Olympus 200 Manuale utente
INSTRUCTIONS
Table of contents
Preparationsbefore takingpictures
Loading the batteries
.................
2
Simple operating procedures
Loading
the
film
....................
4
Taking pictures
.....................
7
Unloading
the
film
..................
13
Automatic flash activation
(1)
Taking pictures
in low light
..........
15
(2)
Taking backlighted subjects
..........
18
Advanced shooting techniques
Spot metering
......................
19
Auto-zoom photography
..............
21
Taking
a
continuous scries
of
shots
.......
23
Using
the
self-timer
..................
24
AUTO-S flash mode
.................
25
Flash OFF mode
....................
28
FILL-IN
flash
mode
.................
29
MULTI
flash
mode
.................
31
Using
the
remote control
..............
33
Use
of
fillers
.......................
36
Mounting
the
strap
..................
38
Use ofthe
optionalOlympuscase
........
39
Care
and
storage
......................
40
Questions
and
answers
..................
42
Description
of
controls
..................
44
Viewfinder
display
and LCD
panel
..........
46
Specifications
........................
47
•Please read this instruction manual carefully before using yourcamera. •Thiscamera will not operate unless the barrier is opened.
•Before takingimportant pictures suchasontravels, itisrecommended that youtaketrial pictures.
1
Remove the battery cover on the
side of the grip.
Insert the batteries in the correct
directions and replace the cover.
Preparations
before taking
pictures
Loading the batteries
Be sure to the correct
batteries, and do not mix
new and old batteries at the
same time.
Remove the batteries and
keep them in a safe place if
you are not likely to use the
camera for long time.
Two 3V lithium batteries
(DL123A/CR123A)
2
Note: After inserting the batteries the
camera may activate electronically
without having set the power switch
to the ON position In this switch-
ON status, the barrier opens and the
LCD panel is indicated The LCD
panel will remain on for approximate-
ly4, 5 minutes.
Set the power switch to ON and
check the charge remaining in the
batteries.
Battery power will be displayed in
the LCD panel.
When is displayed for 12 sec.,
the batteries are OK.
When blinks, it indicates that
the battery power is low, and the
batteries should be replaced.
When lights, replace the
batteries immediately.
3
To open the back, slide the back
cover lock up.
The camera back will open.
Simple operating
procedures
Loading the film
Thiscamera isdesignedto
use 35mm film with "DX"
coding to automatically set
film speed.
If no "DX" film is available,
use ISO-100 film.
4
Prepare a "DX" film cartridge.
Your camera will automatically set
itself for DX-coded film speeds
ranging from ISO 50 — 3200. (Refer
toPage47.)
• In case of non DX film, film speed
is automatically set to ISO 100.
Insert the film cartridge into the
camera.
Always avoid direct sunlight when
loading the film.
Make sure the film lies flat.
5
Align the film leader with the red
mark.
Close the camera back.
6
Setting the powerswitch to ON,
check that the exposure counter
displays"1".
•If the film is not loaded properly, the
exposure counter will not show "1"
and a display as shown in the illus-
tration will appear in the LCD panel
In this case, reload the film correctly.
You can check the type of film in
usethrough the window inthe
back of the camera.
Taking pictures
When the power switch is on,
the LCD panel lights.
The LCD panel goes out
after 4.5 minutes.
Then the lens will zoom
to the wide-angle
position.
7
Set the power switch to ON, which
will open the lens barrier. When the
camera is not in use, always set the
power switch to OFF so that the
shutter cannot be activated by acci-
dent and the lens barrier will be
closed to protect the lens.
When the power switch is set to ON,
thebarrier opens and thelens shifts
out to the wide angle shooting
position.
While looking through the
viewfinder, aim the camera at the
subject you wanttoshoot.
8
Operate the zoom button to adjust
the lensuntil yousee theimageyou
want.
When the T side of the zoom button
is pressed, the lens will zoom to the
telephoto side.
(In the telephoto position. the maxi-
mum focal length ofthe lens is
80mm.)
When the W side of the zoom button
is pressed, the lens will zoom to the
wide-angleside.
(In the wide-angle position, the
minimum focal length of the lens is
38mm.)
9
