Ortur Laser Master 2 Pro Manuale utente
Dongguan Ortur Intelligent Technologies Co., Ltd.
https://ortur.tech/olm2pro
1
No.1 Building, Ruijin Science and Technology Industrial Park, Changping, Dongguan 523558, Guandong Province, China
User Manual
V1.0 - 01 June 2021
Laser Master 2 Pro
Optional Upgrades
Manual Z-Height Oine Controller
2
Dongguan Ortur Intelligent Technologies Co., Ltd.
https://ortur.tech/olm2pro
No.1 Building, Ruijin Science and Technology Industrial Park, Changping, Dongguan 523558, Guandong Province, China
Welcome
Thank you for choosing the Ortur Laser Master 2 Pro!
This manual will guide you through the steps required to assemble, ne tune and
operate your Ortur Laser Master 2 Pro safely and productively.
Please do not skip the Security and Safety Guidelines, and refer back to this
manual Troubleshooting Section if you encounter any problem.
If this manual does not address an issue you are having, please see below all the
contacts on which you could get in touch with our Support Team.
For the most expedite resolution of your problems we ask you to give priority to
contacting our Support Team via our ticketing system at https://ortur.tech/support
We strongly recommend joining our Ocial User Group at Facebook. In This
group you will nd a community of over 15000 users that are always willing to help
and share ideas, tips and trick. https://www.facebook.com/groups/orturusergroup
Description Link/URL
Laser Master 2 Pro Product Page https://ortur.tech/olm2pro/
Ortur Knowledge Base/FAQ https://ortur.tech/kb/docs/
Ortur Customer Support https://ortur.tech/support/
Ortur User Feedback https://ortur.tech/feedback/
Ortur Firmware Repository https://ortur.tech/latest-rmware/
Ortur Product Advisory https://ortur.tech/product-advisories/
Facebook Page https://www.facebook.com/realortur
Facebook User Group https://www.facebook.com/groups/orturusergroup
Youtube https://www.youtube.com/channel/UCvfgW64XBwJH7yd0E79s8Dg
Instagram https://www.instagram.com/orturocial/
Twitter https://twitter.com/OrturOcial
Online Presence - Links
QR Codes
3
Dongguan Ortur Intelligent Technologies Co., Ltd.
https://ortur.tech/olm2pro
No.1 Building, Ruijin Science and Technology Industrial Park, Changping, Dongguan 523558, Guandong Province, China
Contents
WIP
4
Dongguan Ortur Intelligent Technologies Co., Ltd.
https://ortur.tech/olm2pro
No.1 Building, Ruijin Science and Technology Industrial Park, Changping, Dongguan 523558, Guandong Province, China
Security & Safety Guidelines
Basic Information
The Ortur Laser Master 2 Pro engraves and cuts materials by the means of a
high-energy diode laser beam.
The hazards associated with a high-energy diode laser beam include the
possibility of res, generation of hazardous and/or irritating toxic fumes, but more
importantly damage to eyes and skin.
International Classications
Laser engravers are divided into several internationally valid classes based
on their performance and the risk of injury. For the scope of this guide we will
focus on the American FDA classication, even though there are similar other
classication tables.
The Ortur Laser Master 2 Pro falls into the Class IV (Class 4 IEC standard)
as it’s an open, non-enclosed laser engraver, therefore Personal Protective
Equipment (PPE) should be worn at all times – by everyone in the proximity of
the machine, when operating the Ortur Laser Mater 2 Pro.
If you enclose your Ortur Laser Master 2 Pro, make sure the enclosure follows
the above classication guidelines and complies with the international standards.
Laser class Class Denition
Class I Class I laser radiation is not considered hazardous.
Class IIa Class IIa laser radiation is not considered hazardous if viewed for any period of
time less than or equal to 1x103 seconds, but is considered a chronic viewing
hazard for any period of time greater than 1x103 seconds.
Class IIa Class II laser radiation is considered a chronic viewing hazard.
Class II Class IIIa laser radiation is, depending upon the irradiance, either an acute in-
trabeam viewing hazard or chronic viewing hazard. If viewed directly with optical
instruments, Class IIIa laser radiation is classied as an acute viewing hazard.
Class IIIb Direct Class IIIb laser radiation is considered an acute hazard to the skin and
eyes.
Class IV Class IV laser radiation is considered an acute hazard to the skin and eyes from
both direct and scattered radiation.
5
Dongguan Ortur Intelligent Technologies Co., Ltd.
https://ortur.tech/olm2pro
No.1 Building, Ruijin Science and Technology Industrial Park, Changping, Dongguan 523558, Guandong Province, China
Hazards and Precautions
Laser Light
The high energy laser beam can cause severe eye damage,
including blindness and serious skin burns.
Improper use of the controls and modication of the safety features
may cause serious eye injury and burns.
It is recommended to select a room to operate the Ortur Laser Master 2 Pro
where access can be controlled by means of a solid door. No direct view to the
laser beam should be possible from the outside. When possible, a signs should be
used to indicate the Ortur Laser Master 2 Pro is in Operation.
• DO NOT look directly into the laser beam;
• DO NOT aim the laser beam at reective surfaces;
• DO NOT operate the laser without PPE protection for all persons nearby in the
proximity of the Ortur Laser Master 2 Pro
• DO NOT allow unsupervised access to the Ortur Laser Master 2 Pro to
children;
• DO NOT allow access near the Ortur Laser Master 2 Pro to pets;
• DO NOT modify or disable any safety features of the laser system;
• DO NOT touch the high energy laser beam;
Personal Protection Equipment (PPE)
Laser Safety glasses are mandatory at all times when adjusting and
operating the Ortur Laser Master 2 Pro. These should be worn by
the user and any person in the proximity of the Ortur Laser Master
2 Pro.
• Safety Glasses are designed to lter specic ranges of laser wavelength. The
Ortur Laser Master 2 Pro Safety Glasses provided are specic for Ortur Laser
Module;
• If you wish to purchase additional Safety Glasses, these must be applicable to
the Ortur Laser Master 2 Pro Laser Module (wavelength and optical density);
Ortur Laser Master 2 Pro Laser Module has a wavelength of 445nm –
the Rating of the Safety Glasses should be no less than O.D. 4;
Note: the tint/colour of the Safety glasses is not an indication of their specication
6
Dongguan Ortur Intelligent Technologies Co., Ltd.
https://ortur.tech/olm2pro
No.1 Building, Ruijin Science and Technology Industrial Park, Changping, Dongguan 523558, Guandong Province, China
Fire Hazard
The high-energy diode laser beam can produce extremely high
temperatures and signicant amounts of heat as the substrate
material is burned away while engraving and cutting. Some
materials are prone to catch re during cutting operations creating
ame, fumes and smoke.
Although the Ortur Laser Master 2 Pro has a built in ame sensor, this
technology should NOT be considered 100% accurate and should be seen
only as a warning system.
The ame sensor does not have the ability to extinguish ames.
The sensor can only alert the user for the possibility of a ame on
the machine. Do not ignore the Flame sensor Alarm!
It is recommended to select a room to operate the Ortur Laser Master 2 Pro
where access to good ventilation is available as well as make the working
area as re proof as possible. It is important that user remain with the laser
during operation to ensure that any are ups/ ame are properly contained and
extinguished.
It is strongly recommended that a Fire Extinguisher should be located within
close proximity to the Ortur Laser Master 2 Pro. Extinguishers should be
halogen or multi-purpose dry chemical. Alternatively or in conjunction with the Fire
Extinguisher it is recommended a “Fire Extinguisher Ball” is positioned beside the
Ortur Laser Master 2 Pro.
• DO NOT use materials that are highly ammable, explosive or produce toxic
by-products;
• DO NOT remove material from the cutting bed before it has cooled;
• DO NOT leave the Ortur Laser Master 2 Pro operating unattended;
• ALWAYS clean up clutter, debris and ammable materials in the laser Ortur
Laser Master 2 Pro bed after use;
• ALWAYS keep a properly maintained re extinguisher nearby;
• DO NOT allow the USB cable to come in contact with the laser Beam;
• DO NOT allow the 24v power cable to come in contact with the laser Beam;
7
Dongguan Ortur Intelligent Technologies Co., Ltd.
https://ortur.tech/olm2pro
No.1 Building, Ruijin Science and Technology Industrial Park, Changping, Dongguan 523558, Guandong Province, China
Laser Generated Air Contaminants
Laser engraving or cutting will generate fumes, vapours and
particulates from the substrate material that can be highly toxic.
Is recommended to select a room to operate the Ortur Laser
Master 2 Pro where access to good ventilation is available and
proper ventilation is maintained at all times when the Ortur Laser Master 2 Pro is
in operation.
Although most of the recommended materials for engraving on the Ortur Laser
Master 2 Pro are safe, the user should seek information each time a new material
is used.
Some materials, specially plastic based, will generate highly toxic
fumes that are - not only - very health hazardous but can also
damage and corrode your Ortur Laser Master 2 Pro metal frame.
Below a list of some of the most known hazardous materials that the user
SHOULD NOT attempt to engrave or cut on. If a material is not in this list, do
not consider it to be safe to use. Obtain the Safety Data Sheet (SDS) from the
material’s manufacturer when handling unknown materials.
Material Reason to avoid engraving / cutting it
PVC (Poly Vinyl
Chloride)
PVC will emit Chlorine gas when laser cut or laser engraved. This toxic gas can
ruin the optics and motion control system of the laser engraver, In fact, engraving
or cutting PVC is a sure way of voiding the warranty of your laser engraver
Lexan / Thick Poly-
carbonate
Lexan not only cuts poorly but it also catches on re very easily. The window of
the laser engraving machine is usually made from polycarbonate because it does
a very good job of attracting infrared radiation., which is the frequency of light the
engraver uses when cutting and engraving materials. This makes the laser cutter
quite ineective in cutting polycarbonate materials
ABS ABS melts upon exposure to a laser beam as opposed to vaporizing which would
be the ideal reaction needed for laser engraving. Instead of leaving a crisp image,
ABS will melt and leave a gooey deposit on the surface.
HDPE HDPE melts and catches on re pretty easily upon exposure to a laser beam.
Polystyrene Foam Only very thin pieces can be laser cut but for the most part, polystyrene catches
on re and melts when exposed to a laser beam
Fiberglass Fiberglass is made from two materials; glass and epoxy resin. The best method
of marking glass is etching while epoxy resin can emit toxic fumes upon laser
engraving. These two reasons make berglass a bad choice for a laser engraving
material
Polypropylene polypropylene melts and catches on re easily and then the melted material con-
tinues to burn thereby forming pebble-like drips that harden on the surface
Coated Carbon
Fiber
Coated carbon ber emits noxious fumes. Additionally, carbon ber can be cut
albeit with some fraying but this is not the case when it is coated.
8
Dongguan Ortur Intelligent Technologies Co., Ltd.
https://ortur.tech/olm2pro
No.1 Building, Ruijin Science and Technology Industrial Park, Changping, Dongguan 523558, Guandong Province, China
Specications
Description Values
Mechanics
Working Area 400x400 mm (15.75x15.75 In)
Z-Height Clearance 45mm
Min Engraving Speed 40 mm/min
Max Engraving Speed 10000 mm/min
Frame materials Aluminium Extrusion V-slot 20x20
Powder Coated Steel Frame
End-Stops - Limit Switches Mechanical X and Y Limit switches
Drag Chain - Cable Management Y Axis Drag Chain - Zip Ties
Timing Belt GT2 6mm, 2mm Pitch (60cm)
Stepper Motors Nema 17HS Series
X-axis 42mmx38mm - 30mm D Shaft
Y-axis 42mmx29mm - 24mm D Shaft
Sprocket 16mm - 20 Tooth
Y Axis Synchronization Shaft 5mm Stainless Steel
Wheels D Type POM Wheels (Polyoxymethylene)
Linear Bearing - 24mmx10.4mm
Laser Module
Technology Diode Laser
Wavelength 445nm
Power Input 24v 2Amp
Optical Output (W) 0.5W - 10W (Depending on LU2 model)
Laser Control Mode PWM 5V 1khz Duty Cycle
S-Value Range S0-S1000 (0%-100%)
Focus Type Fixed Focus - 50mm Focal Range
Dot Size at optimal Focus 0.08x0.15mm (Depending on LU2 model)
Laser Class FDA Class IV; Class 4 IEC standard
Dimensions and Weight
Packaging Size 66x25x11 cm
Packaging Weight 4.60kg
Machine Size Assembled 57x60x14cm (22.44x23.62x5.51 In)
Machine Weight Assembled 3.8kg
Electricity, Power, Ambient Conditions
Power Adapter Input Voltage (AC) 110-220v 50-60Hz Single Fase
Power Adapter Output Voltage (DC) 24v 2Amp
Power Consumption 48w
Operating Temperature -20ºc - 50ºc
Humidity 40% to max. 70% not condensing
9
Dongguan Ortur Intelligent Technologies Co., Ltd.
https://ortur.tech/olm2pro
No.1 Building, Ruijin Science and Technology Industrial Park, Changping, Dongguan 523558, Guandong Province, China
Description Values
Features
Micro Controller OLM-Pro-V10 32Bit Micro Controller
Safety Features Active Motion Protection
Exposure Duration Detection and Limitation
Laser Beam Safety Guard
Flame Detection Sensor
Emergency Stop Button
Connection Loss Guard
Software - Operating System
Micro Controller Firmware Core GRBL 1.1h
Interface Hardware USB Serial Com (UART)
Baud Rate (115200 - 921600) - Default 115200
Wi (Optional Add-on)
BlueTooth (Optional Add-on)
Compatible Operating Systems Windows XP, Vista, 7, 8 10; MacOs; Linux
Note: Chrome OS not compatible
Compatible Recommended Software Windows: LaserGrbl, LightBurn
Mac: LightBurn
Linux: LightBurn
Diagrams
10
Dongguan Ortur Intelligent Technologies Co., Ltd.
https://ortur.tech/olm2pro
No.1 Building, Ruijin Science and Technology Industrial Park, Changping, Dongguan 523558, Guandong Province, China
The Ortur Laser Master 2 Pro has built in technology and
algorithms to keep its users and the surrounding environment safe.
This said its important to understand the Ortur Laser Master 2 Pro
is not a toy and should be operated with care and respect.
Below a few items in Check List form for your consideration:
WIP
Operational Recommendations and Safety Checks
Indice
Altri manuali Ortur Stampante 3D
