OKI TONER REPLACEMENT INSTRUCTIONS FOR

B2520 B2540

Toner cartridge replacement

Your machine comes with a current consumable management system. It tells you if your toner cartridge is close to its

end of cycle. The following message will appear on your machine screen.

TONER NEAR

END

After this message has been displayed, you are able to change the cartridge.

To quit this screen, press OK.

To replace the toner cartridge, proceed as shown below.

When the following message is displayed on the screen:

TONER EMPTY

REPLACE <OK>

1 Press OK.

OPEN FRONT

COVER

REPLACE TONER

2 Stand in front of the device.

3 Push on the left and right sides of the cover and pull it towards you.

4 Raise and remove the toner cartridge from the machine.

5 Unpack the new cartridge and insert it into the slot as indicated in the diagram below.

6 Close the cover. The following message appears:

HAVE YOU

CHANGED

THE TONER? <OK>

insert the smart card provided with the new toner cartridge as shown on the picture below.

GFBM 2/18/2008

OKI TONER REPLACEMENT INSTRUCTIONS FOR

B2520 B2540

GFBM 2/18/2008

9 A wait message appears.

PLEASE

WAIT

The smart card is read.

NEW TONER

REMOVE CARD

Remove the smart card from the reader, your machine is ready to print again.

Issues with smart cards

If you use a smart card that has already been used, the machine will display:

PLEASE

WAIT

then,

REMOVE CARD

ALREADY USED

If you use a defective smart card, the machine will display:

PLEASE

WAIT

then,

UNKNOWN CARD

REMOVE CARD

If the C button is pressed while the smart card is being read, the machine displays:

ACTION CANCELLED

REMOVE CARD
