Omega Altise O14B Manuale utente

O14B

35cm Turbo Tilt

Box Fan

Instruction

Manual

omega altise

Important Safety Instructions

1. Read all instructions.

2. Disconnect the power plug before dismantling, assembling or before cleaning.

3. Avoid touching mobile parts of the fan.

4. Make sure the fan is on a dry and even surface.

5. Never insert fingers, pencils or any other objects through the guards whenever

the power plug is connected, especially while running.

6. The appliance is not intended for use by young children or infirm persons unless

they have been adequately supervised by a responsible person to ensure that

they can use the appliance safely.

7. Young children or infirm persons should be supervised to ensure that they do not

play with the appliance.

8. Do not use the appliance for any other purpose than its intended use.

9. The fan must not be used if the guards are not fastened according to

instructions.

10. When the power cord is damaged, it must be replaced by the manufacturer or its

service agent or a similarly qualified person in order to avoid a hazard.

11. Do not use your appliance with an extension cord unless it has been checked

and tested by a qualified electrician or electrical supplier.

Read all instructions before using this unit. Keep them for future reference.

Specifications

Model O14B – Turbo Tilt Settings 3 speed, louvre control

Rated Voltage 220-240V / 50Hz Fan blade size cm 35

Watts 70 Tilt action Tilting fan body

Dimensions

(h x w x d) mm 520 x 450 x 200 Oscillation Rotating grille

Weight (carton) kg 5.1 Warranty 2 year replacement

omega altise

Parts List

1. Push control switch

2. Rear Guard

3. Cord

4. Plug

5. Foot

6. Fan blade

7. Front cover

8. Grille hub

9. Grille

10. Fan body

Operating Instructions

1. Use in a dry place, free of excessive humidity and water.

2. To set the fan in motion push the switches to obtain desired fan speed:

0 = OFF 1 = LOW 2 = MEDIUM 3 = HIGH

The fifth button operates the rotating louvre

3. The direction of the airflow is vertically adjustable by tilting the fan body as

shown above.

4. To stop the fan and rotating louvre push the 0 button.

omega altise

Care and Maintenance

1. Always disconnect the cord from the electrical outlet when cleaning your fan.

2. Light accumulated dust may be removed from the fan with a soft cloth or vacuum

cleaner using the dusting brush attachment.

3. Wipe the exterior surfaces of the fan occasionally with a cloth moistened (not

dripping wet) with a mild soap solution. Dry the case thoroughly with a soft dry

cloth before operating the fan.

4. Avoid the use of gasoline, benzine, thinner etc as they may result in damage to

the fan.

5. To clean the fan blades use a screwdriver to remove the rear guard (3 screws),

unscrew the blade fixing screw to take the blade off. Clean the blade with a soft

cloth moistened with a mild soap solution. Replace by tightly securing the blade

with the blade fixing screw. Place the rear guard back into position and fix with

the screws.

6. Store the fan in a clean dry place when not in use.

CAUTION! Do not immerse the fan in water or allow water to drip into

the interior of the fan housing as this could create a fire or electric

shock hazard.

WARNING! Do not attempt to repair the fan yourself. Doing so could

void the warranty and cause damage or personal injury.

Omega Altise products are distributed in Australia by MEA,

(A Division of Hagemeyer Brands Australia Pty Ltd)

ABN 28 001 375 686

Locked Bag 4013, Kingsgrove NSW 2208

Phone: 1300 739 033

Fax: 1800 838 899

Email: [email protected]

Web: meaappliances.com.au
