PRODUCT CATALOG

LSC-5

5-1/4" In-Ceiling Loudspeaker FG01077

For Accurate Music and Voice Reproduction from In-Ceiling Locations

• 5-1/4"polypropylenewooferwithurethanesurround

• 3/4"liquidcooledpolycarbonatedometweeter

• Moistureresistant

LSC-5R

5-1/4" In-Ceiling Loudspeaker with Recessed Grille FG01078

For Accurate Music Reproduction with the Appearance of a Light Fixture

• 5-1/4"polypropylenewooferwithurethanesurround

• 1/2"liquidcooledtweeter

• Moistureresistant

LSC-6

6-1/2" In-Ceiling Loudspeaker FG01079

For Accurate Music and Voice Reproduction from In-Ceiling Locations

• 6-1/2"talc-filledpolypropylenewooferwithtreatedfoamrubbersurround

• 3/4"pivotingliquidcooledpolycarbonatedometweeter

• MoistureandUVresistant

LSC-6.5

6-1/2" In-Ceiling Loudspeaker FG01080

For High Performance Music Reproduction from In-Ceiling Locations

• 6-1/2"injection-molded,graphitefilledpolypropylenewoofer

withbutylrubbersurround

• 1"pivotingliquidcooledsoftdometweeter

• Bafflemountedbassandtreblecontrols(0,-2db)

LSC-6S

6-1/2" Stereo In-Ceiling Loudspeaker FG01081

For Stereo Music Reproduction from a Single In-Ceiling Location

• 6-1/2"micafilledpolypropylenewooferwithtreatedfoamrubbersurround

• Dual3/4"stereoimagedliquidcooledpolycarbonatedometweeters

• MoistureandUVresistant

LSC-8

8" In-Ceiling Loudspeaker FG01199

For High Performance and Accurate Music Reproduction from In-Ceiling Locations

• 8"talcfilledpolypropylenewooferwithtreatedfoamrubbersurround

• 3/4"pivotingliquidcooledpolycarbonatedometweeter

• MoistureandUVresistant

SPEAKERS

2009

SPEAKERS

LSC-BG

6-1/2”Builder Grade: In-Ceiling Loudspeaker FG01527

For Music and Voice Reproduction from In-Ceiling Locations

•Specificallydesignedforin-ceilingapplications

• Wooferis6-1/2”polypropylenewithaurethanesurround

• Tweeteris3/4”fluid-cooledultra-widedispersionKaladex®

LSW-6

6-1/2" In-Wall Loudspeaker FG01082

For Accurate Music and Voice Reproduction from In-Wall Locations

• 6-1/2"talcfilledpolypropylenewooferwithatreatedurethanesurround

• 3/4"pivotingliquidcooledpolycarbonatedometweeter

• Moistureresistant

LSW-6.5

6-1/2" In-Wall Loudspeaker FG01083

For High Performance Music Reproduction from In-Wall Locations

• 6-1/2"injection-molded,graphitefilledpolypropylenewooferwithbutylrubbersurround

• 1"pivotingliquidcooledsoftdometweeter

• MoistureandUVresistant

LST-RLS

Right, Left, Surround In-Wall Loudspeaker FG01084

For High Performance HomeTheater Reproduction from In-Wall Locations

• Dual5-1/4"micafilledpolypropylenewoofers

withbutylrubbersurrounds

• 1"liquidcooledElastoDynamic®dometweeter

• Frontmountedbaseandtreblecutswitches(-3db)

LST-CTR

Center Channel In-Wall Loudspeaker FG01085

For High Performance HomeTheater Reproduction from In-Wall Locations

• Dual5-1/4"magneticshieldedmicafilledpolypropylenewooferswithbutylrubbersurround

• 1"liquidcooledmagneticshieldedElastoDynamic®dometweeter

• Frontmounteddialogswitch

LSS-10

10" 125 Watt, Compact Powered Subwoofer FG01238

For Powerful Bass in HomeTheater or Music Systems

• PowerfulAmplifierCircuitryProvidesDynamicPerformance

• 10”Injection-moldedPolypropyleneWooferWithButylRubberSurround

• RCALFEInputBypassesAllFilteredInputs

PRODUCT CATALOG

2009

PRODUCT CATALOG

SPEAKERS

LSS-12

12” Powered Subwoofer FG01239

For Powerful Bass in HomeTheater or Music Systems

•PowerfulAmplifierCircuitryProvidesDynamicPerformance

•12”Injection-moldedPolypropyleneWooferWithButylRubberSurround

•RCALFEInputBypassesAllFilteredInputs

•LeftAndRightLine-levelInputsIncludeafixed80HzHigh-passFilter

LSO-5

5" Indoor/Outdoor Loudspeaker FG01086

For Accurate Music and Voice Reproduction from Indoor and Outdoor Locations

• 5"micafilledpolypropylenewooferwithbutylrubbersurround

• 3/4"liquidcooledpolycarbonatedometweeter

• Glassandmineral-filledpolypropyleneenclosure

LSO-6

5" Indoor/Outdoor Loudspeaker FG01087

For High Performance Music Reproduction from Indoor and Outdoor Locations

• 5"micafilledpolypropylenewooferwithbutylrubbersurround

• 1"liquidcooledElastoDynamic®dometweeter

• Glassandmineral-filledpolypropyleneenclosure

LSO-7

5-1/4" Indoor/Outdoor Loudspeaker FG01088

For High Performance Music Reproduction from Indoor and Outdoor Locations

• 5-1/4"micafilledpolypropylenewooferwithbutylrubbersurround

• 1"liquidcooledElastoDynamic®dometweeter

• Glassandmineral-filledpolypropyleneenclosure

LSO-8

6-1/2" Indoor/Outdoor Loudspeaker FG01089

For High Performance Music Reproduction from Indoor and Outdoor Locations

• 6-1/2"micafilledpolypropylenewooferwithbutylrubbersurround

• 1"liquidcooledElastoDynamic®dometweeter

• Glassandmineral-filledpolypropyleneenclosure

LSR-5 GRAY

All Weather Rock Loudspeaker FG01090

For Lifelike Sound and Natural Looks Outdoors

• 5-1/4"micafilledpolypropylenewooferwithbutylsurround

• 1/2"liquidcooledsoftdometweeter

•Multi-layerfiberglassconstruction

2009

SPEAKERS

LSR-5 TAN

All Weather Rock Loudspeaker FG01206

For Lifelike Sound and Natural Looks Outdoors

• 5-1/4”micafilledpolypropylenewooferwithbutylsurround

• 1/2”liquidcooledsoftdometweeter

•Multi-layerfiberglassconstruction

LSR-6 GRAY

All Weather Rock Loudspeaker FG01091

For Lifelike Sound and Natural Looks Outdoors

• 6-1/4"micafilledpolypropylenewooferwithbutylsurround

• 1"liquidcooledsoftdometweeter

• Multi-layerfiberglassconstruction

LSR-6 TAN

All Weather Rock Loudspeaker FG01205

For Lifelike Sound and Natural Looks Outdoors

• 6-1/4"micafilledpolypropylenewooferwithbutylsurround

• 1"liquidcooledsoftdometweeter

• Multi-layerfiberglassconstruction

NCB-5

5" Ceiling Bracket FG01093

For Installing 5-1/4" In-Ceiling Speakers in New Construction

• Includeswingstospanstandardceilingjoists

• Scoredwingswithlevellinefacilitateeasy,flexible

andaccurateplacementbetweenjoists

• Willnotboworbucklesheetrock

NCB-6

6" Ceiling Bracket FG01092

For Installing 6-1/2" In-Ceiling Speakers in New Construction

• Includeswingstospanstandardceilingjoists

• Scoredwingswithlevellinefacilitateeasy,flexible

andaccurateplacementbetweenjoists

• Willnotboworbucklesheetrock

NCB-8

8" Ceiling Bracket FG01092

For Installing 8" In-Ceiling Speakers in New Construction

• Includeswingstospanstandardceilingjoists

• Scoredwingswithlevellinefacilitateeasy,flexible

andaccurateplacementbetweenjoists

• Willnotboworbucklesheetrock

PRODUCT CATALOG

2009

PRODUCT CATALOG

QUICK REFERENCE GUIDE

Model Part Number U/M Master Carton Pg

SPEAKERS

LSC-5 FG01077 Pair 4 1

LSC-5R FG01078 Pair 4 1

LSC-6 FG01079 Pair 4 1

LSC-6.5 FG01080 Pair 4 1

LSC-6S FG01081 Each 4 2

LSC-8 FG01199 Pair 4 2

LSW-BG FG01527 Pair 4 2

LSW-6 FG01082 Pair 4 2

LSW-6.5 FG01083 Pair 2 2

LST-RLS FG01084 Each Individual 2

LST-CTR FG01085 Each Individual 2

LSS-10 FG01238 Each 1 2

LSS-12 FG01239 Each 1 3

LSO-5 FG01086 Pair 2 3

LSO-6 FG01087 Pair 2 3

LSO-7 FG01088 Pair 2 3

LSO-8 FG01089 Pair 2 3

LSR-5 Gray FG01090 Each 4 3

LSR-6 Gray FG01091 Each 2 4

LSR-5 Tan FG01206 Each 2 4

LSR-6 Tan FG01205 Each 2 4

NCB-8 FG01200 Pair 4 4

NCB-6 FG01092 Pair 4 4

NCB-5 FG01093 Pair 4 4
