Oticon HIT CIC Manuale utente

CIC, MIC, ITC, HS/LP

INSTRUCTIONS FOR USE

HIT PRO/HIT

Thank you

Thank you for choosing our product as your means to better hearing.

To support your efforts, we have put great care and attention into making sure that your

new hearing instruments are of the highest quality and that they are easy to use and

maintain.

We recommend that you read this manual carefully to achieve the maximum benefit from

your new hearing instruments.

Congratulations on your decision to actively improve your hearing with today’s most

advanced hearing technology in the market.

Contents

Instrument View CIC/MIC 5a

Instrument View ITC 5b

Instrument View HS/LP 5c

Changing batteries 7

Turning your instruments ON and OFF 9

Inserting your hearing instruments 10

Programs (Optional) 11

Stand-by – (only for instruments with push-button) 13

Volume Control (Optional for ITE only) 14

Telecoil (Optional) 15

AutoPhone (Optional) 16

Caring for your hearing instruments 18

Seven easy steps to better hearing 23

Common problems and their solutions 28

Warnings Yellow Pages

IMPORTANT NOTICE

Please familiarize yourself with the entire contents of this booklet before using your

hearing instruments. It contains instructions and important information about the use

and handling of your hearing instruments and batteries.

Instrument View CIC/MIC

Microphone opening Battery door

Ventilation opening

Sound outlet + wax

protection system

Ventilation opening

Removal string

Battery size: 10

Instrument View ITC

Microphone openings

Battery door Ventilation opening

Ventilation opening

Sound outlet + wax

protection system

Push-button (Optional)

Battery size: 312

Instrument View HS/LP

Battery size: 312

Microphone openings Push-button (Optional) Sound outlet +

wax protection system

Ventilation openingVolume Control Wheel

(Optional)

Battery door

Changing batteries

The correct battery size appears in the instrument overview in the first section of this

document.

A worn out battery should be removed immediately and disposed of according to local

regulations.

When the battery power is low, you will hear 2 beeps. This pre-warning starts when

the battery has only a few hours of operation left. The pre-warning will be repeated

in moderate intervals to indicate it is time to change the battery.

To replace the battery, follow these instructions:

Open the battery door with your fingernail and remove•

the old battery. The old battery may be removed by

using the magnetic end of your MultiTool.

Use the magnet at the end of the tool to assist in handling the battery.

MultiTool

8 9

Remove the sticky label from the + side of the new battery.•

Insert the new battery so that its + marking faces the + sign•

printed on the battery door.

Close the battery door. If you feel any resistance, you may•

have inserted the battery incorrectly. Reinsert the battery

and try again.

It will take a few seconds before the battery works to full capacity.

Turning your instruments ON and OFF

Turn ON your hearing instrument by closing the battery door

completely with the battery in place.

When the battery door is closed the instrument will start up

by playing a jingle. This indicates that the battery is working

and the instrument is operating.

Turn OFF your hearing instrument by opening the battery

door with your finger nail.

To preserve the battery, make sure your hearing instrument

is switched off when you are not wearing it.

OFF

IMPORTANT NOTICE

Open the battery compartment fully to allow air to circulate whenever you are not using

your hearing instrument, especially at night!

10 11

Inserting your hearing instruments

Place the tip of the hearing instrument in your ear canal.

Gently pull your earlobe and push the hearing instrument

into the ear canal, twisting slightly if necessary, following

the natural contour of the ear canal.

DO NOT use the battery door as a handle to insert or remove

your instruments. It is not designed for this purpose.

Programs (Optional)

Your hearing instruments may have a push-button for switching between different programs.

Push briefly on the button to switch between programs.

Your hearing instrument can have up to 4 different programs. When switching between

the different programs, your hearing instrument will beep. The number of beeps will

indicate which program you are using.

eOne beep, when you switch to program 1

ee Two beeps, when you switch to program 2

eee Three beeps, when you switch to program 

eeee Four beeps, when you switch to program 4

12 13

Below you can see a description of the programs available in your hearing instrument.

Prg. 1:

Prg. 2:

Prg. 3:

Prg. 4:

To be filled out by your Hearing Care Professional.

Stand-by – (only for instruments with push-button)

If your hearing instrument has a push-button, push the button for a minimum of  seconds

to set the instrument in standby mode.

To reactivate the instrument, push the button briefly again.

Use the standby function if you need to silence the instrument.

PUSH

for 3 seconds

IMPORTANT NOTICE

Do not use the stand-by function as an off switch as the hearing instrument still

draws current from the battery in this mode.

14 15

Volume Control (Optional for ITE only)

Your ITE instrument may have a volume control wheel. The volume control wheel can be

turned with the tip of a finger and can be rotated infinitely both ways.

The volume control allows you to adjust the volume in specific listening situations to the

level you feel comfortable with.

To increase volume, turn the wheel forward.

To decrease volume, turn the wheel toward

the back of your head.

You will hear a beep when you increase or

decrease the volume.

When the hearing instrument is turned on, it starts up at a preferred volume level. When

adjusting the volume control to the preferred level, this is indicated by 2 short beeps.

Telecoil (Optional)

The telecoil is an inductive receiver for audio signals. The telecoil is meant for telephone

conversations and for loop systems in e.g. theaters, churches or lecture rooms.

The telecoil is activated by the push-button. When activated, you will hear a certain

number of beeps corresponding to the telecoil program.

See Programs for the telecoil program setting.

Volume

Control Wheel
