NEC PowerMate CT Manuale utente

USB Port Factory setting.

Selection Enables front

USB port and

rear USB port.

4

5

6

1

2

3

JP27 JP28

Disables front

USB port and

enables rear

USB port.

4

5

6

1

2

3

JP27 JP28

Caution: To prevent damage to the

system board, avoid clearing

CMOS while power is on.

Memory Upgrade

■

Maximum memory supported: 512 MB;

minimum: 32 MB.

■

System supports 184-pin, 64-, 128-, and 256-MB PC700 and PC800

ECC DRAM modules.

■

Memory size and speed can vary between sockets.

■

Continuity module in socket 2 required when one RDRAM module is

installed.

405-00123-000

PowerMate®CT System Board Configuration

Note: See your

PowerMate CT User’s Guide

for detailed option installation information.

Processor

Socket 370

Jumper Settings

Front USB Factory setting.

Device Disables system

Wakeup wakeup by USB

device.

1

2

3

JP21

Enables system

wakeup by USB

device.

1

2

3

JP21

JP21

Jumper JP28

Jumper

JP27

Jumper

Secondary

IDE Connector

Primary

IDE Connector

JP5

Jumper

PCI Slots

PS/2 Factory setting.

Keyboard at Disables keyboard

Power On at power on.

1

2

3

JP16

Enables

keyboard at

power on.

1

2

3

JP16

CMOS Factory setting.

Clear Sets normal

operation.

1

2

3

JP4

Clears CMOS

with power off.

Return jumper to

pins 2 and 3 before

powering system

on.

1

2

3

JP4

To enable BIOS recovery, remove the jumper.

Wait 10 seconds. Replace the jumper on pins 1 and 2.

BIOS Factory setting.

Recovery Sets normal

operation.

1

2

3

JP5

Restores Safe

BIOS settings.

1

2

3

JP5

Audio Factory setting.

Modem Enables onboard

Riser audio.

1

2

3

JP11

Disables onboard

audio (AMR sound

card installed).

1

2

3

JP11

Rear USB Factory setting.

Device Enables system

Wakeup wakeup via

rear USB port.

Disables system

wakeup via rear

USB port.

321

JP3

321

JP3

Save to Factory setting.

RAM Enables Suspend

mode Save to

RAM (STR) function

Disables

Save to RAM

function.

JP18JP18

Website: www.nec-computers.com

Technical Support: 800-632-4525

JP18

Jumper

RIMM

Sockets

JP4

Jumper

JP3

Jumper

JP11

Jumper

JP16

Jumper

AGP Slot

AMR

Connector

405-00123-000 7/10/00 3:05 PM Page 1
