Nivona CafeRomatica 930 Manuale utente
5 6 7 8910
Cafe Romatica
GB User manual
66 Control elements
CLARIS fresh water filter
Operating instructions
Warranty terms
Measuring spoon
2 Cleaning tablets
Test strips
(for measuring water hardness)
Connection tube for milk
WELCOME PACK
(included with machine)
2. CONTROL ELEMENTS
Frother
Type plate
(Remove drip tray)
Coffee grounds container
(inside)
Connection for milk tube
(in the drip tray)
Drip tray
Cover for coffee bean holder
Water tank with cover
On/off switch
Ground coffee shaft
Coffee bean holder
Display
Rotary dial
Height-adjustable
outlet with cover plate
(Frother behind)
Rear rollers (in back)
Cable compartment (in back)
Cup storage area
Service door with handle
(Brewing unit behind)
Connection for milk tube
(In the height-adjustable outlet)
7
3. Operation of the machine 7
Pressing
Turning
DE
GB
FR
NL
PL
RU
3. OPERATION OF THE MACHINE
3.1. Function switches
The NIVONA machine can be operated with the following switches:
3.2. Operation with the rotary dial
Turning
To select / navigate within the main menus Speciality Coffees, Settins and Maintenance,
and to change the setting options in the submenus and recipe menu.
Short press
To start / confirm the currently marked function.
In the Recipe menu, the first press selects the setting parameters and the next press
confirms the change.
A short press when the beverage is drawn cancels the procedure.
Long press
In the Speciality Coffees menu, a long press switches to the Recipe menu to change the
settings there.
Rotary dial
navigate / select / change /
confirm by turning
and pressing
>
Switch between the main
menus
exit
back / cancel / leave
menu
8 Initial startup
4.
3.3. Symbol functions
Currently marked symbol within
the menu is underlined. Symbol
description is displayed below the
menu
Cancellation of a beverage draw or
deletion of a stored MY COFFEE
speciality in the menu Speciality
Coffees
Flashing rotary dial symbol re-
quires confirmation
Start of a beverage draw in the
menu Speciality Coffees
Process progress in the menu
Maintenance
Store changes
Even durin a coffee draw that has already started, various parameters can be changed by
turning the dial as lon as they are optically marked.
A beverage draw can be cancelled either with exit or with . If the draw is cancelled while
the parameters are still flashing, the symbol must be pressed 2x.
4. INITIAL STARTUP
4.1. Preparation
Remove the machine and other supplied parts from the packaging
Place the machine on a level, dry surface
(Ventilation slots must not be covered)
Connect the mains supply cable to a power socket which has been correctly installed
(Any unnecessary length of cable remains inside the cable compartment)
9Initial Startup 9
CAUTION
Insert filter straiht and do not overturn!
Screw filter
into water
tank
NOTE
If used with a filter, the ma-
chine does not need to be
descaled as often.
NOTE
Details on Operation of the Machine are
contained in Chapter 3, starting at page 7.
i
DE
GB
FR
NL
PL
RU
Milk tube – connected
to drip tray
Connect milk tube to the height-adjustable outlet and drip tray
Switch on machine
If the machine is switched on after the initial startup, it first heats up. If the automatic
switch-on rinse is activated, the display shows System rinsin and the rinse procedure starts
automatically. If the automatic switch-on rinse is deactivated, the display shows Please rinse
system, and the rinse procedure must be started by pressing the rotary dial.
4.2. Initial Start menu
The instructions on the display lead you through the Initial Start menu conveniently and
step-by-step.
Set language
Select the language with the rotary dial and confirm
Set filter
Select filter setting with the rotary dial
Operation without filter (factory setting)
Set the menu to No and confirm
with the rotary dial
When using the machine without a filter,
the water hardness must be entered in
the next step.
Operation with filter
Set the menu to Yes
Using the mounting aid at the end
of the measuring spoon, screw the
filter into the water tank and confirm
using the rotary dial.
10 Initial startup
Fill coffee
beans
Fill/rinse
system
Fill water tank
NOTE
At initial startup, the grind
chamber is still empty. After
the first grinding, it is possible
that Please fill coffee beans
is displayed and the machine
does not make coffee.
Press the rotary dial again
for an additional draw; the pro-
cess is then repeated
Test strips Deree of
hardness
Water hard-
ness display
≤
1 red point
1 - 7° DEGREE 1
2 red points 8 - 14° DEGREE 2
3 red points 15 -21° DEGREE 3
(Factory setting)
≥4 red points > 21° DEGREE 4
Set water hardness*
Immerse supplied test strip briefly in water, shake it off and read the test result after
about 1 minute
In the menu, use the rotary dial to select the water hardness read from the test strip
and confirm
Fill water tank (> 0.5l)
Remove the water tank and fill it with fresh, cold water without carbonation (no mineral
water), reinsert the tank, and confirm using the rotary dial
Do not fill any carbonated liquids or any other liquids, or the warranty is void!
Fill coffee bean holder
Fill the coffee bean holder with untreated, roasted coffee beans without foreign objects
or dirt and without sugar, then close the flavour protection cover well and confirm using
the rotary dial
Fill / rinse system, rinse filter
Place a large container (> 0.5 l) under the outlet and confirm using the rotary dial
For operation with filter, a second confirmation with the rotary dial is necessary to fill
the system and rinse the filter
Wait until no more water comes out of the outlet, then empty the container
* For operation without filter
11Menu navigation
Prepare Speciality Coffees
6.5.
Speciality
Coffees
Settings Maintenance
Speciality
Coffees
Connect milk source
GB
FR
NL
PL
RU
DE
Operation tutorial
At the end of initial startup, a short tutorial on the machine’s operation appears. All operating
functions that should be performed when they appear are shown on the display one after
another. As soon as an operating function has been performed, the next one appears. The
tutorial is ended with exit.
All settings that were determined during initial startup can be changed at any time in the
Settins menu.
5. MENU NAVIGATION
In the NIVONA machine, you can select the main menus Settins, Speciality Coffees, and
Maintenance. All available functions of the machine can be carried out within these main
menus.
Detailed information on navigation within and between the main menus is found in Chapter
3 starting at page 7.
6. PREPARE SPECIALITY COFFEES
6.1. Draw speciality coffee
Select the desired speciality coffee in the Speciality Coffees menu
For speciality coffees with milk, connect the milk-filled container (milk container, milk
refrigerator, Tetra Pack, or similar) to the lower end of the milk tube. The upper end
remains in the outlet
A short press on the desired speciality coffee begins the beverage draw
>
Switch
between the
main menus
exit
Back / cancel /
leave menu
12 Prepare Speciality Coffees
Recipe menu
Save Start beverage draw
in the Recipe menu
Frother rinsingConnect tube
After completion of the draw of a speciality coffee with milk, the display shows the
message / instruction to rinse the frother. The frother should then be rinsed as soon
as possible, but at the latest before switching off the machine. To do this, reconnect the
tube to the drip tray, and select and confirm the message / instruction on the display
using the rotary dial. Follow the instructions in the display up to the end of the program
and confirm each time with the rotary dial.
6.2. Recipe menu
The Recipe menu is a submenu in the individual speciality coffees. Here, the factory recipe
settings can be changed individually and stored permanently.
A long press of the rotary dial on the symbol of a speciality coffee leads to the Recipe
menu of the beverage
Adjustable parameters in the Recipe menu:
Bean strenth 1- or 2-cup function Quantity
(Coffee / milk foam /
water / milk, depending
on the speciality coffee)
Temperature Flavour profile
(DYNAMIC, CON-
STANT, INTENSE)
A short press on the activated Save symbol saves the beverage recipe with the changed
parameters
A short press on the activated Start symbol begins the beverage draw with the changed
parameters
13Prepare Speciality Coffees
First milk
1 cup 2 cups
DYNAMIC CONSTANT INTENSE
First
coffee
DE
GB
FR
NL
PL
RU
6.3. 2-cup function*
To fill two cups directly next to each other from the same beverage draw, a second cup must
be placed under the outlet and then either
Press the rotary dial briefly twice in succession to start beverage preparation (for the
current draw) or
Change the cup symbol in the Recipe menu of the speciality coffee (as permanent
recipe setting)
6.4. Cappuccino Connaisseur
By changing the sequence in the sequence symbol, cappuccino / caffè latte enthusiasts can
set in the Recipe menu whether the milk or the coffee goes into the cup first.
6.5. Flavour profiles
Changing the flavour profile (DYNAMIC | CONSTANT | INTENSE) in the Recipe menu
changes the brewing process and extraction from the beans and thus the taste of the coffee
(see also Chapter 7.3. Aroma Balance System on page 16).
6.6. MY COFFEE (for individual speciality coffees)
Up to 9 different beverages can be individually set, named, and stored with the NIVONA
machine.
To do this, in the Speciality Coffees menu select the menu option MY COFFEE
Select an existing beverage with a long press or add a new one with +
* Not for CAFFÈ AMERICANO, HOT WATER, MY COFFEE, ground coffee
MY COFFEE
14 Prepare Speciality Coffees
NOTE
If you accidentally open the ground coffee
shaft – or have not started a beverage draw
after adding ground coffee – the machine
is automatically rinsed about one minute
after the cover is closed again and is then
ready for use again.
CAUTION
The ground coffee shaft is not a storage
container. Therefore, never add more than
one portion to the shaft and use only fresh
or vacuum-packed ground coffee from
coffee beans.
Water-soluble instant coffee must not be
used!
Select a base recipe (speciality coffee), assign a name (if necessary, delete the MY
COFFEE presetting and save the name with OK), set the recipe individually and save it
A stored MY COFFEE recipe can be changed or edited with a long press of the rotary
dial on the corresponding symbol and also removed through confirmation of deletion
6.7. Prepare round coffee
Open the cover of the ground coffee shaft (underneath the cover on the upper right of
the machine)
The display shows Fill round coffee and close shaft lid
Add a level measuring spoon of ground coffee
Close cover and flap
The display shows when the ground coffee is ready
Place a cup in the middle below the coffee outlet
Select the beverage in the Speciality Coffees menu
Start preparation
Fill ground coffee
Save Confirm
deletion
Indice
Altri manuali Nivona Macchina per il caffè
Nivona
Nivona caferomatica NICR8 series Manuale utente
Nivona
Nivona CafeRomatica 7 Manuale utente
Nivona
Nivona CafeRomatica 830 Istruzioni operative
Nivona
Nivona caferomatica NICR8 series Istruzioni operative
Nivona
Nivona caferomatica NICR6 series Istruzioni operative
Nivona
Nivona CafeRomatica NICR9 Series Manuale utente
Nivona
Nivona CafeRomatica 626 Manuale utente
Nivona
Nivona CafeRomatica NICR 520 Manuale utente
Nivona
Nivona CafeRomatica 720 Istruzioni operative
Nivona
Nivona CafeRomatica 630 Istruzioni operative
Nivona
Nivona CafeRomatica NICR 695 Manuale utente
Nivona
Nivona CafeRomatica NICR626 Istruzioni per il montaggio
Nivona
Nivona Cafe Romatica Manuale utente
Nivona
Nivona CAFEROMATICA 710 Manuale utente
Nivona
Nivona caferomatica 730 Manuale utente
Nivona
Nivona CafeRomatica NICR7 Manuale utente
Nivona
Nivona CAFEROMATICA 610 Manuale utente
Nivona
Nivona NICR646 Manuale utente
Nivona
Nivona cafefresco 410 Manuale utente
Nivona
Nivona CAFEROMATICA 710 Manuale utente
