Nvidia NForce 680I LT SLI Guida all'installazione

Enthusiast

CPU Socket Type

Socket 775

Formfactor

Full ATX

Processor Type

Intel

NVIDIA®nForce®680i LT SLI™

MCP is engineered for the extreme gamer.

Featuring award-winning NVIDIA nForce 680i SLI performance, true dual x16 PCI Express slots with support

for NVIDIA SLI™ technology, and best-in-class overclocking, the NVIDIA nForce 680i LT SLI motherboard

delivers extreme gaming performance at a great price.

XFX Part Numbers:

MB-N680-ILT

nForce®680i LT SLITM

1333MHz FSB DDR2 800 Motherboard

• 1333MHz FSB achieves up to 22% faster performance*

• Up to 19% better performance in PCMark05*

• Fully support all Socket 775 including Intel Core 2

Quad Processors

• Features NVIDIA SLI memory enhancement

• Premium High Deﬁnition Audio brings you home

theater audio experience

• XFX NVIDIA powered graphics card compatibility

*Performance of XFX 680i SLI motherboard compared with Intel 975 and Intel 965 chipset motherboards

nForce®680i LT SLITM

1333MHz FSB DDR2 800 Motherboard

High-Speed Memory

Support high-speed SLI-Ready memory up to DDR2-800 to keep pace with

overclocked systems components.

High Deﬁnition Audio (HDA)

High deﬁnition audio brings consumer electronics quality sound to the PC

delivering high quality sound from multiple channels. Using HDA, systems can

deliver 192 kHz/32-bit quality for eight channels, supporting new audio formats.

NVIDIA® nTune Utility

Suite of features that safeguards your most important digital media assets;

always reliable, scalable, and accessible. Includes RAID and SATA drive support.

TCP/IP Acceleration

TCP/IP Acceleration delivers the highest system performance by ofﬂoading

CPU-intensive packet ﬁltering tasks in hardware, providing users a faster PC

networking environment.

Model Number MB-N680-ILT

Package Contents Installation Manual, Quick Install and Reference Guide, Driver CD,

1394a Cable (1 port), USB 2.0 Cable (4 ports), SATA Data Cable x2,

IDE Cable, Floppy Cable, SATA Power Cable, SLI Bridge, I/O Shield

CPU Socket Type Socket 775

CPU Type Core 2 Extreme, Core 2 Quad, Core 2 Duo, Pentium EE,

Pentium D9XX, Pentium D8XX

Chipset NVIDIA nForce 680i LT SLI MCP

FSB 1333Mhz FSB

System Memory 240-pin DDR2 up to 8GB (4)

Expansion Slots PCI-E x16 (2), PCI-E x1 (2), PCI (2)

SATA port SATA II ports (6)

LAN Gigabit LAN cards

IEEE 1394 (Firewire) 1394a (2)

USB USB 2.0 ports (8)

Audio 8-channel integrated HDA sound card

Dimensions Full-size ATX (12”x 9.6”)

www.XFXforce.com

nForce®680i LT SLITM

1. Socket 775 support FSB of 1333 MHz

2. NVIDIA SPP with Active fan (North Bridge)

3. DDR2 DIMM Slots supporting SLI-Ready Memory w/ EPP up

to 800 MHz

4. IDE Connector

5. Serial-ATA II 3GB/s

6. NVIDIA Multimedia and Communication Processor (South Bridge)

7. USB 2.0 Headers

8. True PCI Express x16 slots/NVIDIA SLI Technology

1. PS/2 Mouse Port

2. PS/2 Keyboard Port

3. 1394a (Firewire) Port

4. USB 2.0 ports (2)

5. SPDIF output

6. 8-Channel High Deﬁnition Audio

7. USB 2.0 Ports (2)

8. Gigabit Ethernet Port

23456 7
