PARTS LIST

PART NO.619728

NORCOLD 10/21/2002

DE561

DE561F DE561FT

DE560

EV560

EV561

DE56/EV56 SERIES

DE56/EV56 SERIES PARTS LIST - PAGE 2

DOOR - UPPER (FREEZER) - DE56/EV56 SERIES

NO. PART # DESCRIPTION DE560 DE561

DE561F

DE561FT EV560 EV561

1 61567830 DOOR GASKET-UPPER/GRAY X X X X X

2 61631330 HINGE PLATE-BLACK/RH TOP/LH BOTTOM/PLASTIC X X X X X

3 61689938 DOOR LINER ASSY-FOAMED/UPPER/BLACK/WHITE X X X X X

NS 61592930 PANEL HOLDER-BLACK/UPPER DOOR (NOT SHOWN) X X X X X

4 61743638 DOOR HANDLE ASSY-UPPER/BLACK X X X X X

5 61593830 END CAP-BLACK/STOP CATCH X X X X X

6 61743622 DOOR HANDLE WITH DECAL-UPPER X X X X X

7 61593730 END CAP-BLACK/SPRING CATCH X X X X X

NS 61558822 SPRING-DOOR HANDLE (NOT SHOWN) X X X X X

8 61631430 HINGE PLATE-BLACK/LH TOP/RH BOTTOM/PLASTIC X X X X X

9 61580525 JUICE RACK-WHITE X X X X X

10 61564025 BIN-DOOR SHELF/WHITE X X X X X

DE56/EV56 SERIES PARTS LIST - PAGE 3

DOOR - LOWER (FRESH FOOD) - DE56/EV56 SERIES

NO. PART # DESCRIPTION DE560 DE561

DE561F

DE561FT EV560 EV561

1 61567930 DOOR GASKET-LOWER/GRAY XXXXX

2 61631330 HINGE PLATE-BLACK/RH TOP/LH BOTTOM/PLASTIC XXXXX

3 61690038 DOOR LINER ASSY-FOAMED/LOWER XXXXX

NS 61593030 PANEL HOLDER-BLACK/LOWER DOOR (NOT SHOWN) XXXXX

4 61743738 DOOR HANDLE ASSY-LOWER/BLACK XXXXX

5 61593830 END CAP-BLACK/STOP CATCH XXXXX

6 61743722 DOOR HANDLE WITH DECAL-LOWER XXXXX

7 61593730 END CAP-BLACK/SPRING CATCH XXXXX

NS 61558822 SPRING-DOOR HANDLE (NOT SHOWN) XXXXX

8 61631430 HINGE PLATE-BLACK/LH TOP/RH BOTTOM/PLASTIC XXXXX

9 61579425 BIN-MILK/WHITE (2 PER DOOR) 22222

10 61564025 BIN-DOOR SHELF/WHITE (5 PER DOOR) 55555

11 617760 DAIRY KEEPER-WHITE/BLUE TRIM X X

DE56/EV56 SERIES PARTS LIST - PAGE 4

CABINET ASSEMBLY - FRONT VIEW - DE56/EV56 SERIES

DE56/EV56 SERIES PARTS LIST - PAGE 5

CABINET ASSEMBLY - FRONT VIEW - DE56/EV56 SERIES

NO. PART # DESCRIPTION DE560 DE561

DE561F

DE561FT EV560 EV561

161578522 DOORLATCH XXXXX

261630422 ICECUBETRAY-PLASTIC XXXXX

361580830 HINGEBRACKET-RHTOP/LHBTM/BLACK XXXXX

461578130 HINGEPIN-BLACK/MALE XXXXX

NS61580630 HINGEPIN-BLACK/TOP/BOTTOMHINGE/FEMALE(NOTSHOWN)XXXXX

561566730 HINGEPINSHAFT-BLACK/ATCENTERHINGE XXXXX

661580722 HINGEBUSHING-ATCENTERHINGE XXXXX

761566530 HINGEBRACKET-BLACK/CENTERHINGE XXXXX

8618056 SHELF-WIRE/WHITE/FLIPPER XXXXX

NS618065 CAP-CLEAR/FORFLIPPERSHELF(NOTSHOWN) XXXXX

9618052 SHELF-WIRE/MIDDLE XXXXX

10618055 SHELF-WIRE/CUTOUT XXXXX

NS617756 TRAY-SHELF/WHITE/CUTOUT(NOTSHOWN) XXXXX

NS61580222 RETAINER-WIRESHELF(NOTSHOWN) XXXXX

1161564122 CRISPERCOVER-GLASSSHELF XXXXX

NS61580322 RETAINER-GLASSSHELF(NOTSHOWN) XXXXX

1261571325 CRISPER-WHITE XXXXX

1361580930 HINGEBRACKET-LHTOP/RHBTM/BLACK XXXXX

1461622130 FRONTCOVER-BLACK/REPLACEABLEBOTTOMTRIM XXXXX

1561691222 THERMOSTAT XXXXX

160206700KNOB-THERMOSTAT XXXXX

1661686622 COVERPLATE-THERMOSTAT XXXXX

1761686722 COVERPLATE-FRONT/BLACK XXXXX

1861772122 BOTTOMPAN-SUPPORTASSY XXXXX

1961691310 DRIPTRAY XXXXX

NS61706522 HOLEPLUG-FORDRIPTRAY(NOTSHOWN) XXXXX

NS61693622 RETAININGCLIP-DRIPTRAY(NOTSHOWN) XXXXX

NS61579730 CAP-SNAPON/BLACK/INSTALLATIONHOLES(NOTSHOWN) XXXXX

DE56/EV56 SERIES PARTS LIST - PAGE 6

CABINET ASSEMBLY - REAR VIEW - COOLING UNIT AREA - DE56/EV56 SERIES

NO. PART # DESCRIPTION DE560 DE561

DE561F

DE561FT EV560 EV561

1 61691122 POWER SUPPLY (USE 16011552009) X X X

16011552009 KIT-POWER SUPPLY-DE56 X X X

61700822 POWER SUPPLY (USE 16011501009) X X

16011501009 KIT-POWER SUPPLY/EV56 XX

163009100 OSCILLATOR ONLY-DE561 (USE 16011552009 POWER SUPPLY KIT) X X X

163009110 OSCILLATOR ONLY (USE 16011501009 POWER SUPPLY KIT) X X

196014200 TRANSFORMER ASSY (USE 16011552009 POWER SUPPLY KIT) X X X

196014230 TRANSFORMER ASSY (USE 16011501009 POWER SUPPLY KIT) X X

NS 16092850009 FAN KIT ASSY (NOT SHOWN) X X X

261691522 PANELCOVER-UPPERBACK XXXXX

361691938 FOAMPLUGASSY XXXXX

4 617843 COOLING UNIT X X F

620075 COOLING UNIT-DE561FT FT

617844 COOLING UNIT XX

NS605503202THERMISTER-EVAPORATOR(NOTSHOWN) XXXXX

NS605503310THERMISTER-WIRECONDENSER(NOTSHOWN) XXXXX

NS190228620CORDASSY-COMPRESSOR(NOTSHOWN) XXXXX

NS191224800CORDASSY-EXTENSION/EVAPORATORTHERMISTER(NOTSHOWN)XXXXX

NS192116605CORDWITHTERMINAL-GROUNDCORD(NOTSHOWN) XXXXX
