NetComm N3G001W Manuale utente

3G Wireless Router

Mac Quick Start Guide

3G Wireless Router

Mac Quick Start Guide

This Quick Start guide provides basic instructions for connecting your N3G001W to an

Apple Macintosh computer and to a 3G Internet Server Provider .

1. Ethernet Installation

2. Airport Installation

Before you can use this Quick Start Guide, you must already have a 3G PC Card and an

active data enabled SIM card with a 3G Internet Service Provider (ISP).

These instructions provide a basic set-up conﬁguration that should get home or small ofﬁce

Macs up and running. This will be sufﬁcient for most users.

If you need to perform more advanced conﬁgurations, please see the comprehensive User

Guide on the supplied CD-ROM for additional instructions.

NOTE: NetComm Technical Support for this product only covers the essential installation and features outlined in this Quick Start

Guide. For detailed information regarding the advanced features of this product, please see the conﬁguring sections in the

N3G001W User Guide on the supplied CD-ROM.

Connecting your N3G001W

The NetComm N3G001W can be connected directly to your Mac via an Ethernet interface.

In addition, you can use your Mac’s Airport to connect to the N3G001W wirelessly.

Warning: Before you begin, turn the power off for all devices. These include your Mac and your N3G001W Modem.

Start Here

3G Wireless Router

Mac Quick Start Guide

Step 1 – Install the Hardware

To connect your N3G001W using the Ethernet cable, follow these step-by-step instructions:

> Connect the Ethernet cable.

Connect one end of the Ethernet cable provided to the Ethernet port on your Mac and the

other end of the cable to the Ethernet port of your N3G001W.

> Insert your 3G PC Card

Carefully insert the 3G card into the N3G001W slot until it is ﬁrmly ﬁtted.

> Attach the power connector.

Connect the AC power adapter to the Power connector on the back of the N3G001W and

plug in the adapter into a wall outlet or power strip.

> Switch on the power.

Your N3G001W will start up. Turn on your Mac.

Step 2 – Set up your Mac

This is how to conﬁgure your N3G001W to work with the Mac OS X (10.5.4 Leopard)

1. From the Apple menu, select System Preferences.

Ethernet

Installation

3G Wireless Router

Mac Quick Start Guide

2. The Systems Preferences window opens.

3. Double click on “Network” and the below window opens. Your Ethernet status

should be “connected”. If the status is not connected, please consult the detailed

user guide.

Ethernet

Installation

(cont)

3G Wireless Router

Mac Quick Start Guide

4. Open Safari and type in 192.168.123.254 in the address bar.

5. This will open the modem conﬁguration screen as below. Type in “admin” in the

System Password tab and click on “Login”

6. Select “Wizard” and click enter.

7. The setup wizard will now guide you though the step by step conﬁguration.

Click on “Next” to proceed.

Ethernet

Installation

(cont)

3G Wireless Router

Mac Quick Start Guide

8. Select your WAN connection and then click next.

Note: NetComm used a 3G card from 3 mobile broadband for the purpose of this quick start guide.

9. In the LAN IP Address, type in “192.168.123.254”

In the APN ﬁeld, type in information provided to you by your 3G broadband service

provider and click next.

Note: NetComm used a 3G card from 3 mobile broadband for the purpose of this quick start guide and the APN of 3 mobile is

“3netaccess”. Please ask your 3G broadband service provider for the APN

10. Conﬁrm the settings and click on “apply settings”.

Ethernet

Installation

(cont)

3G Wireless Router

Mac Quick Start Guide

11. The below screen will appear indicating that the changes are being applied.

12. Click “ﬁnish” to return to the status page.

13. You are now connected via Ethernet to the N3G001W router

Ethernet

Installation

(cont)

3G Wireless Router

Mac Quick Start Guide

Airport

Installation

1. Turn Airport on

2. Click on “Join Other Network”

3. This will take you to the screen below. Do not type in any name, but click on

“Show Networks” at the bottom left of the screen. Make sure “Remember this

network” is ticked.

4. Airport will now scan all the available networks as shown below

3G Wireless Router

Mac Quick Start Guide

Airport

Installation

(cont)

5. Select “netcomm n3g series” and click on “join”

The default password is a1b2c3d4e5 – please type this in and ensure that “Show

password” and “Remember this network” are ticked.

6. Now, when you click on the Airport icon, you will see a number of wireless networks.

Select “netcomm n3g series”

8. You are now connected wirelessly to the N3G001W router.
