Nivona CafeRomatica 630 Istruzioni operative
CafeRomatica
Fully automatic coffee centre
Operating Instructions and Useful Tips
630
650
A passion for coffee.
Downloaded from CoffeeMachineManual.com Manuals
2
Operating Instructions and Useful Tips
Dear Customer,
Congratulations and many thanks for choosing a high-quality
NIVONA product. To get the most out of your NIVONA machine,
please read this manual carefully before use. Please start by
reading the safety notes.
Please keep this manual in a safe place. You may want to use
it as reference guide or hand it on to any further users of your
machine.
Purchase made at
Place, date
Downloaded from CoffeeMachineManual.com Manuals
3
Equipment
Bean container
with lid
A
Drip grill
J
Milk-frothing device
‘spumatore’, hot
water jet
R
Symbol display screen
B
Removable water
tank
C
Water quantity
control knob
D
On / Off button
E
Coffee strength
button
F
1-cup button
G
2-cup button
H
Height-adjustable
coffee spout
I
Drip tray
Fill level indicator
for drip tray
K
L
Pre-ground coffee
chamber
M
Cup holding plate
N
Steam warm-up /
rinse button
O
Steam / hot water
valve control knob
P
Grinder settings
(on rear)
Q
Nameplate with
model name
S
Power cord storage
compartment (on rear)
T
Used coffee tray
(inside)
U
Rear rollers, under-
neath, NICR650 only
V
Cup illumination,
NICR650 only
W
1
A
B
C
D
E
F
G
H
M
N
O
P
Q
R
S
T
U
V
W
I
J
K
L
Downloaded from CoffeeMachineManual.com Manuals
Equipment
234
5
8
9
10
6 7
aControl knob
bAir inlet valve
Air inlet pipe
cInlet valve
dSteam / hot water jet
eLiquid inlet hose
a
b
c
d
e
Downloaded from CoffeeMachineManual.com Manuals
Symbols
Number
11
12
13
14
15
16
17
18
19
20
Symbol Brief description
Coffee strength MILD
Coffee strength NORMAL
Coffee strength STRONG
Not enough coffee beans – fill container
Fill water tank
Pre-ground coffee
Hot water / steam, open / closed
Empty used coffee tray / drip tray
Descale machine
Clean machine
Flashing
Downloaded from CoffeeMachineManual.com Manuals
Contents
1. Safety instructions
2. Set up
2.1 Preparing the machine
2.2 Getting started
2.3 Grinder settings
3. Making coffee
3.1 Selecting coffee strength
3.2 Selecting water quantity
3.3 Making one cup
3.4 Making two cups
3.5 Using pre-ground coffee
3.6 Drawing hot water
3.7 Drawing steam / frothing milk
3.7.1 Drawing steam
3.7.2 Frothing milk, hot milk and cappuccino
4. Programming functions
4.1 Filter
Inserting filter
Operating without a filter
4.2 Water hardness
4.3 Temperature
4.4 Automatic switch off
4.5 ECO mode
5. Maintenance and care
5.1 Changing filter
5.2 Cleaning program
Manual cleaning
5.3 Descaling
Manual descaling
5.4 General cleaning
Cleaning the brewing unit
6. System messages
7. Troubleshooting
8. Further instructions
Downloaded from CoffeeMachineManual.com Manuals
7
1. Safety instructions
• The machine is for domestic use
only and is not suitable for
commercial applications. Other-
wise, claims under the guarantee
will not be accepted.
• Operating voltage must be the
same as mains voltage. Please
note the model nameplate /
sticker on the underside of the
machine (fig. 1/S).
• Do not operate the machine if
the power cord or machine case
is damaged.
• Keep the power cord away from
hot parts.
• Do not unplug the machine by
pulling on the power cord.
• Observe the cleaning & descal-
ing instructions provided. Other-
wise, claims under the guarantee
will not be accepted.
• Make sure to switch off and
unplug the machine before
maintenance or cleaning.
• Place the machine on a firm, level
surface and use it indoors only.
• Do not place the machine on a
hot surface or near open flames.
• Keep out of reach of children
and ensure that they do not play
with the appliance.
• Always unplug the machine
during extended periods of
absence.
• Do not leave the machine
switched on unnecessarily.
• Do not submerge the machine
in water.
• Do not put the machine or indi-
vidual parts in the dishwasher.
Otherwise, claims under the
guarantee will not be accepted.
• Unplug immediately if there is
a defect (do not pull the cord
or machine to unplug).
• Liability for damages cannot be
accepted if the machine is incor-
rectly operated, subject to im-
proper use or non-professional
servicing. In such cases, services
will not be provided under the
guarantee.
• Use the coffee grinder for grind-
ing roasted coffee beans only –
do not use with other foods.
Always make sure there is
nothing but coffee beans in the
beans container – otherwise the
guarantee will not apply.
• This machine is not suitable for
individuals (including children)
Downloaded from CoffeeMachineManual.com Manuals
8
with physical, sensory or mental
impairments, including indi-
viduals who do not have suffi-
cient experience or knowledge,
unless they are shown how to
operate the machine or initially
supervised by someone res-
ponsible for their safety.
If repair services are required,
including replacement of the
power cord, please first contact
your dealer or the service-hotline.
Afterwards send the machine to
the dealer from whom it was pur-
chased – or to NIVONA national
customer services.
Caution! Electrical appliances
must be repaired by qualified per-
sonnel! Non-professional repairs
can expose the user to significant
risks. Liability for damages cannot
be accepted if the machine is
used for any other than the in-
tended purpose, incorrectly main-
tained or serviced.
Caution! Using the on/off switch
(fig. 1/E) while the machine is
brewing can cause damage! Only
switch off the appliance when it is
in passive state.
Caution! Risk of scalding!
• Then you produce steam or hot
water, watch out for splashes
from the jet / ‘spumatore’
(fig. 1/R): risk of scalding!
• Only touch the plastic parts of
‘spumatore’ (fig. 1/R) and
never point it at people!
• The steam jet or ‘spumatore’
(fig. 1/R) becomes VERY HOT
during use. Leave to cool for a
few minutes before touching.
CE – This machine conforms to
EC guidelines.
Specifications
Mains voltage: 230 V
Power input: 1400 W
Note: Your fully automatic coffee
centre has a cord storage compart-
ment – if the power cord is too
long, any surplus can be accom-
modated in the storage area on
the rear of the machine (fig. 1/T).
... 1. Safety instructions
Downloaded from CoffeeMachineManual.com Manuals
9
2. Set up
2.1 Preparing the machine
➔ Carefully remove the machine
and all parts from the packaging.
Note: If you need to return your
machine for servicing, it can be
sent by post in the original packag-
ing. Please keep all packaging and
protective material for this pur-
pose.
➔ Remove the water reservoir (fig.
1/C and 2) and wash it out with
clean, cold tap water.
➔ Then fill the reservoir up to the
“max.” mark and replace it in the
machine. Make sure that it clicks
into place.
Note: Only ever fill the reservoir
with fresh, cold water. Do not use
carbonated water or other liquids!
➔ Open the lid of the coffee con-
tainer (fig. 1/A) and fill it with
coffee beans.
Note: Do not use beans which
have been treated with supple-
ments, such as sugar, during or
after the roasting. Supplements
can damage the grinding mecha-
nism and any repair costs arising
as a result are not covered by the
guarantee.
Please make sure the steam / hot
water valve control knob (fig. 1/P
and 5) is turned to ‘0’!
2.2 Getting started
➔ Plug the machine in.
➔ Press the On / Off button (fig.
1/E). In the display light up the
symbols , and one after
another (otherwise, please see
the following Note below).
➔ After a short time the steam /
rinse button ‘S’ (fig. 1/O) light
flashes.
➔ Place a cup under the height-
adjustable coffee spout (fig. 1/I
and 3) and press the steam / rinse
button ‘S’ (fig. 1/O).
➔ The system is then filled with
water and completely rinsed out via
the coffee spout. This operation
must always be carried out when
the machine is started from cold
to preserve the aroma of the cof-
fee. It ensures that no stale water
or coffee left over from previous
brews is used.
➔ All four operating buttons
(fig. 1/F, G, H, O) then light up,
and the selected coffee strength
is shown in the display by the
corresponding number of beans.
Downloaded from CoffeeMachineManual.com Manuals
10
➔ The machine is now operational.
Note: As a protective measure, the
pipes are not filled with water when
the machine is first operated. The
machine indicates this as follows:
➔ When the machine has been
turned on with the On / Off button
(fig. 1/E), Symbol .
➔ Place a cup under the steam /
hot water jet (fig. 1/R).
➔ Turn the steam / hot water valve
control knob (fig. 1/P and 5) to
the right to open the valve. The
system then fills up and some
water may come out of the jet (fig.
1/R).
➔ As soon as the symbol
lights up without flashing and the
filling operation has stopped auto-
matically, you can turn the valve
control knob (fig. 1/P and 5) back
again to close it.
➔ Then follow the steps in ‘2.2
Getting started’.
➔ The machine is now operational.
2.3 Grinder settings
Caution: Grinder settings can only
be adjusted when the grinder is in
operation. You can adjust the grin-
der settings to suit the roast of
your coffee beans. We recommend
that you leave the grinder on a
medium setting.
➔ Slide the regulator on the rear
side (fig. 1/Q) into the desired
position while the grinder is runn-
ing. The smaller the dot, the finer
the coffee is ground. Remember:
· a light roast requires a finer
grind
· a dark roast requires a coarser
grind
Try out the different settings to
find the one that best meets your
personal preferences.
... 2. Set up
Downloaded from CoffeeMachineManual.com Manuals
Questo manuale è adatto per i seguenti modelli
3
Indice
Altri manuali Nivona Macchina per il caffè
Nivona
Nivona caferomatica NICR8 series Istruzioni operative
Nivona
Nivona NICR7 Series Istruzioni operative
Nivona
Nivona CafeRomatica NICR 695 Manuale utente
Nivona
Nivona Cafe Romatica Manuale utente
Nivona
Nivona CafeRomatica 930 Manuale utente
Nivona
Nivona CafeRomatica NICR7 Manuale utente
Nivona
Nivona NICR646 Istruzioni per il montaggio
Nivona
Nivona CafeRomatica 605 Istruzioni operative
Nivona
Nivona CafeRomatica NICR9 Series Manuale utente
Nivona
Nivona CafeRomatica 7 Manuale utente
Nivona
Nivona CAFEROMATICA 710 Manuale utente
Nivona
Nivona caferomatica NICR8 series Manuale utente
Nivona
Nivona CafeRomantica NICR7 series Guida
Nivona
Nivona CafeRomatica NICR 520 Manuale utente
Nivona
Nivona NICR646 Manuale utente
Nivona
Nivona CafeRomatica 960 Manuale utente
Nivona
Nivona CafeRomatica NICR7 Manuale utente
Nivona
Nivona CAFEROMATICA 710 Manuale utente
Nivona
Nivona caferomatica NICR6 series Istruzioni operative
Nivona
Nivona CafeRomatica NICR626 Istruzioni per il montaggio
