
FORQUOTATIONOR
PERFORMANCEOFWORKFOR
NAVITAR
1-51320 A
11
R.PODLENA
P.BONAFEDE
9/18/2003
MOTORIZED(STEP)12XULTRAw/2
POSLS(HE)
1:1
OUTLINE
2-PHASE MOTORPINOUT
PIN3=+5Vdc
PIN13 =COMMON
PIN8=FARLIMIT
PIN12 =NEARLIMIT
PIN1=MOTORA+
PIN7=MOTORA-
PIN6=MOTORB+
PIN11 =MOTORB-15 PINHIGHDENSITY
D-SUB
2.09 [53.1]
2.41 [61.3]
1.46 [37.0]
1.312n-.001
.000+
n1.91 [48.4]
.37 [9.5]
5.29 [134.4]
1.88 [47.6]n
n1.66 [42.2]
n1.40 [35.6]
n1.31 [33.3]
n1.25 [31.8]
4.16 [105.7] .80 [20.3]
.32 [8.1]
.75 [19.1]
.38 [9.5]
4-40 UNC -2B(4)x
26.0-36RMS
.800-36RMS
