Nokia BH 104 - Headset - Over-the-ear Manuale utente
Nokia Bluetooth Headset BH-104
8
2
1
4
3
5
6
7
910
11 12
2
2
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares
that this BH-104 product is in
compliance with the essential
requirements and other relevant
provisions of Directive 1999/5/EC. A
copy of the Declaration of Conformity
can be found at http://www.nokia.com/
phones/declaration_of_conformity/.
Hereby, NOKIA CORPORATION declares
that this BH-104A product is in
compliance with the essential
requirements and other relevant
provisions of Directive 1999/5/EC. A
copy of the Declaration of Conformity
can be found at http://www.nokia.com/
phones/declaration_of_conformity/.
© 2008-2009 Nokia. All rights reserved.
Nokia, Nokia Connecting People and the
Nokia Original Accessories logo are
trademarks or registered trademarks of
Nokia Corporation. Nokia tune is a
sound mark of Nokia Corporation. Other
product and company names mentioned
herein may be trademarks or
tradenames of their respective owners.
Reproduction, transfer, distribution, or
storage of part or all of the contents in
this document in any form without the
prior written permission of Nokia is
prohibited.
Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
Nokia operates a policy of ongoing
development. Nokia reserves the right to
make changes and improvements to any
of the products described in this
document without prior notice.
To the maximum extent permitted by
applicable law, under no circumstances
shall Nokia or any of its licensors be
responsible for any loss of data or
income or any special, incidental,
consequential or indirect damages
howsoever caused.
The contents of this document are
provided "as is". Except as required by
applicable law, no warranties of any
© 2008-2009 Nokia. All rights reserved.
3
kind, either express or implied,
including, but not limited to, the implied
warranties of merchantability and
fitness for a particular purpose, are
made in relation to the accuracy,
reliability or contents of this document.
Nokia reserves the right to revise this
document or withdraw it at any time
without prior notice.
The availability of particular products
may vary by region. Please check with
your Nokia dealer for details.
Export Controls
This device may contain commodities,
technology or software subject to export
laws and regulations from the US and
other countries. Diversion contrary to
law is prohibited.
Introduction
With the Nokia Bluetooth Headset
BH-104, you can make and receive
calls while on the move.
Read this user guide carefully
before using the headset. Also,
read the user guide for your phone.
This product may contain small
parts. Keep them out of the reach
of small children. The surface of
this device is nickel-free.
Bluetooth wireless
technology
Bluetooth wireless technology
allows you to connect compatible
devices without cables. The phone
and the headset do not need to be
in line of sight, but they should be
within 10 metres (33 feet) of each
other. Connections may be subject
to interference from obstructions,
such as walls, or other electronic
devices.
© 2008-2009 Nokia. All rights reserved.
4
4
The headset is compliant with
Bluetooth Specification 2.1 + EDR
supporting the Headset Profile 1.1
and Hands-Free Profile 1.5. Check
with the manufacturers of other
devices to determine their
compatibility with this device.
Get started
The headset contains the
following parts shown on the title
page: indicator light (1), earloop
(2), volume keys (3), answer/end
key (4), earpiece (5), power key (6),
charger connector (7), and
microphone (8).
Before using the headset, you
must charge the battery and pair
the headset with a compatible
phone.
Parts of the device are magnetic.
Metallic materials may be
attracted to the device. Do not
place credit cards or other
magnetic storage media near the
device, because information
stored on them may be erased.
Charge the battery
Before charging the battery,
carefully read “Battery and
charger information”.
Warning: Use only
chargers approved by
Nokia for use with this
particular model. The use
of any other types may
invalidate any approval or
warranty, and may be
dangerous.
© 2008-2009 Nokia. All rights reserved.
5
When you disconnect the power
cord of any accessory, grasp and
pull the plug, not the cord.
1. Connect the charger to a wall
outlet.
2. Connect the charger cable to
the charger connector. The red
indicator light is displayed
during charging. Charging the
battery fully may take up to 2
hours.
3. When the battery is fully
charged, the green indicator
light is displayed. Disconnect
the charger from the headset,
then from the wall outlet.
The fully charged battery has
power for up to 10 hours of talk
time or up to 200 hours of standby
time.
To check the battery charge when
the headset is not connected to a
charger, press the power key. If the
indicator light is green, the charge
level is sufficient. If the light is
yellow, you may need to recharge
the battery soon. If the light is red,
recharge the battery.
When the battery charge is low,
the headset beeps every 5 minutes
and the red indicator light flashes.
Switch on or off
To switch on, press and hold the
power key for about 2 seconds. The
headset beeps, and the green
indicator light is displayed. The
headset tries to connect to a
paired phone.
To switch off, press and hold the
power key for about 2 seconds
when the headset is on. The
headset beeps, and the red
indicator light is briefly displayed.
If the headset is not connected to
a phone within about 30 minutes,
it switches off automatically.
© 2008-2009 Nokia. All rights reserved.
6
6
Pair and connect the headset
Before using the headset, you
must pair and connect it with a
compatible phone.
1. Ensure that your phone is on
and the headset is off.
2. Press and hold the power key
(for about 5 seconds) until the
green indicator light starts to
flash quickly.
3. Within about 3 minutes,
activate the Bluetooth feature
on the phone, and set it to
search for Bluetooth devices.
4. Select the headset from the list
of found devices.
5. If necessary, enter the passcode
0000 to pair and connect the
headset to your phone. In some
phones, you may need to make
the connection separately after
pairing.
When the headset is connected to
your phone and is ready for use,
the green indicator light flashes
about every 5 seconds.
Basic use
Place the headset on the ear
The headset is ready to be used on
the left ear. To use the headset on
the right ear, rotate the earloop so
that it is to the right of the Nokia
logo (11 and 12).
Slide the earloop behind your ear
(9), and gently push the earpiece
against your ear. Carefully bend
© 2008-2009 Nokia. All rights reserved.
7
the earloop around your ear for
the best fit. Push or pull the
earloop to set its length. Point the
headset towards your mouth (10).
Calls
To make a call, use your phone in
the normal way when the headset
is connected to it.
To redial the number you last
called (if your phone supports this
feature with the headset), when
no call is in progress, press the
answer/end key twice.
To activate voice dialling (if your
phone supports this feature with
the headset), when no call is in
progress, press and hold the
answer/end key for about 2
seconds. Proceed as described in
the phone user guide.
To answer or end a call, press the
answer/end key. To reject a call,
press this key twice.
To adjust the volume, press either
volume key.
To mute or unmute the
microphone, press both volume
keys at the same time. When the
microphone is muted, the green
indicator light flashes twice about
every 5 seconds.
To switch a call from the headset
to a compatible phone, press and
hold the answer/end key for about
2 seconds, or switch off the
headset. To switch the call back to
the headset, press and hold the
answer/end key for about 2
seconds, or switch on the headset.
Turn lights on or off
By default, the indicator lights are
shown in all situations. To turn the
© 2008-2009 Nokia. All rights reserved.
8
8
lights off in some situations (for
example, during a call or when the
headset is connected to a phone)
or back on, press and hold the
power key and the answer/end key
for about 5 seconds when the
headset is connected to a phone.
Clear settings or reset
To delete the pairings from the
headset when it is switched off,
press and hold the power key and
the answer/end key (for about 5
seconds) until the red and green
indicator lights start to alternate.
To reset the headset if it stops
functioning, even though it is
charged, connect the headset to a
charger while you press and hold
the power key.
Troubleshooting
If you cannot connect the headset
to your compatible phone, check
that the headset is charged,
switched on, and paired with your
phone.
Battery and charger information
This device has an internal,
nonremovable, rechargeable battery.
Do not attempt to remove the battery
from the device as you may damage
the device. This device is intended for
use when supplied with power from
the following chargers: AC-3, AC-4,
AC-5, AC-8, and DC-4. The exact
charger model number may vary
depending on the type of plug. The
plug variant is identified by one of
the following: E, EB, X, AR, U, A, C, or
UB. The battery can be charged and
discharged hundreds of times, but it
© 2008-2009 Nokia. All rights reserved.
9
will eventually wear out. Recharge
your battery only with Nokia
approved chargers designated for
this device. Use of an unapproved
charger may present a risk of fire,
explosion, leakage, or other hazard.
If a battery is being used for the first
time or if the battery has not been
used for a prolonged period, it may be
necessary to connect the charger,
then disconnect and reconnect it to
begin charging the battery. If the
battery is completely discharged, it
may take several minutes before the
charging indicator light is displayed.
Unplug the charger from the
electrical plug and the device when
not in use. Do not leave a fully
charged battery connected to a
charger, since overcharging may
shorten its lifetime. If left unused, a
fully charged battery will lose its
charge over time.
Always try to keep the battery
between 15°C and 25°C (59°F and
77°F). Extreme temperatures reduce
the capacity and lifetime of the
battery. A device with a hot or cold
battery may not work temporarily.
Battery performance is particularly
limited in temperatures well below
freezing.
Do not dispose of batteries in a fire as
they may explode. Batteries may also
explode if damaged.
Never use any charger that is
damaged.
© 2008-2009 Nokia. All rights reserved.
10
10
Important: Battery talk
and standby times are
estimates only and
depend on network
conditions, features used,
battery age and
condition, temperatures
to which battery is
exposed, and many other
factors. The amount of
time a device is used for
calls will affect its
standby time. Likewise,
the amount of time that
the device is turned on
and in the standby mode
will affect its talk time.
© 2008-2009 Nokia. All rights reserved.
Altri manuali per BH 104 - Headset - Over-the-ear
2
Questo manuale è adatto per i seguenti modelli
1
Indice
Altri manuali Nokia Cuffia
Nokia
Nokia BH 102 - Headset - Over-the-ear Manuale utente
Nokia
Nokia LPS-4 Manuale utente
Nokia
Nokia HS-16 Manuale utente
Nokia
Nokia BH-902 Manuale utente
Nokia
Nokia WH-800 Manuale utente
Nokia
Nokia HS 36W Manuale utente
Nokia
Nokia HDW 3 - Headset - Over-the-ear Manuale utente
Nokia
Nokia HS 11W Manuale utente
Nokia
Nokia HS 3W Manuale utente
Nokia
Nokia BH-108 Manuale utente
Nokia
Nokia HS 26W - Headset - Over-the-ear Manuale utente
Nokia
Nokia BH-204 Manuale utente
Nokia
Nokia BH-607 Manuale utente
Nokia
Nokia BH-106 Black Manuale utente
Nokia
Nokia HDE-2 - Headset - Ear-bud Manuale utente
Nokia
Nokia BH-803 - Headset - Over-the-ear Manuale utente
Nokia
Nokia Bluetooth Headset BH-701 Manuale utente
Nokia
Nokia 9232254 Manuale utente
Nokia
Nokia HS-69 - Headset - Ear-bud Guida rapida
Nokia
Nokia BH 213 - Headset - Over-the-ear Manuale utente
