Navitar 1-51324 Guida
ROCHESTER,NEWYORK
UNLESS OTHERWISE SPECIFIED
DIMENSIONSAREININCHES AND
INCLUDECHEMICALLYAPPLIED
ORPLATEDFINISHES
0.0inch1.0
0.0mm 25.0
P/NSUFFIXDEFINITION
-1CONVERSIONCOATING
-2PAINTING
-3MARKING
-RREWORK
SIZE
REV
TOLERANCES AS FOLLOWS
DEC..XXX
DEC..XX
FRACT.
ANGLES
CONCENTRICITY
BREAK ALL SHARPEDGES
.005 MIN..010 MAX.
MAX.SURF.ROUGHNESS:32
`.005
`.010
`1/64
`30'
.003 TIR
USEDON:
MATERIAL:
FINISH:
CHAMFERALL THREADS30~
TOROOTDIAMETER
SCALE:
DR:
CH:
APP:
DATEDR:
DONOTSCALEDRAWINGSHEETOF
THECONTENTSOFTHIS
DOCUMENTAREPROPRIETARY
TONAVITAR,ITSUSE IS
AUTHORIZEDONLYFOR
RESPONDINGTOREQUESTFOR
QUOTATIONORPERFORMANCE
OFWORKFORNAVITAR
11A
1-51324
R.PODLENA
P.BONAFEDE
9/16/2003
MOTORIZED(STEP)12XULTRAw/2POS
LS(HE)&COAX PORT
1:1
B
OUTLINE
2-PHASE MOTORPINOUT
PIN3=+5Vdc
PIN13 =COMMON
PIN8=FARLIMIT
PIN12 =NEARLIMIT
PIN1=MOTORA+
PIN7=MOTORA-
PIN6=MOTORB+
PIN11 =MOTORB-15 PINHIGHDENSITY
MALED-SUB
2.41 [61.3]
2.09 [53.1]
1.88 [47.6]n1.312n-.001
.000+
n1.91 [48.4]
.37 [9.5]
6.57 [167.0]
3.53 [89.6]
.75 [19.1]
.38 [9.5]
5.46 [138.6] .80 [20.3]
.32 [8.1]
1.46 [37.0]
1.14 [28.9]
n1.73 [43.8]
11/2-32 UN -2A
1.093-32 UN -2B
1.22 [30.9]
13/16-32 UN -2B
.800-36RMS26.0-36RMS
