Nuvoton NuMaker Tomato Manuale utente

NuMaker Tomato

Sep. 30, 2016 Page 1of 25 Rev 1.00

NUMAKER TOMATO USER MANUAL

ARM® 926EJ-S

32-bit Microprocessor

NuMaker Tomato User Manual

The information described in this document is the exclusive intellectual property of

Nuvoton Technology Corporation and shall not be reproduced without permission from Nuvoton.

Nuvoton is providing this document only for reference purposes of NuMicro microcontroller based system

design. Nuvoton assumes no responsibility for errors or omissions.

All data and specifications are subject to change without notice.

For additional information or questions, please contact: Nuvoton Technology Corporation.

www.nuvoton.com

NuMaker Tomato

Sep. 30, 2016 Page 2of 25 Rev 1.00

NUMAKER TOMATO USER MANUAL

Table of Contents

1Overview.............................................................................................3

2Hardware Features ................................................................................4

2.1 NuMaker Tomato Board Features .................................................................. 4

2.2 NUC976DK62Y Features............................................................................. 5

3Board Extension Interfaces.......................................................................7

4Getting Started with NuMaker Tomato........................................................ 10

4.1 Download Software Package and USB CDC Driver ............................................10

4.2 Install Nuvoton USB CDC Driver...................................................................10

4.3 Copy Software Package to MicroSD Card........................................................11

4.4 Connect and Set Up Hardware.....................................................................11

4.5 Open USB CDC Serial COM Port..................................................................12

5Example of Executing Sample Code.......................................................... 14

6Appendix........................................................................................... 15

6.1 Schematics ............................................................................................15

6.2 Python API.............................................................................................22

6.2.1 I2C (pysmbus) ................................................................................................. 22

6.2.2 SPI (spidev).................................................................................................... 22

6.2.3 GPIO (gpio).................................................................................................... 22

6.2.4 PWM (pwm).................................................................................................... 23

6.2.5 ADC (adc)...................................................................................................... 23

6.2.6 UART(pyserial)................................................................................................ 23

7REVISION HISTORY............................................................................ 24

NuMaker Tomato

Sep. 30, 2016 Page 3of 25 Rev 1.00

NUMAKER TOMATO USER MANUAL

1 OVERVIEW

NuMaker Tomato is an open development board. The NuMaker Tomato development platform

enables you to design prototypes for Internet of Things (IoT) devices, Gateway / Router or audio

stream application and Ethernet industrial control, using hardware and an API that are similar to

those offered for Arduino boards.

The platform is based on Nuvoton 300MHz ARM9 SoC which is highly integrated System-on-Chip

(SOC) design, The SoC provides features such as 10/100Mbps Ethernet, high-speed USB 2.0

host/device ports, and built-in 64M Byte DDRII memory .

The NuMaker Tomato uses the NUC976DK62Y as the target microprocessor. Figure 1-1 shows

the NuMaker Tomato board.

Figure 1-1 NuMaker Tomato Board

NuMaker Tomato

Sep. 30, 2016 Page 4of 25 Rev 1.00

NUMAKER TOMATO USER MANUAL

2 HARDWARE FEATURES

2.1 NuMaker Tomato Board Features

MPU: NUC976DK62Y with ARM® ARM926EJ-S™processor core running up to 300 MHz

Built-in 64M Byte DDRII memory

8 MB SPI Flash

USB CDC (Communications Device Class) port

10/100Mbps Ethernet

Stereo Audio Headphone out

Mono Microphone input

1.5W Mono Speaker output

MicroSD card slot up to 32G Byte

USB 2.0 High Speed Host

USB 2.0 High Speed Device

Figure 2-1 NuMaker Tomato Board Features

NuMaker Tomato

Sep. 30, 2016 Page 5of 25 Rev 1.00

NUMAKER TOMATO USER MANUAL

2.2 NUC976DK62Y Features

Core

–ARM® ARM926EJ-S™processor core running up to 300 MHz

–Supports 16 KB instruction cache and 16 KB data cache

Embedded SRAM and ROM

–Embedded 64MB DDRII

–Supports up to four booting modes:

USB / eMMC / NAND Flash / SPI Flash

Ethernet MAC Controller

–Supports IEEE Std. 802.3 CSMA/CD protocol

–Supports packet time stamping for IEEE Std. 1588 protocol

–Supports 10 and 100 Mbps operations

–Supports RMII interface to Ethernet physical layer PHY

–Supports Ethernet physical layer PHY management through MDC and MDIO interface

USB 2.0 Controller

–Supports USB Revision 2.0 specification

–Supports one set of USB 2.0 High-Speed (HS) Device/Host with embedded transceiver

–Supports one set of USB 2.0 High-Speed (HS) Host with embedded transceiver

–Supports 2048 Bytes internal SRAM for USB host function and 4096 Bytes internal

SRAM for USB device function

Flash Memory Interface

–Supports NAND Flash interface

–Supports 8-bit data bus width

–Supports SLC and MLC type NAND Flash device

–Supports 512 B, 2 KB, 4 KB and 8 KB page size NAND Flash device

–Supports ECC4, ECC8, ECC12, ECC15 and ECC24 BCH algorithm for ECC code

generation, error detection and error correction

–Supports eMMC Flash interface

I2S Controller

–I2S interface

Supports both mono and stereo

Supports both record and playback

Supports 8-bit, 16-bit, 20-bit and 24-bit data precision

Supports master and slave mode

–PCM interface

Supports 2 slots mode to connect 2 devices

Supports 8-bit, 16-bit, 20-bit and 24-bit data precision

Supports master mode

JPEG Codec

–Supports Baseline Sequential mode JPEG codec function compliant with ISO/IEC

10918-1 international JPEG standard

Crypto Engine

–PRNG

–Supports 64-bit, 128-bit, 192-bit and 256-bit key generation

–DES / 3DES / AES / SHA / HMAC

–Supports both encryption and decryption

Periphery

NuMaker Tomato

Sep. 30, 2016 Page 6of 25 Rev 1.00

NUMAKER TOMATO USER MANUAL

–UART/ SPI / I2C / 4-channel PWM / 12-bit ADC / CAN

NuMaker Tomato

Sep. 30, 2016 Page 7of 25 Rev 1.00

NUMAKER TOMATO USER MANUAL

3 BOARD EXTENSION INTERFACES

NU1

NU1

Name

Pin 1

GND

Pin 2

VDD3

Pin 3

RESET

Pin 4

VDD3

Pin 5

VIN5

Pin 6

GND

Pin 7

GND

Pin 8

VIN5

NU3

NU3

Name

MPU

Pin 1

9 (SW3)

GPF10

Pin 2

(LED2)

GPD7

Pin 3

ADC7

AIN7

Pin 4

ADC6

AIN6

Pin 5

ADC5

AIN5

Pin 6

ADC4

AIN4

NU2

NU2

Name

MPU Pin

Pin 1

GPA10

Pin 2

GPA11

Pin 3

PWM0

GPA12

Pin 4

PWM1

GPA13

Pin 5

PWM2

GPA14

Pin 6

PWM3

GPA15

Pin 7

GND

Pin 8

AVDD3

AVDD3 V

Pin 9

SDA

I2C SDA

Pin 10

SCK

I2C SCL

NuMaker Tomato

Sep. 30, 2016 Page 8of 25 Rev 1.00

NUMAKER TOMATO USER MANUAL

NU4

NU2

Name

MCU Pin

Pin 1

UART RX

Pin 2

UART TX

Pin 3

GPI4

Pin 4

GPI3

Pin 5

GPB2

Pin 6

GPB3

Pin 7

GPA8

Pin 8

GPA9

NU5

NU6

Name

MCU

NU6

MCU

Name

VIN5

Pin 1

Pin 2

VIN5

GPA0

Pin 3

Pin 4

GPA1

GPA2

Pin 5

Pin 6

GPA3

GPA4

Pin 7

Pin 8

GPA5

GPA6

Pin 9

Pin 10

GPA7

GPG6

Pin 11

Pin 12

GPG7

GPG8

Pin 13

Pin 14

GPG9

GPI7

Pin 15

Pin 16

GPI8

GPI9

Pin 17

Pin 18

GPI10

NU5

Name

MCU Pin

Pin 1

SPICLK

SPI CLK

Pin 2

VDD3

3.3V

Pin 3

MISO

SPI MISO

Pin 4

MOSI

SPI MOSI

Pin 5

SPI CS

Pin 6

GND

NuMaker Tomato

Sep. 30, 2016 Page 9of 25 Rev 1.00

NUMAKER TOMATO USER MANUAL

GPI11

Pin 19

Pin 20

GPI12

GPI13

Pin 21

Pin 22

GPI14

GPI15

Pin 23

Pin 24

GPJ0

GPJ1

Pin 25

Pin 26

GPJ2

GPJ3

Pin 27

Pin 28

GPJ4

TX0(UART)

GPE0

Pin 29

Pin 30

GPE1

RX0(UART)

39(LED3)

GPH1

Pin 31

Pin 32

VDD3

Pin 33

Pin 34

VDD3

GND

Pin 35

Pin 36

GND

NuMaker Tomato

Sep. 30, 2016 Page 10 of 25 Rev 1.00

NUMAKER TOMATO USER MANUAL

4 GETTING STARTED WITH NUMAKER TOMATO

4.1 Download Software Package and USB CDC Driver

Please download the software package from Nuvoton’s official webpage:

http://www.nuvoton.com/opencms/resource-download.jsp?tp_GUID=SW1020160914071736

The software package includes the Linux 3.10 kernel, precompiled Python bin, USB Wi-Fi driver,

Periphery sample code and application demo code.

Please download Nuvoton USB CDC driver from Nuvoton’s official webpage:

http://www.nuvoton.com/opencms/resource-download.jsp?tp_GUID=SW0620160913015934

4.2 Install Nuvoton USB CDC Driver

Please execute the “NuvotonCDC_V1.00.001_Setup.exe” to install the driver.

Figure 4-1 Software Package List
