Norac UC4.5 Manuale utente
H
A
RDI Economy
HPZ and HAZ (18-30m) DAH09
Installation Manual
HD11
Printed in Canada
Copyright 2012 by NORAC Systems International Inc.
Reorder P/N: UC4.5-BC-HD11-INST Rev B (HARDI Economy HPZ and HAZ (18-30m) DAH09)
NOTICE: NORAC Systems International Inc. reserves the right to improve products and their specifications without notice and
without the requirement to update products sold previously. Every effort has been made to ensure the accuracy of the information
contained in this manual. The technical information in this manual was reviewed at the time of approval for publication.
Contents
1Introduction................................................................................................................ 1
2General UC4.5 System Layout................................................................................. 2
3Kit Parts ...................................................................................................................... 3
4Ultrasonic Sensor Installation .................................................................................. 5
5Roll Sensor Installation............................................................................................ 10
6Electrical Installation ............................................................................................... 12
7Software Setup......................................................................................................... 15
8Cable Drawings ........................................................................................................ 16
1
1Introduction
Congratulations on your purchase of the NORAC UC4.5 Spray Height Control System. This
system is manufactured with top quality components and is engineered using the latest
technology to provide operating reliability unmatched for years to come.
When properly used the system can provide protection from sprayer boom damage, improve
sprayer efficiency, and ensure chemicals are applied correctly.
Please take the time to read this manual completely before attempting to install the system. A
thorough understanding of this manual will ensure that you receive the maximum benefit from
the system.
Your input can help make us better! If you find issues or have suggestions regarding the parts
list or the installation procedure, please don’t hesitate to contact us.
Every effort has been made to ensure the accuracy of the information contained in
this manual. All parts supplied are selected to specially fit the sprayer to facilitate
a complete installation. However, NORAC cannot guarantee all parts fit as
intended due to the variations of the sprayer by the manufacturer.
Please read this manual in its entirety before attempting installation.
2
2General UC4.5 System Layout
Figure 1 illustrates the general layout of the UC4.5 system components:
Figure 1: General UC4.5 System Layout
Do not use high speed power tools/drills when installing hardware.
The use of dielectric grease is not recommended on any NORAC electrical
connections.
To ensure all stainless steel hardware does not gall or seize apply a light coating of
the supplied Permatex Anti-seize grease to all threaded parts upon installation.
Permatex Anti-seize lubricant is preferred, but other similar anti-seize products
may be used.
3
3Kit Parts
3.1 Kit Overview
Figure 2: HD11 System Parts
4
3.2 List of Parts
Item Part Number Name Quantity
B06 105728 RAM-233 RAIL MOUNT ADAPTER KIT FOR RAM-202 BASE 1
B10 44728 MOUNTING BRACKET COMPLETE UC4 BREAKAWAY EXTENDED 2
B11 44695-15 MOUNTING BRACKET UC4 SENSOR HARDI COMMANDER ML 1
B14 100610 BOLT HEX 3/8X1 STAINLESS STEEL 4
B15 100947 WASHER LOCK SPRING SS 3/8 IN 4
C05 43210-20 CABLE UC5 NETWORK 18 AWG 20M 2
C07 43220-01 CABLE UC5 NETWORK 14 AWG 1M 1
C10 44650-52 CABLE UC4.5 POWER HARDI 1
C11 44651-51 CABLE UC4.5 EXTENSION VALVE HARDI 1
C12 44658-78 CABLE INTERFACE HARDI DAH09 1
C17 44658-107 CABLE UC4.5 INTERFACE TWIN/FORCE DEMO 1
E01 45100 UC4.5 BOOM CONTROL PANEL 1
E04 43741 UC5 ROLL SENSOR VER. 2 2
E05 43750 UC5 ULTRASONIC SENSOR 3
E11 43765 UC5 NETWORK COUPLER 8-WAY 1
E12 43764 UC5 NETWORK COUPLER 2-WAY 1
E20 43764T UC5 NETWORK COUPLER 2-WAY WITH TERMINATOR 2
M01
UC4.5-BC-MANUAL-
OPERATOR
OPERATOR MANUAL UC4.5 SPRAY HEIGHT CONTROL 1
M02 UC4.5-BC-HD11-INST MANUAL INSTALLATION UC4.5 HARDI ECONOMY HPZ AND HAZ (18-30M) 1
M10 102084 TOOL PIN REMOVAL G.P. WITH NORAC LOGO 1
P03 105882 UC5 NETWORK 6 PIN PLUG 2
5
4Ultrasonic Sensor Installation
4.1 Bracket Assembly
Assemble the breakaway sensor bracket as illustrated in Figure 3, following the instructions
below.
Figure 3: Breakaway Bracket Assembly
1. Compress the spring and insert it together with the collar into the base.
2. Slide the tube through the assembled part.
3. Using the bolt and nut, tighten the collar to the tube with the sensor tube centered.
4. Apply a small amount of grease to the rotating surfaces of the bracket.
6
4.2 Ultrasonic Sensor Serial Number Arrangement
When installing the sensors, start with the smallest serial number on the left-hand side, and
proceed to the largest serial number on the right hand side. Each sensor has a serial number
stamped on the sensor housing.
Apply a light coating of the supplied Permatex Anti-seize grease to all threaded
parts upon installation.
Figure 4: Sensor Serial Number Arrangement
7
4.3 Ultrasonic Sensor Mounting Guidelines
The following guidelines will ensure optimal sensor performance and prevent sensor
measurement error. These rules should be followed for both the wing sensors and the main
lift (middle) sensor.
1. In its lowest position, the sensor must be 9 inches (23 cm) or more from the ground (A).
2. The centerline of the acoustic cone should be approximately vertical at normal operating
heights (A).
3. The bottom of the sensor must be at least 9 inches in front of the spray nozzles and boom
structure (B). (This does not apply for the main lift sensor)
4. The bottom of the sensor must be at least 9 inches above the spray nozzles (C).
5. Ensure there are no other obstructions with a 12 inch (23 cm) diameter circle projected
directly below the sensor (D).
6. The sensor bracket should be oriented forward (ahead of the boom).
7. Mount the NORAC ultrasonic sensor into the sensor bracket and run the sensor cable
through the sensor tube.
A problem can arise if a sensor is not mounted correctly. It is possible for the
sensor to read off of the boom instead of the ground. This may only become
apparent once the control system is switched from soil to crop mode.
Also be careful that the sensor bracket does not collide with any other part of the
boom when the boom is folded to transport position. If possible, mount the sensor
brackets while the booms are folded to ensure they will not cause interference.
Figure 5: Sensor Mounting Guidelines
Figure 6: Sensor Reading Off Boom
