Norcold DE-0041 Manuale utente

PART NO.624379

NORCOLD 02/27/2008

EV0041

DE0041T

DV0041 SERIES

DE0041

PARTS LIST

DV0041 SERIES PARTS LIST - PAGE 2

DOOR - (FRESH FOOD) - DV0041 SERIES

NO. PART # DESCRIPTION DE0041 DE0041T EV0041

1 621669 DOOR LINER ASSY-FOAMED X X X

2 618510 HINGE-DOOR SIDE/TOP LH/BTM RH/BLACK X X X

3 621667 PANEL RETAINER-BLACK/HINGESIDE X X X

4 618511 HINGE-DOOR SIDE/TOP RH/BTM LH/BLACK X X X

5 623696 BIN-DOOR-LARGE WHITE X X X

6 618619 BIN-DOOR SHELF/SMALL/WHITE X X X

7 621668 PANEL RETAINER-BLACK/HANDLE SIDE X X X

8 621520 DOORHANDLEASSY-VERTICAL X X X

9 618160 CAP-HINGEPLUG/BLACK X X X

NS 619569 BOLT-CAP SHOULDER/TORX HEAD X X X

NS = NOT SHOWN

DV0041 SERIES PARTS LIST - PAGE 3

CABINET ASSEMBLY - FRONT VIEW - DV0041 SERIES

DV0041 SERIES PARTS LIST - PAGE 4

CABINET ASSEMBLY - FRONT VIEW - DV0041

NO. PART # DESCRIPTION DE0041 DE0041T EV0041

1 161013400 COOLING UNIT-DE0041/EV0041 X X X

2 160928900 FANONLY-50 CYCLE/40 WATT X X X

3 169000500 POWER SUPPLY-AC (SP-243B) X X

169000510 POWERSUPPLY-AC (SP-260A) X

4 621634 GRILL-TOP/VENTILATION X X X

5 163011200 POWER SUPPLY-DC (SP-295) X X

163011210 POWERSUPPLY-DC (SP-294) X

6 FUSE-BLADE/10 AMP/DC POWER SUPPLY (AUTOMOTIVE SUPPLY) X X X

7 160220100 KNOB-THERMOSTAT X X X

8 623119 SWITCH-CABINET LIGHT X X X

9 61630422 ICECUBETRAY-PLASTIC X X X

10 621557 STRIKEPLATE-BLACK X X X

11 623123 TRIM PIECE-SIDE/RH X X X

12 619117 EVAPORATOR DOOR ASSY X X X

13 61632930 MOUNTING CLIP-RH/WHITE/EVAPORATOR DOOR X X X

NS 619041 SPRING HOLDER ASSY-RH/EVAP DOOR/SILVER SPRING X X X

14 61633030 MOUNTING CLIP-LH/WHITE/EVAPORATORDOOR X X X

NS 619042 SPRING HOLDER ASSY-LH/EVAP DOOR/YELLOW SPRING X X X

15 621629 DRIP TRAY-INSIDE/EVAPORATOR X X X

16 617756 TRAY-SHELF/WHITE/CUT OUT X X X

17 621678 SHELF-WIRE/WITH CUTOUT X X X

NS 623121 CLAMP-SHELF RETAINING LOOP 3/8" X X X

18 621573 GRILL ASSY-BOTTOM X X X

19 619335 HINGE-CABINET/3 POINT/TOP RH/BTM LH/PANEL/BLACK X X X

20 618144 HINGE BUSHING-DOOR HINGE/BLACK X X X

21 618145 HINGE PIN-DOOR/PANEL DOORS/BLACK X X X

22 623133 CHANNEL-BOTTOM RAIL X X X

23 623124 TRIM PIECE-SIDE/LH X X X

24 61629722 LAMP BRACKET ASSY X X X

NS 61628922 LAMP-GE#214-2/DC LIGHT BULB X X X

NS 621827 COVER-LAMP BRACKET X X

26 621697 COVER-STRIKEPLATE/BLACK X X X

26 619336 HINGE-CABINET/3 POINT/TOP LH/BTM RH/PANEL/BLACK X X X

27 169000700 CIRCUIT BOARD-LIGHT CONTROL X X X

NS = NOT SHOWN

DV0041 SERIES PARTS LIST - PAGE 5

CABINET ASSEMBLY - REAR VIEW - COOLING UNIT AREA - DV0041 SERIES

DV0041 SERIES PARTS LIST - PAGE 6

CABINET ASSEMBLY - REAR VIEW - COOLING UNIT AREA - DV0041 SERIES

NO. PART # DESCRIPTION DE0041 DE0041T EV0041

1 169000700 CIRCUIT BOARD-LIGHT CONTROL X X X

2 163011200 POWER SUPPLY-DC (SP-295) X X

163011210 POWERSUPPLY-DC (SP-294) X

3 FUSE-BLADE/10 AMP/DC POWER SUPPLY (AUTOMOTIVE SUPPLY) X X X

4 169000500 POWER SUPPLY-AC (SP-243B) X X

169000510 POWERSUPPLY-AC (SP-260A) X

5 160928900 FANONLY-50 CYCLE/40 WATT X X X

6 623153 BRACKET-FAN X X X

7 322066300 HOLDER-CONDENSER X X X

8 161013400 COOLING UNIT X X X

9 621617 FOAM PLUG PANEL ASSY-EVAPORATORACCESS X X X

10 621571 GASKET-EVAPORATORPLUG X X X

11 322066400 HOLDER-CONDENSER X X X

12 623133 CHANNEL-BOTTOM RAIL X X X

NS 190282000 COUPLER ASSY-DC INPUT CORD X X X

NS FUSE-GLASS/10 AMP/DC CORD (AUTOMOTIVE SUPPLY) X X X

NS 192116604 CORD WITH TERMINAL-GROUND CORD X X X

NS 190264700 COUPLER ASSY-COOLING UNIT TO EXTENSION X X X

NS 601064730 COUPLER ASSY-DC POWER SUPPLY TO CORD/COOLING UNIT X X X

NS 601064830 COUPLER ASSY-DC POWER SUPPLY TO FAN X X X

NS 601064600 COUPLER ASSY-DC POWER SUPPLY TO THERMISTER X X X

NS 605505420 THERMISTER-EVAPORATOR X X X

NS = NOT SHOWN
