Nextar N1-502 Manuale utente

Portable Mini Photo Album

N1-502

Instruction Manual

Thank you for purchasing the Nextar N1-502

Portable Mini Photo Album. Please read this

manual to get the optimum performance out

of this product.

Quickstart Guide

NOTE: YOU MUST INSTALL INCLUDED

SOFTWARE BEFORE ATTACHING YOUR

PHOTO ALBUM TO YOUR PC.

Software Installation:

1. Insert the included CD into your PC’s

CDROM drive

2. Open “My Computer” and find the CD

you just inserted. It will appear similar

to the image below:

3. Double click the CD drive icon to open

the CD. ** NOTE** THE ACTUAL

DRIVE LETTER (D IN THIS CASE)

COULD BE DIFFERENT ON YOUR

PC. LOOK FOR THE DRIVE THAT IS

THE CDROM ON YOUR

PARTICULAR PC

4. Double click the “Photoviewer….exe”

icon. NOTE: THE EXACT REVISION

NUMBER OF THE VERSION ON

YOUR CD COULD BE DIFFERENT

THAN IN THE PHOTO BELOW:

5. After double clicking this icon, the

following screen should appear:

6. Follow the on-screen prompts to install

the software. Accept all the “defaults”

that the program suggests (if you are

experienced in installing software you

can customize your install)

You are now ready to charge your Mini Photo

Album.

1. Using the included cable, plug the cable

into your PC first, and then into your

Mini Photo Album.

NOTE: YOUR PHOTO ALBUM MUST

BE FULLY CHARGED BEFORE USING IT.

THIS CHARGING TIME IS TYPICALLY 2-3

HOURS

2. While the unit is charging, the following

screen will appear:

These two lines of text will blink

alternately while the unit is charging.

Once fully charged, “Charge Finished”

will remain on the screen

3. Once the unit is fully charged, unplug it

from your PC and turn it off using the

ON/OFF switch on the side of the unit.

4. With the unit off, plug it back into your

PC (using the same procedure as #1).

5. Your PC will recognize the unit as a

flash drive and install it as a removable

drive. To see this, open “My Computer”

and you will see a new removable drive

letter indicated, similar to the image

below:

NOTE: YOUR ACTUAL DRIVE LETTER

MAY BE DIFFERENT DEPENDING UPON

HOW MANY REMOVEABLE DEVICES YOU

HAVE INSTALLED ON YOUR PC

6. Once your PC indicates that the drive is

installed and ready to use, go to your

START/ALL PROGRAMS menu and

look for the newly installed program

group. It should be called “Photo

Viewer”

7. Go to this new program group and

double click the Photoviewer icon to

open the program

Charge Finished

Low Battery

8. Once open, you should see a program

screen similar to the one below:

9. To add pictures to your Mini Photo

Album from your PC, navigate to the

image on your PC using the controls on

the left-hand side of the Photoviewer

software

10. Select the photo you want to add by

clicking on it once.

11. Then click the blue arrow (circled on the

image as “1”) to POST the image to the

keychain.

12. Then to finalize the transfer, click the

SYNCHRONIZE button (circled on the

image as “2”) to make the transfer

complete

13. You can delete images on the Photo

Key-Chain by selecting them, pressing

the DELETE button and then the

synchronize button

Once you have completed the transfer of

images to your Mini Photo Album, exit the

Photoviewer software and remove your unit

from your PC by disconnecting the USB

cable from your Mini Photo Album first and

then from your PC.

To turn on the Mini Photo Album, make sure

the POWER button is in the ON position, and

then press the MENU button for 2 seconds

To flip through images stored on your Photo

Album, use the UP/LEFT and DOWN/RIGHT

buttons.

Detailed Instructions:

Supported graphic formats

•BMP

•JPG

•GIF

Button Functions

1. UP/LEFT

2. MENU

3. DOWN/RIGHT

4. Power ON/OFF

This side shows the

navigation of

images on your PC

This side shows

images installed on

your Mini Photo

Album

Menu Functions:

OFF

DISPLAY MODE

CLOCK SET

POWER

CLOCK DISP

EXIT

OFF – This menu selection will turn the unit

off and save all data saved to the unit.

DISPLAY MODE - This menu selection will

allow you to set how the

images are displayed on

the screen. Selecting

AUTO SLIDE will then allow you to set

the interval time that

each image will stay on

screen before the next

image automatically

slides onto the screen

MANUAL SLIDE will allow you to

manually change images

using the UP/LEFT and

DOWN/RIGHT buttons

CLOCK SET – This selection will allow

you to set the unit’s clock

using the UP/LEFT and

DOWN/RIGHT buttons

to set the current date

and time

POWER - This selection lets you

set how the unit

automatically powers

on/off.

Selecting “ON” will put

the unit into an auto

power-off mode and if no

buttons are pushed the

unit will shut off after a

predetermined amount of

time. This function

saves battery power

Selecting OFF turns this

feature off and returns to

the main menu.

CLOCK DISP – This function allows you

to either set the screen

to display the current

date and time like a

watch, or to add the date

and time as a

“watermark” over top of

the images on the

screen:

Select the mode that you

want to use and then

press MENU to exit this

mode

EXIT - This selection exits the

menu screen and returns

to the image or clock

display

Disp Clock

Normal

Disp Clock

Watermark

Auto

ON/OFF

Auto ON/OFF

OFF

Specifications:

•Image storage capacity ~ 60 images

•Image formats: BMP, JPG, GIF

•Display size 1.5” SCSTN LCD 128x128

65k color resolution

•Power source: 3.7V lithium Ion

rechargeable battery

Included In Package:

•Mini Photo Album

•Software CD

•USB cable

•Key chain

•Instruction manual

•Product registration card

System Requirements:

•Windows 98/2000/ME/XP

•125MB of available hard drive space

•Color monitor

•CDROM drive

•USB 1.1 or 2.0 port

Nextar may find it necessary to modify, amend or

otherwise change or update this manual.

We reserve the right to do this at any time, without

any prior notice. All specifications and features are

subject to change without notice.

All screen shots shown are simulated and may not

represent the actual screen on production units sold

to consumers.

For instruction manuals, updated drivers or other

information, be sure to visit our website at:

www.Nextar.com

Or write us at:

Nextar

1661 Fairplex Dr.

LaVerne, CA USA 91750
