NetComm NP740n Manuale utente

NP740n 11n Wireless Router

802.11n Draft 2.0 Wireless Router with 4 Ethernet Ports

Your Network - Now faster, stronger and more secure

The NetComm NP740n is a world class 11n Wireless Router with a built-in 4

port Ethernet switch. Powered with advanced Wireless ‘N’ technology, this Router

provides Wireless speeds of up to 300Mbps1, 650% faster than ‘G’ technology.

This Next Generation Wireless standard utilises advanced MIMO (Multi-In, Multi-

Out) technology, which allows you to enjoy network applications with signiﬁcantly

improved reliability. Delivering up to 300% wider coverage and 650% faster

speeds over current wireless technologies.

Unlike other 11n Products the NP740n is based on 802.11n Draft 2.0 meaning it

can be easily upgraded to future 11n revisions with a simple ﬁrmware upgrade2.

• Wi-Fi Multimedia (WMM)

Quality VoIP calls and smooth multimedia streaming are maintained by

prioritising audio, video, voice and applications trafﬁc

• Wi-Fi Protected Setup (WPS)

Set up your Wireless connection with the push of a button! (Requires WPS

compatible wireless adapter such as NetComm NP745n)

• Virtual Server & DMZ

Control the access of external users with your own network

• VPN Pass-Through (IPSec/PPTP)

Access your company’s network through a remote and secure private

connection

• Web conﬁguration

Set-up & management is a breeze with a user friendly web interface

KEY FEATURES

802.11n Draft 2.0 compliant for state-of-the-art wireless up to 300Mbps1

Greatly increase your wireless network speed, reliability and coverage

Easy set-up and management with an intuitive web based interface

4 10/100 Ethernet ports for wired connections

Works with all major operating systems, no software required

Built in Firewall provides security and peace of mind

NETCOMM LIMITED ABN 85 002 490 486 PO Box 1200, Lane Cove NSW 2066 Australia

P: 02 9424 2070 F: 02 9424 2010 E: [email protected] W: www.netcomm.com.au

Trademarks and registered trademarks are the property of NetComm Limited or their respective owners. Speciﬁcations are

subject to change without notice. Images shown may vary slightly from the actual product.

Your NetComm dealer:

MINIMUM SYSTEM REQUIREMENTS

• Internet connection, provided by xDSL or cable modem with a

RJ-45 Ethernet port.

• Computer or network devices with wired or wireless network

interface card.

• Web browser (IE 4.0, Netscape 4.7 or above, Opera or Safari).

• An available AC power socket (100 – 240V, 50/60Hz)

NP740n 11n Wireless Router

802.11n Draft 2.0 Wireless Router with 4 Ethernet Ports

Power Adapter

Gaming Console

Switch

Desktop Computer

Internet

ADSL or Cable Modem

• 802.11n Draft 2.0 compliant for state-of-the-art wireless of up to 300Mbps1

• Greatly increase your wireless network speed, reliability and coverage

• Easy set-up and management with an intuitive web based interface

• 4 10/100 Ethernet ports for wired connections

• Works with all major operating systems, no software required

• Built in Firewall provides security and peace of mind

1 Maximum wireless signal rate and coverage values are derived from IEEE Standard 802.11g and 802.11n Draft 2.0 speciﬁcations. Actual wireless speed and cover-

age are dependent on network and environmental conditions included but not limited to volume of network trafﬁc, building materials and construction/layout.

2 Upgradeability is based on current predicted 802.11n Draft revisions and is subject to change, NetComm cannot guarantee upgradeability in the event or revisions

requiring hardware changes.

TECHNICAL SPECIFICATIONS

PACKAGE CONTENTS

• NP740n 11n Wireless Router

• Vertical Stand

• Ethernet Cable x 1

• Quick Start Guide

• CDROM containing

User Guide (in PDF Format)

• 12VDC 1A Power Supply

Your Network – Now faster, stronger and more secure

CPU

• Ralink RT1310

SWITCH

• Realtek RTL8305SC (5 Port Switch)

WIRELESS MODULE

• Ralink RT2860 + RT2820

FLASH

• 4 MB NOR Flash

RAM

• 16 MB SDRAM

WAN PORT

• 10/100M UTP Port x 1

LAN PORTS

• 10/100M UTP Port x 4

ANTENNA

• Fixed Antenna x 3 (2T3R MIMO Technology)

POWER

• 12VDC, 1A Switching Power Adaptor

DIMENSION

• 30(H)*187(W)*100(D) mm

TEMPERATURE

• 10~40oC

HUMIDITY

• 10~90% (Non-Condensing)

CERTIFICATION

• FCC, CE
