NetComm NP2008 Manuale utente

NETCOMM LIMITED ABN 85 002 490 486 • 2-6 Orion Road, LANE COVE, NSW, 2066 • phone 02 9424 2070 • fax 02 9424 2010 • email [email protected]

www.netcomm.com.au

10/100 Mbps NETWORK SWITCH

SMALL-MEDIUM BUSINESS

Product Code: NP2008

EASY TO INSTALL AND USE

NetComm s SmartSwitch is so smart it s a pleasure to install. And,

once installed, you never need approach it again. SmartSwitch has

been designed to be a full Plug & Play solution with quick and

simple installation. Its auto-sensing 10Base-T and 100Base-TX

design means it will adjust itself to your network system and

conditions without the need for user intervention.

NETWORKING & COMMUNICATIONS CONVERGED

Eight 10/100Mbps half/full duplex auto-sensing

switch ports

Intelligent ‘Store & Forward Technology

Easy Plug & Play configuration

Increase network speed and decrease chatter

Durable metal case

Supports most popular ethernet protocols

CHECK THESE GREAT FEATURES

The high-speed network our business needs

Creating or boosting the performance of a network is

as simple as choosing a NetComm SmartSwitch over a

standard network hub. A SmartSwitch is eas to install,

it configures itself, and it’s at home in an network

environment – TCP/IP, Windows® or AppleTalk.

HOW DOES NETCOMM’S SMARTSWITCH DO THIS?

By using Intelligent Networking technology, NetComm s

SmartSwitch pinpoints the exact recipient of a packet of data and

delivers that data directly to it, whereas an ordinary network hub

simply “sprays” the data to everyone, clogging up the system with

network traffic. The SmartSwitch reduces network traffic, resulting

in higher data transfer speeds and fewer network errors. Simply

put, SmartSwitch directly connects PCs to PCs, and PCs to network

peripherals such as Print Servers and NAS units, ensuring your

network is operating efficiently and your staff get their work

completed faster.

10/100 Mbps NETWORK SWITCH

SMALL-MEDIUM BUSINESS

Standard IEEE802. 10Base-T Ethernet, IEEE 802. i

& 802. u x 100Base-TX Fast Ethernet

Number of ports 8x 10/100 Mbps Auto-sensing RJ-45 ports

Data Ethernet: 10 Mbps (half duplex)

Transfer 20 Mbps (full duplex)

Rate: Fast Ethernet: 100 Mbps (half duplex)

200 Mbps (full duplex)

Network Cables Cat-5unshielded twisted-pair cable

Topology Star

LED Indicators Per Device Power

Per Port 100 Mbps, LINK/ACT

Transmission Method Store and forward

MAC address table 8K-entry MAC address table

Maximum (64 byte packets)

Forwarding Rate 14,880 pps/10Base-T

148,800 pps/100Base-T

TECHNICAL SPECIFICATIONS

SmartSwitch 8-Port

Quick Start Guide

Power Pack

Warranty Card

PACKAGE CONTENTS

Compliant with IEEE 802. i & 802. u standards

Automatic MDI/MDIX crossover for 10Base-T & 100Base-TX ports

Provides eight auto-sensing RJ-45 ports for 10Base-T or 100Base-TX

connections

N-Way Auto-negotiation for 10/100 Mbps transmission

Intelligent Store & Forward switching architecture

Auto-detect of full/half-duplex mode in all ports

Back-pressure for half-duplex; Pause frame for full-duplex

Plug & Play configuration auto address learning

Embedded 8K MAC address table and 2M Bits frame buffer

LED-indicators for power, speed 100Mbps, link/activity

Space-saving small size

Durable metal case

FEATURES

NETWORKING & COMMUNICATIONS CONVERGED

Maximum (64 byte packets)

Filtering Rate 14,880 pps/10Base-T

148,800 pps/100Base-T

Flow control Pause frame (full-duplex)

Back-pressure (half-duplex)

Duplex mode Supports half-duplex & full-duplex mode

Power Supply External power adaptor, DC 7.5V, 1000mA

Uplink Auto Uplink on all ports

Dimensions 171mm x 98mm x 29mm (L x W x H)

Temperature Operating: 0˚C to 45˚C ( 2F to 11 F)

Storage: -10˚C to 70˚C (-22F to 140F)

Humidity 10% to 90% (non-conditioning)

EMI FCC Class B, CE mark, C-Tick

Safety TUV, CUL

Operating System Support All ethernet networks including Windows®

95/98/NT/2000/XP, TCP/IP and AppleTalk

networks

Your Netcomm dealer: NetComm is Australia’s d namic data communications and

networking solutions provider. For more information on this and

other NetComm products, please visit www.netcomm.com.au

NetComm Limited ABN 85 002 490 486

PO Box 1200, Lane Cove NSW 2066 Australia.

PHONE (02) 9424 2070 • FAX (02) 9424 2010

www.netcomm.com.au • EMAIL [email protected]

Trademarks and registered trademarks are t e property of NetComm

Limited or t eir respective owners. Specifications are subject to c ange

wit out notice. Images s own may vary slig tly from t e product.
